OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
This manual provides information for:
MODELS TD/FPC
BRAISING PAN
· Stainless Steel
· Table Top Mounted
· Manual Tilting
· Electrically Heated
· 40 Quart Capacity
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND
WARNINGS CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
POST IN A PROMINENT LOCATION
Instructions to be followed in the event user smells
gas. This information shall be obtained by consulting
your local gas supplier. As a minimum, turn off the gas
and call your gas company and your authorized service
agent. Evacuate all personnel from the area.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this
equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE
It is the responsibility of the consignee to inspect the container upon receipt of
same and to determine the possibility of any damage, including concealed dam-
age. Unified Brands suggests that if you are suspicious of damage to make a
notation on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
PART NUMBER 121066, REV. D (04/11)
Domestic
1055 Mendell Davis Drive
Jackson, MS 39272
888-994-7636, fax 888-864-7636
unifiedbrands.net
Advertisement
Table of Contents
Related Manuals for Groen OM-BTD
Summary of Contents for Groen OM-BTD
- Page 1 OPERATOR MANUAL IMPORTANT INFORMATION, KEEP FOR OPERATOR This manual provides information for: MODELS TD/FPC Domestic BRAISING PAN · Stainless Steel · Table Top Mounted · Manual Tilting · Electrically Heated · 40 Quart Capacity THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL.
-
Page 2: Important Operator Warnings
IMPORTANT - READ FIRST - IMPORTANT CAUTION: BE SURE OPERATORS READ, UNDERSTAND AND FOLLOW THE OPERATING INSTRUCTIONS, CAUTIONS, AND SAFETY INSTRUCTIONS IN THIS MANUAL. WARNING: THIS UNIT IS INTENDED FOR USE IN THE COMMERCIAL HEATING, COOKING AND HOLDING OF WATER AND FOOD PRODUCTS, PER THE INSTRUCTIONS CONTAINED IN THIS MANUAL. ANY OTHER USE COULD RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT AND WILL VOID WARRANTY. - Page 3 CAUTION: NEVER LEAVE A CHLORINE SANITIZER IN CONTACT WITH STAINLESS STEEL FOR LONGER THAN 30 MINUTES. LONGER CONTACT CAN CAUSE CORROSION. WARNING: DO NOT USE ANY FUSE WITH A HIGHER AMP RATING THAN THE RATING SPECIFIED FOR THAT CIRCUIT. OM-BTD/FPC...
-
Page 4: Table Of Contents
Table of Contents Important Operator Warnings ............page 2-3 References..................page 4 Equipment Description..............page 5 Inspection and Unpacking ............page 6 Initial Start-Up................page 7 Operation ..................page 8 Sequence of Operation ............... page 9 Cleaning................... page 10-11 Maintenance................page 11 Troubleshooting................ -
Page 5: Equipment Description
178 mm Base Width 28.5 inches 724 mm Base (front to back) 18 inches 457 mm kW at 208 Volts 5.7 KW kW at 240 Volts 6.0 KW kW at 380 Volts 6.0 KW kW at 480 Volts 6.0 KW OM-BTD/FPC... -
Page 6: Inspection And Unpacking
Installation WARNING Internal wiring for the Braising Pan is supplied complete. When you receive the unit, it THE BRAISING PAN MUST BE INSTALLED is ready for connection. A wiring diagram is located inside the console on the side of BY PERSONNEL WHO ARE QUALIFIED TO the pan, as well as in this manual. -
Page 7: Initial Start-Up
Heating should continue until the water boils. To shut the unit down, turn the thermostat dial to “OFF.” Position a container for the pour-off. Turn the handwheel clockwise to pour the water out. This will confirm that the pan body tilts from horizontal to vertical. OM-BTD/FPC... -
Page 8: Operation
Operation WARNING The operator controls braising pan operation with the thermostat dial, which is located DO NOT HEAT AN EMPTY PAN FOR MORE on the right front of the unit. Setting the dial sends electric power to turn the heaters THAN FIVE MINUTES AT SETTINGS ABOVE on or off and sets the operating temperature of the pan. -
Page 9: Sequence Of Operation
The pan will heat as fast as it can until it reaches the set temperature, no matter what that temperature is. Turning the thermostat dial to a higher setting will only cause heating to continue longer, until the pan reaches the higher temperature. It will not make the pan heat any faster. OM-BTD/FPC... -
Page 10: Cleaning
Cleaning WARNING Suggested Tools BEFORE ANY CLEANING OPERATION, Cleaner, such as Klenzade TURN THERMOSTAT DIAL TO “OFF” TO Brushes in good condition CUT ANY POWER TO THE HEATING Cloth for cleaning controls ELEMENTS. BEFORE CLEANING ANY PART Chlorine sanitizer such as Klenzade OTHER THAN THE INSIDE OF THE PAN, Heavy Duty Cleaner, such as Klenzade LC-30 DISCONNECT ELECTRICAL SUPPLY AT... -
Page 11: Maintenance
WARRANTIES. SERVICE PERFORMED BY OTHER enter the date on which it was done, what was done, and who did it. THAN FACTORY-AUTHORIZED PERSONNEL WILL VOID ALL WARRANTIES. WARNING ELECTRICAL POWER MUST BE SHUT OFF BEFORE WORK IS DONE ON INTERNAL COMPONENTS. OM-BTD/FPC... -
Page 12: Troubleshooting
Troubleshooting Your Braising Pan will operate smoothly and efficiently if properly maintained. However, the following is a list of checks to make in the event of a problem. If the actions suggested do not solve the problem, call your authorized Service Representative. For the phone number of the nearest agency, call your area representative or the Parts and Service Department. - Page 13 Light, Indicator, 016028 208 & 240 Volt Light, Indicator, 480 Volt 002986 Block, Pillow, 1-1/2” ID 002989 Collar, Set 1-1/2” ID 003118 Washer, Plain. 1/2” 002213 Tilt Detent Assembly 002970 Nut, Cap, 3/8-24 003188 Washer, Lock, 3/8 005618 Handle 012694 OM-BTD/FPC...
- Page 14 Electrical Parts CONTACTOR HEATER INDICATOR LIGHT TRANSFORMER MODEL Part No. Part No. Part No. Part No. 208 V/1 Ph 9178 12842 16028 None 208 V/3 Ph 9210 12842 16028 None 240 V/1 Ph 9178 12843 16028 None 240 V/3 Ph 9210 12843 16028...
-
Page 15: Wiring Diagram
Wiring Diagram OM-BTD/FPC... -
Page 16: Wiring Diagram
Wiring Diagram OM-TD/FPC... -
Page 17: Service Log
Service Log Model No: Purchased From: Serial No: Location: Date Purchased: Date Installed: Purchase Order No: For Service Call: Date Maintenance Performed Performed By OM-BTD/FPC... -
Page 18: Service Log
Service Log Model No: Purchased From: Serial No: Location: Date Purchased: Date Installed: Purchase Order No: For Service Call: Date Maintenance Performed Performed By OM-TD/FPC... - Page 19 OM-BTD/FPC...
- Page 20 1055 Mendell Davis Drive • Jackson MS 39272 888-994-7636 • 601-372-3903 • Fax 888-864-7636 unifiedbrands.net PART NUMBER 121066, REV. D (04/11) © 2011 Unified Brands. All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
