Parts Manual for
YARD TRACTOR ELECTRIC CLUTCH
HYDRO 4WD RMO
YT400 Series
MODEL
YT2350 4WD (2690765)
Briggs & Stratton Yard Power Products Group
535 Macon Road
Manual No.
7006273
McDonough, GA, 30253 U.S.A.
800-935-2967
Revision IR,
9/17/2008
TP 400-5416-IR-TC-N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YT2350 and is the answer not in the manual?

Questions and answers

Related Manuals for Snapper YT2350

Summary of Contents for Snapper YT2350

  • Page 1 Parts Manual for YARD TRACTOR ELECTRIC CLUTCH HYDRO 4WD RMO YT400 Series MODEL YT2350 4WD (2690765) Briggs & Stratton Yard Power Products Group 535 Macon Road Manual No. 7006273 McDonough, GA, 30253 U.S.A. 800-935-2967 Revision IR, 9/17/2008 TP 400-5416-IR-TC-N...

  • Page 3: Table Of Contents

    PAGE GROUP Wheels & Tires Group Steering Group - Power Steering Steering Group - Power Steering Hood, Grille & Dash Group Seat & Seat Deck Group Frame & Front Axle Group - 4WD Controls Group Cruise Control Group Transmission Group Engine Group - 23HP Briggs &...
  • Page 4 Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 5: Wheels & Tires Group

    Wheels & Tires Group Item Part No Description 1735010 WHEEL & TIRE ASSEMBLY, Front 1735706 TIRE, 16 x 6-1/2 - 8 2153038 TUBE, Tire 1722834 WHEEL ASSEMBLY 2172353 VALVE STEM & CAP ASSEMBLY 2860202 WASHER, Flat 3/4 x 1-5/8 x 1/8 1722717 WASHER, Flat 1960114...

  • Page 6: Steering Group - Power Steering

    Steering Group - Power Steering Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 7: Steering Wheel

    Steering Group - Power Steering Item Part No Description 1733363 STEERING WHEEL 1724685A PLATE, Steering Mounting 1960655 CARRIAGE BOLT, 5/16-18 x 1-1/4 G5 1725294 ADAPTER, Tilt 1723898 SPACER 1933988 NUT, Push Pal 1960636 NUT, Hex Keps 5/16-18 1733790 STEERING UNIT, Tilt 1686970 BELLOWS, Tilt Steering Unit w/Slot 1725024...
  • Page 8 Steering Group - Power Steering Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 9: Steering Group - Power Steering

    Steering Group - Power Steering Item Part No Description 1733894 POWER STEERING, 4 Ports, 4WD 1916964 LOCKWASHER, Spring 1/4 2860444 CAPSCREW, Hex Hd, M06-1 x 16mm 1722138 TUBE, Hydraulic 2825094 TIE, Wire 1733727 TUBE-Hydraulic 1931646 SCREW, Whiz Lock, 1/4-20 x 1/2 1722123 FITTING, Straight 1719168...

  • Page 10: Hood, Grille & Dash Group

    Hood, Grille & Dash Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 11 Hood, Grille & Dash Group Item Part No Description 1728031D HOOD, W/Scoop 1721804D PANEL, R.H. Side 1721803D PANEL, L.H. Side 1721810 HEADLIGHT ASSEMBLY 1721802D GRILLE 1930641 NUT, Hex Flange 1/4-20 Whiz Lock 1726827 DASHBOARD 1726894 DASHBOARD, W/Hydraulic Lift Slot 1721808A HINGE, Hood L.H.

  • Page 12: Seat & Seat Deck Group

    Seat & Seat Deck Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 13 Seat & Seat Deck Group Item Part No Description 1722129A BRACKET, 1-5/8 x 1-3/4 1732000 SEAT, 18” Back 1722128A SUPPORT, Seat 2172434 CLIP, Wire 1709256A WASHER, Spring, 5/16 x 1-1/4 1714263 SPRING, Compression 1919438 NUT, Hex Lock, ESNA Light, 5/16-18 1717051 SPRING, Compression 1930591...

  • Page 14: Frame & Front Axle Group - 4Wd

    Frame & Front Axle Group - 4WD Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 15 Frame & Front Axle Group - 4WD Item Part No Description 1734731A FRAME ASSEMBLY, Front & Rear 4WD 1733139A TOWER & SUPPORT ASSEMBLY 1723528A SUPPORT, Seat Deck 1722602A SUPPORT, Drawbar 1733918A BRACKET ASSEMBLY, Steering 4WD 1721805A BUMPER, 4GA 1733480 AXLE ASSEMBLY, Front 1734241A PIVOT ASSEMBLY, Axle w/Bushings 1960755...
  • Page 16 Frame & Front Axle Group - 4WD Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 17 Frame & Front Axle Group - 4WD Item Part No Description 1733402 FITTING, Bulkhead Union 13/16-16 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 G5 1960636 NUT, Hex KEPS, 5/16-18 1733947 NUT, Jam 13/16-16 1960103 WASHER, 3/8 1931355 CARRIAGE BOLT, 3/8-16 x 2-1/4 G5 1733044A SUPPORT, Steering Unit 7GA 1924856...

