Snapper 13388E Parts Manual

Snapper 13388E Parts Manual

Two stage large frame series 8 snow thrower pro
Hide thumbs Also See for 13388E:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
Parts Manual for
TWO STAGE LARGE FRAME
SNOW THROWER PRO
SERIES 8
MODEL
13388E
E13388E
McDonough, GA, 30253 U.S.A.
Briggs & Startton Yard Power Products Group
Manual No.
7006160
Copyright ©
2006
Briggs & Startton Corporation
Milwaukee, WI USA. All Rights Reserved
Revision IR,
12/4/2006
TP 400-5246-IR-LF-N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 13388E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snapper 13388E

Summary of Contents for Snapper 13388E

  • Page 1 Parts Manual for TWO STAGE LARGE FRAME SNOW THROWER PRO SERIES 8 MODEL 13388E E13388E McDonough, GA, 30253 U.S.A. Briggs & Startton Yard Power Products Group Manual No. 7006160 Copyright © 2006 Briggs & Startton Corporation Milwaukee, WI USA. All Rights Reserved...

  • Page 3: Table Of Contents

    PAGE GROUP Handle & Controls Group Auger Drive Group Gear Box Assembly Auger Housing & Chute Group Engine & Frame Group Traction Drive Group Wheels & Tires Group Decal Group TWO STAGE LARGE FRAME SERIES 8 Table Of Contents Manual No. 7006160 TP 400-5246-IR-LF-N...

  • Page 4: Handle & Controls Group

    Handle & Controls Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...
  • Page 5 Handle & Controls Group Item Part No Description 1960729 SCREW, Hex Head Serrated Flange Taptite, 5/16-18 x 1 1960730 SCREW, Hex Head Serrated Flange Taptite, 5/16-18 x 2 1931317 CARRIAGE BOLT, 1/4-20 x 3/4, G5 1726832 CABLE & SPRING ASSEMBLY 1731333A HANDLE, Tube L.H.
  • Page 6 Handle & Controls Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...
  • Page 7 Handle & Controls Group Item Part No Description 1731334A HANDLE, Tube R.H. 2006 Snow 1921221 CAPSCREW, Hex Head, 5/16-18 x 1-1/2, G5 1722460 PIN, Quick 1726304 ROD, 3/8 DIA 11.38 LG 1960686 NUT, Hex Flange, 5/16-18 ESNA 1666255 ROD, Shift Lower 1728968 HARNESS, Hand Warmers/Spout Snow 2006 1923358...

  • Page 8: Auger Drive Group

    Auger Drive Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...

  • Page 9: Auger Drive Group

    Auger Drive Group Item Part No Description 1731321A AUGER ASSEMBLY, 38” Housing, R.H. 1731322A AUGER ASSEMBLY, 38” Housing, L.H. 1931333 CARRIAGE BOLT, 5/16-18 x 3/4, G5 1931277 NUT, Hex Whiz Lock Flange, 5/16-18 1732303 GEAR BOX ASSEMBLY 2818312 KEY, Woodruff, 3/16 x 5/8 #61 SAE 1035 1612187A IMPELLER ASSEMBLY, Large Frame Snow 1960474...
  • Page 10 Gear Box Assembly Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...

  • Page 11: Gear Box Assembly

    Gear Box Assembly Item Part No Description 1923282 CAPSCREW, 1/4-20 x 2-1/2 1960346 CAPSCREW, 1/4-20 x 2-1/4 1612136 GEAR CASE, L.H. 1668971 TAPERED PIPE PLUG 1612124 GASKET 1732440 SHAFT, Auger Cutoff 1732182 SHAFT, Worm Cutoff 1612093 SEAL, Oil 1612149 FLANGE BUSHING 2836098 PIN, Drive Lock 1612127...

  • Page 12: Auger Housing & Chute Group

    Auger Housing & Chute Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...

