Sonance Symphony S622C Specification Sheet

Sonance Symphony Cabinet Speakers
®
The Sonance Symphony® S622
C
formance and quality of Sonance Symphony series in-wall
speakers to those who can't use in-wall speakers. Ideal for both
multi-channel home theater and stereo music applications,
Symphony S622 Cabinet speakers deliver impressive musical
C
performance, yet they integrate into a wide variety of lifestyles.
The new enclosure is one key to the Symphony S622
speaker's superior performance. The 1"-thick MDF baffle and
back panels maintain ultra-high rigidity and banish resonances.
An exclusive laminate made-up of ½" MDF and ½" particle
board maximizes stiffness and reduces resonances in the top,
bottom and side panels.
The Sonance Symphony S622
C
quality entertainment to life anywhere in the home while its
compact size allows it to be used in a variety of installations.
Features:
• Cabinet design offers Sonance Symphony series quality and
performance to listeners who can't use in-wall speakers.
• Same voicing as Sonance Symphony in-wall speakers allows
mix-and-match between in-wall and cabinet versions while
maintaining character and quality of 'Sonance sound'.
• Polypropylene woofer cone delivers robust, low-distortion bass;
silk dome tweeter has extended high-frequency response.
• Tweeter acoustic back chamber widens and smoothes
high-frequency performance.
• Large woofer magnet increases output and power handling.
• Ultra-rigid 1" MDF baffle and back panels minimize resonances.
• Cabinet top, bottom & sides made from an exclusive laminate
of ½" MDF and ½" particle board, for superior stiffness and
resonance damping.
• Large connection terminals accept up to 14AWG speaker wire.
• Compact size increases installation options.
w w w . s o n a n c e . c o m
212 Avenida Fabricante
San Clemente, CA 92672-7531 USA
(800) 582-7777 or (949) 492-7777
FAX: (949) 361-5151
Technical Support: (800) 582-0772
©2004 Sonance, All Rights Reserved. Sonance, Sonance Symphony and RotoLock are trademarks of Sonance. All specifications are subject to change without notice.
Cabinet speaker offers the per-
Cabinet
C
Cabinet speaker brings high-
Sonance Symphony
Symphony S622
Cabinet Speaker

SPECIFICATIONS

Sonance Symphony S622
Tweeter
Woofer
Frequency Response
Impedance
Power Handling
Sensitivity
Baffle & Back Panel Material
Top, Bottom & Side Panel Material
Grille Material
Dimensions (W x H x D)
Shipping Weight
DIMENSIONS
Sonance Symphony
S622 Cabinet Speaker
C
®
Cabinet
C
1" (25mm) Silk dome, Ferrofluid-cooled
6½" (165mm) Polypropylene cone, rubber
surround
45Hz – 20kHz ±3dB
8 Ohms nominal; 6 Ohms minimum
5 watts minimum; 125 Watts maximum
89dB SPL (2.83V 1 meter)
1" MDF
Laminate (½" MDF / ½" particle board)
Black cloth
7½" (310mm) x 11" (206mm) x 11½" (98mm)
18 lbs. (8.2 KG) each
Series
C
0405
