Sonance Cinema Ultra II
®
Sonance Cinema Ultra II® LCR Cabinet speakers offer the
ultimate in cinema performance to those who can't use Sonance
in-wall speakers. In fact, earning THX® Ultra 2 certification
guarantees that in rooms over 3,000 cubic feet, Cinema Ultra II
LCR Cabinet speakers will reproduce film soundtracks precisely
as their filmmakers intended them to sound.
The new enclosure is a key to the Cinema Ultra II LCR Cabinet
speaker's superior performance. The 1"-thick MDF baffle and
back panels maintain ultra-high rigidity and banish
resonances. An exclusive laminate made-up of ½" MDF and ½"
particle board maximizes stiffness and reduces resonances in the
top, bottom and side panels.
Sonance Cinema Ultra II LCR Cabinet speakers establish the
benchmark for home entertainment performance, and are ideal
for both multi-channel home theater and music applications.
Features:
• Cabinet configuration offers top-of-the-line Sonance quality
and performance to listeners who can't use in-wall speakers.
• THX
Ultra 2 certification guarantees cinema-quality
®
performance in even the largest home theater rooms.
• Same drivers and voicing as Cinema Ultra II in-wall speakers
allows mix-and-match between in-wall and cabinet versions
while maintaining character and quality of 'Sonance sound'.
• Rotating tweeter/midrange array allows horizontal placement.
• Ultra-rigid 1" MDF baffle and back panels minimize resonances.
• Cabinet top, bottom & sides made from an exclusive laminate
of ½" MDF and ½" particle board, for superior stiffness and
resonance damping.
• Extensive cross-bracing maximizes enclosure stiffness.
• Tweeter level control and boundary compensation control
fine-tune performance for a variety of installations.
w w w . s o n a n c e . c o m
212 Avenida Fabricante
San Clemente, CA 92672-7531 USA
(800) 582-7777 or (949) 492-7777
FAX: (949) 361-5151
Technical Support: (800) 582-0772
©2004 Sonance, All Rights Reserved. Sonance, Sonance Cinema Ultra II and RotoLock are trademarks of Sonance. THX and THX Select are trademarks or registered trademarks of THX, LTD.
Cinema Ultra II LCR Cabinet
LCR Cabinet Speakers
All specifications are subject to change without notice. 09/04
Sonance Cinema
SPECIFICATIONS
Cinema Ultra II LCR Cabinet
Tweeter
Midrange
Woofer
Frequency Response
Impedance
Power Handling
Sensitivity
Baffle & Back Panel Material
Top, Bottom & Side Panel Material
Grille Material
Adjustments
Dimensions (W x H x D)
Shipping Weight
DIMENSIONS
Cinema Ultra II
LCR Cabinet Speaker
®
Series
1" (25mm) Silk dome, Ferrofluid-cooled,
shielded magnet
Two 3" (76mm) One-piece black aluminum
cones, rubber surrounds, shielded magnets
8" (203mm) One-piece black aluminum
cone, rubber surround, shielded magnet
70Hz – 20kHz ±3dB
6 Ohms nominal; 4 Ohms minimum
5 watts minimum; 200 Watts maximum
90dB SPL (2.83V 1 meter)
1" MDF
Laminate (½" MDF / ½" particle board)
Black cloth
±3dB Tweeter level, boundary compensation
1
3
10
/
" (257mm) x 18
/
" (467mm) x 11½" (292mm)
8
8
35 lbs. (15.9 KG) each