  • Page 18: Controls Group

    Controls Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 19 Controls Group Item Part No Description 1721353 ROD, Brake Lock 1721891 KNOB, Push On, Red Plastic “P” 1930591 CAPSCREW, Hex Flange Whiz Lock, 5/16-18 x 3/4 1919326 WASHER, 5/16, Black 1721476 ROD, Brake 1931353 CARRIAGE BOLT, 3/8-16 x 1 3/4 1663114 BUSHING, 5/8 x 3/4 x 3/4, Nylon 2821133...
  • Page 20 Controls Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 21 Controls Group Item Part No Description 1721674 PAD, Foot Pedal Reverse 1920397 NUT, Hex Lock ESNA Light, 1/4-20 1686612 CAM, Roller 1721995 SPRING, Extension Footnotes: YARD TRACTOR ELECTRIC CLUTCH YT400 Series Note Manual No. 7006273 TP 400-5416-IR-TC-N...

  • Page 22: Cruise Control Group

    Cruise Control Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 23 Cruise Control Group Item Part No Description 1722314 COVER, w/Cruise Icon 1960666 SCREW, Torque Head Plus Socket Head, 1/4-20 x 7/8 1722303 KNOB, Cruise 1920397 NUT, Hex Lock ESNA Light, 1/4-20 1722003 LEVER & BRACKET ASSEMBLY, Cruise 1960103 WASHER, 3/8, Black 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 7091587...

  • Page 24: Transmission Group

    Transmission Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 25 Transmission Group Item Part No Description 1733478 TRANSMISSION, K664 4WD 1722194 PULLEY 1719233 1933958 SCREW, Hex Taptite 1/4-20 x 1-1/2 1721392 V-Belt 1721593A STRAP, Torque 1733318A CONTROL ARM, Front 1721424 ROD, Brake 1722684 SPRING, Compression 1729277 SPRING, Compression 1722711 CAP, Tank 1960676 SCREW, Pan Hd Torx,Taptite, 1/4-20 x 1-1/4 1704351...
  • Page 26 Transmission Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 27 Transmission Group Item Part No Description 1960687 NUT, Hex ESNA Flange, 3/8-16 1918267 WASHER 1931350 BOLT, Carriage 3/8- 16 x 1 1960590 CAPSCREW, Hex Hd 5/16-18 x 3 1919326 WASHER, Flat 5/16 1960637 NUT, Hex Keps 3/8-16 1727215A ACTUATOR, Switch 1960241 RIVET, Pop 1/4 x 1/2 1724107...

  • Page 28: Engine Group - 23Hp Briggs & Stratton, Vanguard Twin

    Engine Group - 23HP Briggs & Stratton, Vanguard Twin Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 29 Engine Group - 23HP Briggs & Stratton, Vanguard Twin Item Part No Description 1736543 MUFFLER 1917356 LOCKWASHER, 5/16 2860660 CAPSCREW, Socket Head, 5/16-18 x 7/8, G8 1723165 HOSE, Oil Drain * ENGINE, 23HP B&S VANGUARD Twin Mod. 386777-0111-E1 1722949 SEAL, Circle 1722388A BULKHEAD 1925003...
  • Page 30 Engine Group - 23HP Briggs & Stratton, Vanguard Twin Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 31 Engine Group - 23HP Briggs & Stratton, Vanguard Twin Item Part No Description 1722390A DUCT, Muffler Extension Footnotes: Note* See your local Briggs & Stratton distributor for parts and service. YARD TRACTOR ELECTRIC CLUTCH YT400 Series Note Manual No. 7006273 TP 400-5416-IR-TC-N...

  • Page 32: Decals Group

    Decals Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 33 Decals Group Item Part No Description 1731930 DECAL, YT400 23HP 1725065 DECAL, Hood Stripe, Snapper, LH 1725066 DECAL, Hood Stripe, Snapper, RH 1722806 DECAL, Ignition Switch Symbols, White/Black 1718025 DECAL, Automatic Control Traction 1716518 DECAL, Power Steering 1734027 DECAL, Tunnel Cover...

