- Page 1 HOME APPLIANCES Deluxe Wine Cooler 4.6 Cu. Ft. Use & Care Instructions Read All Instructions Carefully. Save These Instructions.
-
Page 2: Table Of Contents
Table of Contents Product Introduction ............. 2 Installation ................3-8 Cleaning and Maintenance ........... 8 LED Light Replacement ............9 Troubleshooting ..............10 Safety Warnings ..............11 Customer Service ..............11 Product Warranty ..............12 Model #80901/103... -
Page 3: Product Introduction
PRODUCT INTRODUCTION Adjustable Electronic Thermostat with Digital Display LED Light and Power Control LED Interior Light Adjustable Wood Shelves Double Wood Shelf Adjustable Front Leveling Legs Double Pane Glass Door with Stainless Steel Frame Stainless Steel Handle - 2 -... -
Page 4: Installation
INSTALLATION STOP! BEFORE YOU DO ANYTHING! Do not plug the wine cooler into a power outlet until it has been resting in its upright position for at least six (6) hours. If the wine cooler has been laid on its side, placed upside down or tilted more than 45°... - Page 5 INSTALLATION POWER SUPPLY This wine cooler is equipped with a 115V/60Hz single phase motor. If the power supply to the unit is subject to large fluctuations, it is strongly advised to utilize a wall-mounted power conditioner surge protection device to prevent damage to the electronic components and motor. The power plug is a standard grounded three-prong non-polarized flush mount, which allows for easier connection to power outlets.
- Page 6 INSTALLATION HANDLE INSTALLATION IMPORTANT: NEVER LAY THE WINE COOLER ON ITS BACK. The compressor and motor components are installed at the back of the unit and may easily be damaged if the wine cooler is placed on its back. IMPORTANT: DO NOT USE STAINLESS STEEL HANDLE TO MOVE OR LIFT THE UNIT. Locate the two mounting studs protruding from the Align the stainless steel handle door handle with the exterior stainless steel door frame.
- Page 7 INSTALLATION USING YOUR WINE COOLER The wine cooler is designed for the storage of wine. After connecting the wine cooler to a wall outlet, you will immediately hear a short beep. ∧ ∨ Use the buttons to set the set the desired temperature. Fahrenheit range: 33º...
- Page 8 INSTALLATION STOCKING YOUR WINE COOLER The wine cooler accommodates 45 standard wine bottles. To accommodate all 45 bottles, position the wood shelves and stock the wine as illustrated below. Due to air circulation, temperatures may vary slightly within the cooler. Typically, the upper shelves may exhibit warmer temperatures, while the lower shelves exhibit cooler temperatures.
-
Page 9: Cleaning And Maintenance
INSTALLATION SHUTDOWN If the wine cooler will not be in use for a long period of time, disconnect it from the power outlet, clean inside thoroughly and leave the door open to prevent mildew. SAFETY WARNING The appliance is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the appliance. -
Page 10: Led Light Replacement
If the LED light is not illuminating, the light most likely needs to be replaced. LED Light A replacement LED light may be purchased from Tramontina by calling Tramontina’s Customer Service Department (800-221-7809). NOTE: The replacement light is NOT available from home improvement, hardware or discount stores. -
Page 11: Troubleshooting
• Do not overload the wine cooler. • Do not put hot beverages in the wine cooler. E or F is showing in the display. • Contact Tramontina’s Customer Service Department for assistance. Flashing H within the display and • Temperature in the cooler is too high. Press any key emitting buzzer alarm. -
Page 12: Safety Warnings
In the unlikely event this item is damaged or missing parts, please do not return it to the store. Instead, please contact our customer service department listed below for assistance so we can work quickly and efficiently to resolve product issues. TRAMONTINA USA, Inc. Customer Service 12955 West Airport Blvd. -
Page 13: Product Warranty
Sugar Land, TX 77478-6119 (800) 221-7809 www.tramontina-usa.com For faster assistance, please register your product online at www.tramontina-usa.com MADE IN CHINA ©COPYRIGHT 2015, TRAMONTINA USA, Inc. TRAMONTINA® is Reg. U.S. Pat & TM Off. Packaging Designed by TDS (BR.80901/503-052015). - 12 -... - Page 14 Product & Warranty Registration Card Thank you for purchasing this Tramontina product. We appreciate you taking a few minutes to complete this card and mailing it back to us, or registering online for faster assistance. The information we receive will help us develop new products and services to meet your expectations.
- Page 15 PLEASE PLACE STAMP HERE POST OFFICE WILL NOT MAIL WITHOUT POSTAGE TRAMONTINA USA, Inc. 12955 West Airport Blvd. Sugar Land, Texas 77478-6119 Fold Here Use tape to seal card...
