Parts Manual for
YARD TRACTOR ELECTRIC CLUTCH
HYDRO 4WD RMO
YT400 Series
MODEL
YT2350 4WD (2690765)
Briggs & Stratton Yard Power Products Group
535 Macon Road
Manual No.
7006273
McDonough, GA, 30253 U.S.A.
800-935-2967
Revision IR,
9/16/2008
TP 400-5416-IR-TC-N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YT2350 4WD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snapper YT2350 4WD

Summary of Contents for Snapper YT2350 4WD

  • Page 1 Parts Manual for YARD TRACTOR ELECTRIC CLUTCH HYDRO 4WD RMO YT400 Series MODEL YT2350 4WD (2690765) Briggs & Stratton Yard Power Products Group 535 Macon Road Manual No. 7006273 McDonough, GA, 30253 U.S.A. 800-935-2967 Revision IR, 9/16/2008 TP 400-5416-IR-TC-N...

  • Page 3: Table Of Contents

    PAGE GROUP Wheels & Tires Group Steering Group - Power Steering Steering Group - Power Steering Hood, Grille & Dash Group Seat & Seat Deck Group Frame & Front Axle Group - 4WD Controls Group Cruise Control Group Transmission Group Engine Group - 23HP Briggs &...
  • Page 4 Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 5: Wheels & Tires Group

    Wheels & Tires Group Item Part No Description 1735010 WHEEL & TIRE ASSEMBLY, Front 1735706 TIRE, 16 x 6-1/2 - 8 2153038 TUBE, Tire 1722834 WHEEL ASSEMBLY 2172353 VALVE STEM & CAP ASSEMBLY 2860202 WASHER, Flat 3/4 x 1-5/8 x 1/8 1722717 WASHER, Flat 1960114...

  • Page 6: Steering Group - Power Steering

    Steering Group - Power Steering Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 7: Steering Wheel

    Steering Group - Power Steering Item Part No Description 1733363 STEERING WHEEL 1724685A PLATE, Steering Mounting 1960655 CARRIAGE BOLT, 5/16-18 x 1-1/4 G5 1725294 ADAPTER, Tilt 1723898 SPACER 1933988 NUT, Push Pal 1960636 NUT, Hex Keps 5/16-18 1733790 STEERING UNIT, Tilt 1686970 BELLOWS, Tilt Steering Unit w/Slot 1725024...
  • Page 8 Steering Group - Power Steering Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 9: Steering Group - Power Steering

    Steering Group - Power Steering Item Part No Description 1733894 POWER STEERING, 4 Ports, 4WD 1916964 LOCKWASHER, Spring 1/4 2860444 CAPSCREW, Hex Hd, M06-1 x 16mm 1722138 TUBE, Hydraulic 2825094 TIE, Wire 1733727 TUBE-Hydraulic 1931646 SCREW, Whiz Lock, 1/4-20 x 1/2 1722123 FITTING, Straight 1719168...

  • Page 10: Hood, Grille & Dash Group

    Hood, Grille & Dash Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 11 Hood, Grille & Dash Group Item Part No Description 1728031D HOOD, W/Scoop 1721804D PANEL, R.H. Side 1721803D PANEL, L.H. Side 1721810 HEADLIGHT ASSEMBLY 1721802D GRILLE 1930641 NUT, Hex Flange 1/4-20 Whiz Lock 1726827 DASHBOARD 1726894 DASHBOARD, W/Hydraulic Lift Slot 1721808A HINGE, Hood L.H.

  • Page 12: Seat & Seat Deck Group

    Seat & Seat Deck Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 13 Seat & Seat Deck Group Item Part No Description 1722129A BRACKET, 1-5/8 x 1-3/4 1722307 SEAT, 18” Back 1722128A SUPPORT, Seat 2172434 CLIP, Wire 1709256A WASHER, Spring, 5/16 x 1-1/4 1714263 SPRING, Compression 1919438 NUT, Hex Lock, ESNA Light, 5/16-18 1717051 SPRING, Compression 1930591...

  • Page 14: Frame & Front Axle Group - 4Wd

    Frame & Front Axle Group - 4WD Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 15 Frame & Front Axle Group - 4WD Item Part No Description 1735085A FRAME ASSEMBLY, Front & Rear 4WD 1733139A TOWER & SUPPORT ASSEMBLY 1723528A SUPPORT, Seat Deck 1733918A BRACKET ASSEMBLY, Steering 4WD 1721805A BUMPER, 4GA 1736007 AXLE ASSEMBLY, Front 1734241A PIVOT ASSEMBLY, Axle w/Bushings 1960755 CAPSCREW, Hex Head, 5/8-11 x 2-1/2 G5...
  • Page 16 Frame & Front Axle Group - 4WD Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 17 Frame & Front Axle Group - 4WD Item Part No Description 1733402 FITTING, Bulkhead Union 13/16-16 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 G5 1960636 NUT, Hex KEPS, 5/16-18 1733947 NUT, Jam 13/16-16 1960103 WASHER, 3/8 1931355 CARRIAGE BOLT, 3/8-16 x 2-1/4 G5 1733044A SUPPORT, Steering Unit 7GA 1924856...

