- Page 1 Parts Manual for 21" CAST DECK WALK BEHIND MOWER COMMERCIAL EUROPEAN SERIES 2 MODEL ECLP21602KWV McDonough, GA, 30253 U.S.A. COPYRIGHT © 2005 Manual No. 7006203 SNAPPER PRODUCTS, INC. Revision 1, 8/11/2005 TP 400-5061-1-WB-N ALL RIGHTS RESERVED.
-
Page 3: Table Of Contents
PAGE GROUP HANDLES & CONTROLS ENGINE, CUTTING DECK, BLADE WHEELS, FRONT & REAR TRANSMISSION DECALS ACCESSORIES 21" CAST DECK WALK BEHIND MOWER SERIES 2 Table Of Contents Manual No. 7006203 TP 400-5061-1-WB-N... -
Page 4: Handles & Controls
HANDLES & CONTROLS Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2... - Page 5 HANDLES & CONTROLS Item Part No Description 7074411 HANDLE, Upper 7074156 HANDLE, Middle 7034864 BRACKET, Handle 7073821 COTTER PIN, Bow Tie Locking 7074418 BAIL, OPC Control 7034872 CLIP, Zone Control 7074141 CABLE, Zone Control 7046520 ASSEMBLY, Handle Clutch 7028407 GRIP, International Symbol 7046518 CABLE, Clutch (Adjustable) 7026219...
- Page 6 HANDLES & CONTROLS Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2...
- Page 7 HANDLES & CONTROLS Item Part No Description 7091020 PUSHNUT, 1/4” Footnotes: 21" CAST DECK WALK BEHIND MOWER SERIES 2 Note Manual No. 7006203 TP 400-5061-1-WB-N...
-
Page 8: Engine, Cutting Deck, Blade
ENGINE, CUTTING DECK, BLADE Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2... - Page 9 ENGINE, CUTTING DECK, BLADE Item Part No Description 7052881 ASSEMBLY, Discharge Door 7072143 BELT GUIDE (Wireform) 7091088 SCREW, 3/8-16 x 2” Hex Head Self-Tap 7091696 SCREW, 1/4-20 x 5/8” Phillips Truss Head Machine *ENGINE, 6.0 H.P. Kawasaki OHV, Euro 7043888 DECK, 21”...
- Page 10 ENGINE, CUTTING DECK, BLADE Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2...
- Page 11 ENGINE, CUTTING DECK, BLADE Item Part No Description 7091267 NUT, #10-24 Hex Center Lock 7091294 WASHER, .28 x .63 x .06 Flat 7043870 SHIELD, Trailing, Commercial Cast Footnotes: *NOTE: Purchase engine components directly from engine manufacturer dealer. 21" CAST DECK WALK BEHIND MOWER SERIES 2 Note was 90055...
-
Page 12: Wheels, Front & Rear
WHEELS, FRONT & REAR Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2... - Page 13 WHEELS, FRONT & REAR Item Part No Description 7029492 BELT, Traction Drive, Sect. 3L, 33.20” effective length 7074630 WHEEL, 9.0 x 2.0 (Rear Drive) 7073618 BUSHING, Wheel (PM) 7091593 COTTER PIN, 3/8” Self Locking 7041744 WELDMENT, Tie Bar 7091598 COTTER PIN, 1/8 x 3/4” 7024751 SPRING, Tie Bar 7024558...
-
Page 14: Transmission
TRANSMISSION Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2... - Page 15 TRANSMISSION Item Part No Description 7074221 AXLE/TRANSMISSION ASSY (Incl. items 2-19 & 24-28) 7028813 TRANSMISSION ASSY, 3SP Commercial 7041738 WELDMENT, Rear Axle 7024573 SHIELD, Dust 7024749 PAWL, 3/16” O.D. 7024549 PINION, RH Drive 7024550 PINION, LH Drive 7014341 RING, External Retaining 7026479 SEAL, Pinion (Felt) 7026478...
-
Page 16: Decals
DECALS Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2... - Page 17 DECALS Item Part No Description 7075618 DECAL, SNAPPER 7072921 DECAL, Warning (Deck) 7013010 DECAL, Danger (Keep Hands and Feet Away) 7022841 DECAL, Warning (International Symbol) 7029366 DECAL, Commercial, Walk-Behind Mower 7046924 DECAL, Chute Deflector (Cast) 7029784 DECAL, Chute/International Warning 7046357...
-
Page 18: Accessories
ACCESSORIES Manual No. 7006203 21" CAST DECK WALK BEHIND MOWER TP 400-5061-1-WB-N SERIES 2... - Page 19 ACCESSORIES Item Part No Description 7028445 GRASS BAG, SNAPPER Platinum Series 49915 ASSEMBLY, Catcher Frame 7026421 GRIP, Rectangular (Black) 7026390 PLUG, Mulching 7026714 CHUTE, Side Discharge (incl. WARNING Decal, p/n 13010) Footnotes: 21" CAST DECK WALK BEHIND MOWER SERIES 2...
- Page 22 21" CAST DECK WALK BEHIND MOWER COMMERCIAL EUROPEAN SERIES 2 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