  • Page 13: Housing Assembly

    Auger Housing & Chute Group Item Part No Description 1732271D HOUSING ASSEMBLY, 38” 1723921A BLADE, Scraper 38” 1931333 CARRIAGE BOLT, 5/16-18 x 3/4, G5 1935048 NUT, Hex Lock Flange, 5/16-18 1960699 CARRIAGE BOLT, 5/16-18 x 5/8, G5 1733599 DECAL, Red Strip 1725747A SKID SHOE 1960702...
  • Page 14 Auger Housing & Chute Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...
  • Page 15 Auger Housing & Chute Group Item Part No Description 1925205 CAPSCREW, Hex Head, 5/16-18 x 5/8, G5 1733105 BEARING, Ball, 1.002 ID 2.049 OD 1.09 LG 1931277 NUT, Hex Whiz Lock Flange, 5/16-18, 1733209 STICK, Cleanout w/Brush, Snow 722242 CLIP, Retainer 1933896 NUT, Hex Lock, 10-24 with Nylon Insert 724565...

  • Page 16: Engine & Frame Group

    Engine & Frame Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...

  • Page 17: Frame Assembly

    Engine & Frame Group Item Part No Description 1922128 CAPSCREW, Hex Head 3/8-24 x 1-1/2, G8 1916965 LOCKWASHER, Spring 3/8 1922755 WASHER, 3/8, .41 ID x 1 OD x .13 THK 1726867 PULLEY, Engine Outside 1726866 PULLEY, Engine Middle 1726865 PULLEY, Engine Inside 1921515 CAPSCREW, Hex Head 5/16-24 x 3/4, G5...
  • Page 18 Engine & Frame Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...
  • Page 19 Engine & Frame Group Item Part No Description 1725664A GUARD, Muffler 1665994 PIN, Flat Head Drilled 1727149 SPRING, Extension L.F. 1929477 SCREW, Hex Taptite, 10-24 x 1/2 1927557 NUT, Hex Whiz Lock Flange, 5/16-18 1724064 CORD, Electric Extension 1672732 V-BELT, 3L 31.00 (Drive) 1666655 V-BELT, HA 41.3 (Auger) 1928731...

  • Page 20: Traction Drive Group

    Traction Drive Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...
  • Page 21 Traction Drive Group Item Part No Description 1930601 SCREW, Hex Washer Head Taptite, 5/16-18 x 5/8 1667341 RETAINER, Bearing 1705897 BEARING, Ball 1726856 SHAFT, Hex 1921332 CAPSCREW, Hex Head, 5/16-18 x 3/4, G5 1725428 DISC, Friction with Insert 1665995 HUB, Friction Disc 1960684 NUT, Hex Keps, 5/16-18, Conical Washer 1960687...
  • Page 22 Traction Drive Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...
  • Page 23 Traction Drive Group Item Part No Description 1726467 ROD, Pivot, 9-15/100 LG 1722460 PIN, Quick 1725666 SPRING, Extension 1719879 DRIVE DISC with SPINDLE 2818312 KEY, Woodruff, 47/250 x 5/8 1924366 WASHER, 5/8 1670849 ARM, Pivot with Bushings & Bearings 1665521 BEARING, Ball 1666425 BUSHING, 3/4 ID x 1 OD x 3/4 LG, Powdered Metal...

  • Page 24: Wheels & Tires Group

    Wheels & Tires Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...
  • Page 25 Wheels & Tires Group Item Part No Description 1731186 PIN, Klik Ring 1726745 WHEEL & TIRE ASSEMBLY, Snow R.H. 2172353 VALVE STEM & CAP ASSEMBLY, Air 1722762 HUB, Wheel, 5-3/8 Wide 8 Diameter 3/4 ID 1727075 TIRE, 16 x 6.5-8 X-TRAC TL 1726744 WHEEL &...

  • Page 26: Decal Group

    Decal Group Manual No. 7006160 TWO STAGE LARGE FRAME TP 400-5246-IR-LF-N SERIES 8...

  • Page 27: Decal Group

    1722867 DECAL, Lubrication 1727208 DECAL, Danger Avoid Injury from Auger 1716532 DECAL, Danger Avoid Injury from Auger 1733075 DECAL, Stripe Snapper Professional 38” 1722674 DECAL, Danger Auger, Use Snow Stick 7071880 DECAL, Danger Auger, Use Snow Stick 1731389 MYLAR OVERLAY...
  • Page 30 Parts Manual for TWO STAGE LARGE FRAME SNOW THROWER PRO SERIES 8 IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs &...

This manual is also suitable for:

E13388e