  • Page 18: Controls Group

    Controls Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 19 Controls Group Item Part No Description 1721353 ROD, Brake Lock 1721891 KNOB, Push On, Red Plastic “P” 1930591 CAPSCREW, Hex Flange Whiz Lock, 5/16-18 x 3/4 1919326 WASHER, 5/16, Black 1721476 ROD, Brake 1931353 CARRIAGE BOLT, 3/8-16 x 1 3/4 1663114 BUSHING, 5/8 x 3/4 x 3/4, Nylon 2821133...
  • Page 20 Controls Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 21 Controls Group Item Part No Description 1721674 PAD, Foot Pedal Reverse 1920397 NUT, Hex Lock ESNA Light, 1/4-20 1686612 CAM, Roller 1721995 SPRING, Extension Footnotes: YARD TRACTOR ELECTRIC CLUTCH YT400 Series Note Manual No. 7006273 TP 400-5416-IR-TC-N...

  • Page 22: Cruise Control Group

    Cruise Control Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 23 Cruise Control Group Item Part No Description 1722314 COVER, w/Cruise Icon 1960666 SCREW, Torque Head Plus Socket Head, 1/4-20 x 7/8 1722303 KNOB, Cruise 1920397 NUT, Hex Lock ESNA Light, 1/4-20 1722003 LEVER & BRACKET ASSEMBLY, Cruise 1960103 WASHER, 3/8, Black 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 7091587...

  • Page 24: Transmission Group

    Transmission Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 25 Transmission Group Item Part No Description 1733478 TRANSMISSION, K664 4WD 1722194 PULLEY 1719233 1933958 SCREW, Hex Taptite 1/4-20 x 1-1/2 1721392 V-Belt 1721593A STRAP, Torque 1733318A CONTROL ARM, Front 1721424 ROD, Brake 1722684 SPRING, Compression 1729277 SPRING, Compression 1722711 CAP, Tank 1960676 SCREW, Pan Hd Torx,Taptite, 1/4-20 x 1-1/4 1704351...
  • Page 26 Transmission Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 27 Transmission Group Item Part No Description 1960687 NUT, Hex ESNA Flange, 3/8-16 1918267 WASHER 1931350 BOLT, Carriage 3/8- 16 x 1 1960590 CAPSCREW, Hex Hd 5/16-18 x 3 1919326 WASHER, Flat 5/16 1960637 NUT, Hex Keps 3/8-16 1727215A ACTUATOR, Switch 1960241 RIVET, Pop 1/4 x 1/2 1724107...

  • Page 28: Engine Group - 23Hp Briggs & Stratton, Vanguard Twin

    Engine Group - 23HP Briggs & Stratton, Vanguard Twin Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 29 Engine Group - 23HP Briggs & Stratton, Vanguard Twin Item Part No Description 1726920 MUFFLER 1722625 MUFFLER 1917356 LOCKWASHER, 5/16 2860660 CAPSCREW, Socket Head, 5/16-18 x 7/8, G8 1723165 HOSE, Oil Drain * ENGINE, 22HP B&S VANGUARD Twin Mod. 386777-0111-E1 1722949 SEAL, Circle 1722388A...
  • Page 30 Engine Group - 23HP Briggs & Stratton, Vanguard Twin Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 31 Engine Group - 23HP Briggs & Stratton, Vanguard Twin Item Part No Description 1722390A DUCT, Muffler Extension Footnotes: Note* See your local Briggs & Stratton distributor for parts and service. YARD TRACTOR ELECTRIC CLUTCH YT400 Series Note Manual No. 7006273 TP 400-5416-IR-TC-N...

  • Page 32: Decals Group

    Decals Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 33 Decals Group Item Part No Description 1731930 DECAL, YT400 23HP 1725065 DECAL, Hood Stripe, Snapper, LH 1725066 DECAL, Hood Stripe, Snapper, RH 1722806 DECAL, Ignition Switch Symbols, White/Black 1718025 DECAL, Automatic Control Traction 1716518 DECAL, Power Steering 1734027 DECAL, Tunnel Cover...

