OPERATOR'S
MANUAL
Baron XL / 2400 XL / RD Series
18HP Hydro Tractors
Mfg. No.
Description
2690337
Baron XL, 18HP & 40" Mower (CE)
2690339
2418 XL, 18HP 40" Mower (CE)
2690341
RD18S40, 18HP 40" Mower (CE)
2690342
RD18VG40, 18HP 40" Mower (CE)
2690507
Baron XL, 18HP & 40" Mower (CE)
2690508
RD18S40, 18HP 40" Mower (CE)
2690509
RD18VG40, 18HP 40" Mower (CE)
1694670
Baron XL, 18HP (CE)
1694672
2418 XL, 18HP (CE)
1694674
RD18S40, 18HP (CE)
1694675
RD18VG40, 18HP (CE)
20HP Hydro Tractors
Mfg. No.
Description
2690338
Baron XL, 20HP & 40" Mower (CE)
2690340
2420 XL, 20HP & 40" Mower (CE)
2690506
Baron XL, 20HP & 40" Mower (CE)
2690510
2420 XL, 20HP & 40" Mower (CE)
1694671
Baron XL, 20HP (CE)
1694673
2420 XL, 20HP (CE)
40" Mower Decks
Mfg. No.
Description
1694790
40" Mower Deck (CE)
1694796
40" Mower Deck (CE)
1694813
40" Mower Deck (CE)
1695031
40" Mower Deck (CE)
1695032
40" Mower Deck (CE)
Rev. Date 11/2005
TP 100-4090-03-BR-SMN
1727704
Revision 03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XL Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Snapper XL Series

  • Page 1 OPERATOR’S MANUAL Baron XL / 2400 XL / RD Series 18HP Hydro Tractors Mfg. No. Description 2690337 Baron XL, 18HP & 40” Mower (CE) 2690339 2418 XL, 18HP 40” Mower (CE) 2690341 RD18S40, 18HP 40” Mower (CE) 2690342 RD18VG40, 18HP 40” Mower (CE) 2690507 Baron XL, 18HP &...
  • Page 3: Table Of Contents

    Safety Rules & Information...2 Identification Numbers...7 Safety Decals ...8 Safety Icons ...9 Safety Interlock System ...9 Features & Controls ...10 Control Functions ...10 Operating the Tractor ...12 General Operating Safety ...12 Adding Fuel ...12 Starting the Engine ...12 Stopping the Tractor & Engine ...12 Driving the Tractor ...13 Mowing...13 Mowing in Reverse ...13...
  • Page 4: Safety Rules & Information

    Safety Rules & Information Read the Manual The operator’s manual contains important safety information you need to be aware of BEFORE you operate your unit as well as DURING operation. Safe operating techniques, an explanation of the product’s features and controls, and maintenance information is included to help you get the most out of your equipment investment.
  • Page 5: Safety Rules And Information

    Moving Parts This equipment has many moving parts that can injure you or someone else. However, if you are seated in the seat properly, and follow all the rules in this book, the unit is safe to operate. The mower deck has spinning mower blades that can amputate hands and feet. Do not allow anyone near the equipment while it is running! To help you, the operator, use this equipment safely, it is equipped with an operator-present safety system.
  • Page 6: General Operation

    Safety Rules & Information Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. This mowing deck is capable of amputating hands and feet and throwing objects.
  • Page 7: Ignition System

    SLOPE OPERATION Slopes are a major factor related to loss-of-control and tip- over accidents, which can result in severe injury or death. Operation on all slopes requires extra caution. If you can- not back up the slope or if you feel uneasy on it, do not operate on it.
  • Page 8: Service And Maintenance

    Safety Rules & Information SERVICE AND MAINTENANCE Safe Handling of Gasoline 1. Extinguish all cigarettes, cigars, pipes, and other sources of ignition. 2. Use only approved gasoline containers. 3. Never remove the gas cap or add fuel with the engine running.
  • Page 9: Identification Numbers

    J. Sound Pressure at Operator’s Position in Decibels ** K. Vibration at the Steering Wheel * L. Vibration at the Seat * This unit complies with European Harmonized Lawn Mower Standard EN 836, European Machinery Directive 98/37/EC, and European EMC Directive 89/336/EC...
  • Page 10: Safety Decals

    Safety Decals SAFETY DECALS This unit has been designed and manufactured to pro- vide you with the safety and reliability you would expect from an industry leader in outdoor power equipment manufacturing. Although reading this manual and the safety instructions it contains will provide you with the necessary basic knowledge to operate this equipment safely and effec- tively, we have placed several safety labels on the unit to...
  • Page 11: Safety Icons

