Safety Instructions, Installation & Operator's Manual For

# 6-3162 BLOWER KIT for

COMMERCIAL GRASS CATCHERS

for MID MOUNT Z-RIDERS

SNAPPER INC.

MANUAL No. 7-3571 (Rev. 1, 7/28/00)

Table of Contents

Need help?

Do you have a question about the 6-3162 and is the answer not in the manual?

Questions and answers

Summary of Contents for Snapper 6-3162

Page 1 Safety Instructions, Installation & Operator’s Manual For # 6-3162 BLOWER KIT for COMMERCIAL GRASS CATCHERS for MID MOUNT Z-RIDERS COPYRIGHT © 2000 SNAPPER INC. ALL RIGHTS RESERVED MANUAL No. 7-3571 (Rev. 1, 7/28/00)
Page 2: Important Safety Instructions
If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-935-2967).
Page 3: Operation
Only use accessories attachments SNAPPER. 8. Keep people and pets out of mowing area. Immediately, STOP blades, STOP engine, and STOP machine if anyone enters the area. 9. DO NOT operate machine unless all shields,...
Page 4: Important Safety Instructions
15. Have machine serviced SNAPPER dealer at least once a year and have the dealer install any new safety devices. Never allow untrained personnel to service machine. 16. Use only genuine SNAPPER replacement parts to assure that original standards are maintained.
Page 5: Decals
DECALS NEW DECAL _-_____ 24773...
Page 6: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ... 2-4 DECALS ... 5 TABLE OF CONTENTS ... 6 SECTION 1 - INSTALLATION... 7-10 SECTION 2 - PARTS IDENTIFICATION... 11-15 WARRANTY... 16...
Page 7: Section 1 - Installation
SECTION 1 – INSTALLATION INTRODUCTION This section covers installation Commercial Grass Catcher Blower Kit for Snapper Mid Mount Z-Rider mowers. FAMILIARIZE YOURSELF WITH THIS PRODUCT BEFORE INSTALLATION. Sections ILLUSTRATIONS and PARTS LISTS. Study these pages. Become familiar with the parts, their method of assembly, and also, their location.
Page 8 SECTION 1 – INSTALLATION D. Install the discharge adapter. See Figure 1.3. SECURE WITH COTTER PIN HOOK FASTEN HOOK OVER LIP ON DECK. PUSH DOWN TO SECURE IN PLACE. FIGURE 1.3 1.3 BLADE INSTALLATION - 61” DECKS ONLY NOTE: Blade Part No. 2-9251 is included in Adapter Kit Part No.
Page 9 SECTION 1 – INSTALLATION WARNING DO NOT attempt any adjustments, maintenance, repairs, service, and unclogging grass tube or deck adapter with the engine running. STOP engine. STOP blade. Engage parking brake. Remove key from ignition switch. Remove spark plug wire(s) and secure wire(s) away from spark plug(s).
Page 10 SECTION 1 - INSTALLATION 1.5 MOUNTING THE BLOWER SUPPORT ASSEMBLY 1. Place blower support assembly into position on the right rear corner of the frame. 2. Align the blower support assembly with the four (4) holes in the side of the frame and secure with four (4) 5/16-18 x 3/4”...
Page 11: Section 2 - Parts Identification
SECTION 2 – PARTS IDENTIFICATION CONTENTS ITEM PAGE NO. Blower, Idler, Adapter & Blade Assemblies ...12-13 Blower Assembly ...14-15...
Page 12 BLOWER, IDLER, ADAPTER & BLADE ASSEMBLIES (SEE PAGES 13 & 14 FOR PARTS BREAKDOWN) BLOWER KIT...
Page 13 BLOWER, IDLER, ADAPTER & BLADE ASSEMBLIES ITEM PART NO. 5-7704 1-3010 9-1298 5-8583 5-7717 4-2622 1-4409 3-5816 9-1598 9-1804 9-1518 9-1553 9-1299 1-3324 3-5713 1-9078 4-6249 7-2738 4-6248 *19A 4-6247 *19B 7-3170 *20A 6-3076 *20B 6-3077 9-0550 9-1947 2-9251 2-4773 5-8583 9-1514 2-2522...
Page 14: Blower Assembly
BLOWER ASSEMBLY BLOWER KIT...
Page 15 BLOWER ASSEMBLY ITEM PART NO. 4-1990 4-2867 4-4893 4-4924 5-7733 4-6215 4-6393 5-7734 7-9944 9-0160 9-1298 9-1299 9-1320 9-1328 9-1331 9-1508 9-1802 9-1803 9-1823 2-4773 2-2522 BLOWER KIT DESCRIPTION MOUNT, Grass Catcher Gearbox, MMZ/OFZ PULLEY, 5.45 O.D. Cast WELDMENT, Blower Impeller WELDMENT, Chute Adapter WELDMENT, Impeller Housing Front (Includes Item 21) GEARBOX, Right Angle...
Page 16: Warranty
For one (1) year from purchase date for the original purchaser's use, SNAPPER, through any authorized SNAPPER dealer will replace, free of charge (except for taxes where applicable), any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both.
