Snell AMC 830 Specification Sheet

SNELL'S 3rd GENERATION IN-WALL LCR, A ZERO COMPROMISE
MUSIC AND THEATER MONITOR.
In 1990, Snell built the world's first fully enclosed in-wall LCR. Like better
freestanding monitor's it had accurate, predictable bass, pinpoint imag-
ing, detail, and startling dynamics. Unlike all open-backed in-walls it
minimized sound leakage to adjacent rooms, and was a very competent
alternative to bulky, obtrusive in-room speakers... and it smoked. Two
generations later, Snell's chief engineer, Joe D'Appolito reconfigured the
800 Series to feature the his famous D'Appolito Array. The Snell AMC 830
borrows the 5 1⁄4 D'Appolito Array from its in-room brother, the LCR7,
which includes two very long excursion woofers mounted over and under a
low resonance 1-inch silk dome tweeter. The result is a design which aligns
the output from all three drivers to a single point, for remarkable clarity
and soundstage. Other features include Snell's three-layer baffle for re-
duced wall resonance, and high order crossover for reliable hi-output use.
Like all Snell speakers the AMC 830 is hand-tuned to match its reference
master by .5dB.
AMC 830
Design Infinite Baffle, Back-Boxed, "D'Appolito" In-Wall LCR
Frequency Response 70Hz-20kHz+3dB
Sensitivity 89dB
Nominal Impedance 4 Ohms
Crossover Frequency 2kHz
Recommended Amplifier Power 50-250 Watts
Maximum Output (per pair) 110dB
Placement 2" x 4" Stud Wall or Ceiling
Drive Units Tweeter:
Woofer:
Input Connection Spring Loaded, Push Post, Accepts 12 Gauge Wire
Dimensions Finish: Height:
Width:
Depth:
Rough Opening: Height:
Width:
Mounting System 8 "dog-Leg" clamps
Finishes Cabinet: White
Grille: White, Perforated Metal 53% Open
Manufactured by Snell Acoustics, PO 3717, Peabody MA 01960
www.snellacoustics.com
1-inch SEAS Silk Dome
Two 5.25-inch Poly, 5mm Excursion
23.25-inches
13.25-inches
3.75-inches
22-inches
12-inches
978-538-6262 978-538-6266fax
AMC Series
AMC 830