    SAFETY ICONS Warning: Read Operator’s Manual. Read and understand the Operator’s Manual before using this machine. Warning: Remove Key Before Servicing. Remove the key and consult techni- cal literature before performing repairs or maintenance. Danger: Dismemberment. This machine can amputate limbs. Keep bystanders and children away when engine is running.
  • Page 12: Features & Controls

    Features & Controls Figure 1. Tractor and Mower Controls NOTE: Steering wheel removed for clarity Please take a moment and familiarize yourself with the name, location, and function of these controls so that you will better understand the safety and operating instructions pro- vided in this manual.
  • Page 13: Seat Adjustment Lever

    PTO Switch The PTO (Power Take-Off) switch engages and disen- gages attachments that use the PTO. To engage the PTO, pull UP on the switch. Push DOWN to disengage. Note that the operator must be seated firmly in the trac- tor seat for the PTO to function.
  • Page 14: Operating The Tractor

    Features & Controls Catcher Open/Close Lever The catcher open/close lever opens the catcher so that it may be emptied and closes it for mowing. To empty the catcher, depress the catcher dump lock pedal and pull forward on the handle. To close, push the lever back- ward until the catcher closes and locks.
  • Page 15: Driving The Tractor

    DRIVING THE TRACTOR 1. Sit in the seat and adjust the seat so that you can comfortably reach all the controls and see the dash- board display. 2. Engage the parking brake. 3. Make sure the PTO switch is disengaged. 4.
  • Page 16: Parking Brake Functions

    Operating the Tractor Figure 3. Engaging the Parking Brake A. Ground Speed Pedals B. Brake Pedal C. Parking Brake Knob PARKING BRAKE FUNCTION Applying the Parking Brake - See Figure 3. To lock the parking brake, release the ground speed pedals (A), fully depress the brake pedal (B), pull UP on the parking brake knob (C), and then release brake pedal.
  • Page 17: Attaching A Trailer

    ADJUSTING THE DEFLECTOR (Select Models) Adjusting the defuser will change the distribution of grass clippings. To adjust the defuser: 1. Loosen hardware (B, Figure 6) 2. Slide defuser (A) up or down. 3. Secure hardware (B). 4. Repeat steps 1-3 if necessary. ATTACHING A TRAILER NOTE: Remove the hopper to attach a trailer.
  • Page 18: Mower Deck Removal & Installation

    Operating the Tractor Figure 8. Raising & Lowering Mower A. Attachment Lift C. Hopper Lever B. Cutting Height Control WARNING Engage parking brake, disengage PTO, stop engine and remove key before attempting to install or remove the mower. MOWER DECK REMOVAL & INSTALLATION Removing the Mower Deck 1.
  • Page 19: Installing The Mower Deck

    Installing the Mower Deck 1. Park tractor, shut off PTO and engine, remove the key and apply parking brake. Turn the wheels fully to the left. 2. From the rear with the grass catcher open pull dis- charge chute to rear. 3.
  • Page 20: Mulch Plug Installation & Removal (Some Models)

    Operating the Tractor MULCH PLUG INSTALLATION & REMOVAL (SOME MODELS) 1. Secure plate (B, Figure 14) to the mulch plug (A) using 1/4-20 x 3/4 capscrews (D) and 1/4 lockwash- ers (C). WARNING For your personal safety, do not handle the sharp mower blades with bare hands.
  • Page 22: Regular Maintenance

    Regular Maintenance MAINTENANCE SCHEDULE & PROCEDURES The following schedule should be followed for normal care of your tractor and mower. Use the hour meter to deter- mine your operating time. SAFETY ITEMS Check Grass Collector for Wear Check Safety Interlock System Check Tractor Brakes Check Mower Blade Stopping Time TRACTOR MAINTENANCE ITEMS...
  • Page 23: Check Tire Pressures

    CHECK TIRE PRESSURES Service Interval: Every 25 Hours Tire Pressure should be checked periodically, and main- tained at the levels shown in the chart. Note that these pressures may differ slightly from the “Max Inflation” stamped on the side-wall of the tires. The pressures shown provide proper traction, improve cut quality, and extend tire life.
  • Page 24: Lubrication

    Regular Maintenance LUBRICATION Service Interval: Every 25 Hours Lubricate the unit at the locations shown in Figures 19- 22 as well as the lubrication points listed. Generally, all moving metal parts should be oiled where contact is made with other parts. Keep oil and grease off belts and pulleys.
  • Page 25: Lubricate Rear Axle Shafts

