Summary of Contents for Soleus Air SG-WAC-06ESE
-
Page 3: Important Safety Instructions
Thank you for choosing a Soleus Air powered by Gree Air Conditioner. This owner’s manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new air conditioner. -
Page 4: Electrical Requirements
Recommended Ground Method For your personal safety, this air conditioner must be grounded. This air conditioner is equipped with a 3 prong power supply cord with a grounded plug. To minimize the possibility of electrical shock, the cord must be plugged into a 3 prong outlet and grounded in accordance with all local codes and ordinances. -
Page 5: Packing List
PACKING LIST Packing List: • Window Air Conditioner • Remote Control • AAA Batteries (2) • Top Mounting Rail • Top Mounting Rail Seal Strip • 2/5” Screw for Top Mounting Rail (4) • Accordion Panels (Left & Right) 2/5”... -
Page 6: Specifications
Design Pressure (PSIG) (H/L) Dimensions (W” x H” x D”) Package Dimensions (W” x H” x D”) Net/Gross Weight (Lbs) Refrigerant Type Refrigerant Charge (Oz) SG-WAC-06SE SG-WAC-06ESE 1/115/60Hz 31.2 6,000 56/61 18.59 x 12.75 x 15.72 18.59 x 12.75 x 15.72 21.84 x 14.19 x 17.91... - Page 7 INSTALLATION & ASSEMBLY INSTRUCTIONS Some assembly is required for your new air conditioner. Please read and follow these instructions carefully. 1. This air conditioner is designed to be installed in a standard double-hung window with a window width between 21” and 38” .
-
Page 8: Storm Window Requirements
FIG. 2). Do this for both panels. FIG. 2 4. Slide the free end of the accordion panel into the side panel of the air conditioner (See FIG. 3). Do this for each side. 5. Once the accordion panels are slid into place adjust the top and bottom rails of the accordion panels into the top and bottom rails of the air conditioner (See FIG. - Page 9 4. Close (slide) the side panels into frame. 5. Keeping a firm grip on air conditioner, raise the sash and carefully “rock” air conditioner backward to drain any condensate water in base of unit. Be careful not to spill any remaining water while lifting unit from window.
-
Page 10: Using Your Air Conditioner
Increase Fan Speed Saver, and Fan only. Power Button 7. Auto-on Timer: When the air conditioner is off, it can be set to automatically turn on in 1-24 hours at the previous set mode and fan setting. To set the Auto-on Timer, press the DELAY button on the unit or remote control. - Page 11 Mode to Cool and the Fan to Low with the temperature set in the middle. NOTE: If the air conditioner is off and is then turned on while set to a Cool setting or if turned from a fan setting to a Cool setting, it may take approximately 3 minutes for the compressor to start and cooling to begin.
-
Page 12: Care And Cleaning
Winter Storage To store the air conditioner when it is not in use for an extended period of time, remove it care- fully from the window according to the installation... -
Page 13: Troubleshooting
TROUBLESHOOTING PROBLEM The Air Conditioner will not start The Air Conditioner does not cool as it should The Air Conditioner is freezing up The Remote Control is not working POSSIBLE CAUSES The air conditioner is unplugged The fuse is blown/circuit breaker is tripped. - Page 14 Water is dripping outside Water is dripping inside the room Water collects in the base pan POSSIBLE CAUSES Hot and Humid weather. The air conditioner is not correctly tilted outside. Moisture removed from the air is draining into the base pan. SOLUTIONS •...
-
Page 15: Warranty
One Year Limited Warranty Soleus International, Inc. warrants the accompanying Soleus Air Powered by Gree Air Conditioner to be free of defects in material and workmanship for the applications specified in its operation instruction for a period of ONE (1) year from the date of original retail purchase in the United States. - Page 16 66129903754...