  • Page 34: Lift Group - Manual Lift

    Lift Group - Manual Lift Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 35 Lift Group - Manual Lift Item Part No Description 1927557 NUT, Hex Whiz Lock Flange, 5/16-18, Large, Black 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 1722291 GRIP, Lift Lever 1723124 BUTTON, Red Nylon, for 1/4 Rod 1960674 NUT, Push 1723321 SPRING, Compression, Lift Lever 1721581 QUADRANT, Lift, Powdered Metal 1926149...
  • Page 36 50" Mower Deck - Housing, Arbors & Blades Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 37: Mower Deck - Housing, Arbors & Blades

    50" Mower Deck - Housing, Arbors & Blades Item Part No Description 1734785D HOUSING ASSY, 50" 2823471 CAPSCREW, Hex 7/16-14 x 1-1/4 1656916 WASHER, Spring 1713089 WASHER, Hex, 11/16 x 2 1708229 BLADE, Mower 1713196 SHIELD, Grass Lower Arbor 1713612 SHAFT, Arbor 1713195 SHAFT, Arbor...
  • Page 38 50" Mower Deck - Housing, Arbors & Blades Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 39 50" Mower Deck - Housing, Arbors & Blades Item Part No Description 1705115 PLUG, Hole 1716870A BAFFLE, Blowout, 50" LH 1735184A BAFFLE, Blowout, 50" RH 1927557 NUT, Hex Flange 5/16-18 1931333 BOLT, Carriage 5/16-18 x 3/4 1960633 BOLT, Carriage 1/4-20 x 1-1/2 1704314 FITTING, Grease Footnotes:...
  • Page 40 50" Mower Deck - Clutch & Support Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 41: Mower Deck - Clutch & Support Group

    50" Mower Deck - Clutch & Support Group Item Part No Description 1732977A HITCH ASSY 1715759 ROD, Latch 2156302 SPRING 1733830 PIN, Clevis 3/4 x 2 2860202 WASHER, Flat 3/4 1960033 CLIP, Spring 1924356 WASHER, Flat 3/8 1923938 CAPSCREW, 3/8-16 x 3-1/2 1703836 V-BELT, Arbor Drive 50"...
  • Page 42 50" Mower Deck - Height Adjust Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 43: Mower Deck - Height Adjust Group

    50" Mower Deck - Height Adjust Group Item Part No Description 2860681 NUT, Hex Toplock Spiralock Flange 3/8-16 1706644 SPACER, 3/8 x 3/4 x 15/16 1924940 WASHER, 3/4 1922606 CAPSCREW, Hex Head 3/8-16 x 1-3/4 G8 1722995 ROD, Adjusting 1931202 SCREW, Hex Washer Head Taptite 5/16-18 x 1-1/4 1919381 WASHER, 5/16...
  • Page 44 50" Mower Deck - Height Adjust Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 45 50" Mower Deck - Height Adjust Group Item Part No Description 1960170 WASHER, 1/2 2108765 BOLT, Wheel 3/8-16 1960686 NUT, Hex Flange 5/16-18 1930570 CAPSCREW, Hex Head 5/16-18 x 1-1/2 G8 1708088A CHAIN, Link 1927557 NUT, Hex Flange 5/16-18 Whiz Lock Large 1931350 CARRIAGE BOLT, 3/8-16 x 1 G5 1727135A...

  • Page 46: Electrical Group

    Electrical Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 47 Electrical Group Item Part No Description 1721810 HEADLIGHT ASSEMBLY, 4 Bulb 1677371 BULB, Headlight, 12.8V 1723451 SOCKET ASSEMBLY, Headlight, Sealed 1722669 HARNESS, Headlight 1722887 SWITCH, PTO Push/Pull Symbols 1726556 MODULE, RMO 1726557 KEY, RMO Module Plastic 1925003 CAPSCREW, Hex Washer Head Taptite, 1/4-20 x 1/2, Black 1665238 BREAKER, Circuit, 12 Volt 20 Amps 1665237...
  • Page 48 Electrical Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 49 Electrical Group Item Part No Description 1722009 STRAP, Battery, 14 Long, Rubber 1929000 CAPSCREW, Hex Head Taptite, 1/4-20 x 3/8 1726810A BRACKET, Switch Mount 1732004 SWITCH, Reverse Pedal 1704379 SWITCH, Reverse Pedal 1732006 SWITCH, Push Button, Foot Pedal 1717050 SWITCH, Cruise Control, Grey, NO 2860665 SCREW, Pan Head Torx, #10-32 x 1/2 1917365...
  • Page 52 IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 www.snapper.com Copyright © 2008 Briggs & Stratton Corporation Milwaukee, WI USA. All Rights Reserved Manual No. 7006273...