  • Page 34: Lift Group - Manual Lift

    Lift Group - Manual Lift Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 35 Lift Group - Manual Lift Item Part No Description 1927557 NUT, Hex Whiz Lock Flange, 5/16-18, Large, Black 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 1722291 GRIP, Lift Lever 1723124 BUTTON, Red Nylon, for 1/4 Rod 1960674 NUT, Push 1723321 SPRING, Compression, Lift Lever 1721581 QUADRANT, Lift, Powdered Metal 1926149...
  • Page 36 50" Mower Deck - Housing, Arbors & Blades Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 37: Mower Deck - Housing, Arbors & Blades

    50" Mower Deck - Housing, Arbors & Blades Item Part No Description 1734785D HOUSING ASSY, 50" 2823471 CAPSCREW, Hex 7/16-14 x 1-1/4 1656916 WASHER, Spring 1713089 WASHER, Hex, 11/16 x 2 1708229 BLADE, Mower 1713196 SHIELD, Grass Lower Arbor 1713612 SHAFT, Arbor 1713195 SHAFT, Arbor...
  • Page 38 50" Mower Deck - Clutch & Support Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 39: Mower Deck - Clutch & Support Group

    50" Mower Deck - Clutch & Support Group Item Part No Description 1732977A HITCH ASSY 1731414 ROD, Latch 2176012 SPRING PIN 1723701 CAPSCREW, 3/8-16 x 2 2860202 WASHER, Flat 1960687 NUT, Flange ESNA Lock 3/8-16 1924356 WASHER, Flat 3/8 1923938 CAPSCREW, 3/8-16 x 3-1/2 1703836 V-BELT, Arbor Drive 50"...
  • Page 40 50" Mower Deck - Housing, Arbors & Blades Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 41 50" Mower Deck - Housing, Arbors & Blades Item Part No Description 1705115 PLUG, Hole 1716870A BAFFLE, Blowout, 50" LH 1735184A BAFFLE, Blowout, 50" RH 1927557 NUT, Hex Flange 5/16-18 1931333 BOLT, Carriage 5/16-18 x 3/4 1960633 BOLT, Carriage 1/4-20 x 1-1/2 1704314 FITTING, Grease Footnotes:...
  • Page 42 50" Mower Deck - Height Adjust Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...

  • Page 43: Mower Deck - Height Adjust Group

    50" Mower Deck - Height Adjust Group Item Part No Description 2860681 NUT, Hex Toplock Spiralock Flange 3/8-16 1706644 SPACER, 3/8 x 3/4 x 15/16 1924940 WASHER, 3/4 1922606 CAPSCREW, Hex Head 3/8-16 x 1-3/4 G8 1722995 ROD, Adjusting 1931202 SCREW, Hex Washer Head Taptite 5/16-18 x 1-1/4 1919381 WASHER, 5/16...
  • Page 44 50" Mower Deck - Height Adjust Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 45 50" Mower Deck - Height Adjust Group Item Part No Description 1960170 WASHER, 1/2 2108765 BOLT, Wheel 3/8-16 1960686 NUT, Hex Flange 5/16-18 1930570 CAPSCREW, Hex Head 5/16-18 x 1-1/2 G8 1708088A CHAIN, Link 1927557 NUT, Hex Flange 5/16-18 Whiz Lock Large 1931350 CARRIAGE BOLT, 3/8-16 x 1 G5 1727135A...

  • Page 46: Electrical Group

    Electrical Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 47 Electrical Group Item Part No Description 1721810 HEADLIGHT ASSEMBLY, 4 Bulb 1677371 BULB, Headlight, 12.8V 1723451 SOCKET ASSEMBLY, Headlight, Sealed 1722669 HARNESS, Headlight 1722887 SWITCH, PTO Push/Pull Symbols 1726556 MODULE, RMO 1726557 KEY, RMO Module Plastic 1925003 CAPSCREW, Hex Washer Head Taptite, 1/4-20 x 1/2, Black 1665238 BREAKER, Circuit, 12 Volt 20 Amps 1665237...
  • Page 48 Electrical Group Manual No. 7006273 YARD TRACTOR ELECTRIC CLUTCH TP 400-5416-IR-TC-N YT400 Series...
  • Page 49 Electrical Group Item Part No Description 1722009 STRAP, Battery, 14 Long, Rubber 1929000 CAPSCREW, Hex Head Taptite, 1/4-20 x 3/8 1726810A BRACKET, Switch Mount 1732004 SWITCH, Reverse Pedal 1704379 SWITCH, Reverse Pedal 1732006 SWITCH, Push Button, Foot Pedal 1717050 SWITCH, Cruise Control, Grey, NO 2860665 SCREW, Pan Head Torx, #10-32 x 1/2 1917365...
  • Page 52 IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 www.snapper.com Copyright © 2008 Briggs & Stratton Corporation Milwaukee, WI USA. All Rights Reserved Manual No. 7006273...