    LUBRICATE REAR AXLE SHAFTS Service Interval: Yearly We recommend removing the rear wheel hubs and lubri- cating the axle shafts yearly. This prevents the wheel hubs from seizing onto the axle shaft and makes future service easier. 1. Turn off the ignition, turn off the PTO, engage the parking brake, and block the front tires.
  • Page 26: Servicing The Mower Blades

    Regular Maintenance 4x4 Wood Block Figure 24. Removing the Blade SERVICING THE MOWER BLADES WARNING For your personal safety, do not handle the sharp mower blades with bare hands. Careless or improper handling of blades may result in serious injury. Service Interval: Every 100 Hours or As Required NOTE: Replace blades and bolts in sets.
  • Page 27: Set Mower Belt Tension

    SET MOWER BELT TENSION WARNING For your personal safety, do not handle the sharp mower blades with bare hands. Careless or improper handling of blades may result in serious injury. Service Interval: Yearly 1. Turn the PTO to the off position, engage the parking brake, turn the engine off, and remove the key.
  • Page 28: Troubleshooting, Adjustments, & Service

    Troubleshooting, Adjustments, & Service TROUBLESHOOTING While normal care and regular maintenance will extend the life of your equipment, prolonged or constant use may eventually require that service be performed to allow it to continue operating properly. The troubleshooting guide below lists the most common problems, their causes and remedies.
  • Page 29: Troubleshooting The Mower

    Tractor Troubleshooting Continued Tractor drive belt slips. Brake will not hold. Tractor steers hard or handles poorly. TROUBLESHOOTING THE MOWER PROBLEM Mower will not raise. Mower cut is uneven. Mower cut is rough looking. Engine stalls easily with mower engaged. Excessive mower vibration.
  • Page 30: Seat Adjustment

    Troubleshooting, Adjustment, & Service SEAT ADJUSTMENT Pitch Adjustment The pitch of the seat can be adjusted to one of three positions. To adjust, remove the carriage bolts, spacers, washers, and nuts (B, Figure 28) from the hinge and reinstall them in the desired holes. Seat Slide Adjustment The seat can also be adjusted forward and back.
  • Page 31: Steering Gear Adjustment

    STEERING GEAR ADJUSTMENT If there is excessive slack in the steering system, the steering gear backlash can be removed. 1. See Figure 30. Locate the steering gear assembly on the underside of the tractor. Loosen the two nuts and adjust the bracket so the gear teeth are closely meshed.
  • Page 32: Catcher-Full Alarm Adjustment

    Troubleshooting, Adjustment, & Service CATCHER-FULL ALARM ADJUSTMENT There are two ways to adjust the “catcher full” alarm one for grass volume and one for sensitivity. GRASS VOLUME ADJUSTMENT Sliding the paddle bracket (C, Figure 32) up increases the volume of grass in the collector before the alarm goes off.
  • Page 33: Pto Clutch Adjustment

    PTO CLUTCH ADJUSTMENT WARNING To avoid serious injury, perform adjustments only with engine stopped, key removed and tractor on level ground. Check the PTO clutch adjustment after every 250 hours of operation. Also perform the following procedure if the clutch is slipping or will not engage, or if a new clutch has been installed.
  • Page 34: Transmission Purging

    Troubleshooting, Adjustment, & Service TRANSMISSION PURGING Purge the transmission if the unit is excessively noisy or lacks drive in forward or reverse. 1. Elevate the rear end of the tractor using a chain hoist or floor jack. Support the rear of the unit using jack- stands.
  • Page 35: Mower Adjustments

    MOWER ADJUSTMENTS WARNING Before checking mower, shut off PTO and engine, remove the key, and allow all moving parts to stop. Cutting Height Adjustment The cutting height adjustment lever (A, Figure 37) con- trols the mower cutting height. Push the button to release the lever.
  • Page 36: Pto Belt Replacement

    Troubleshooting, Adjustment, & Service PTO BELT REPLACEMENT 1. With the mower deck installed, park the tractor on a smooth, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, shut the engine off, and remove the key. 2.
  • Page 37: Specifications

    NOTE: Specifications are correct at time of printing and are subject to change without notice. * Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors. ENGINE: 20 HP* Briggs & Stratton Make Briggs & Stratton Model Vanguard Horsepower...
  • Page 38: Parts & Accessories

    For applicable manuals currently available for your model, contact our Customer Publications Department at 262-284-8519 (Simplicity) / 866-313-6682 (Snapper). Have the information listed in the box below available when phoning in your request. Technical manuals can be downloaded from www.simplicitymfg.com...
  • Page 40 500 N Spring Street / PO Box 997 Port Washington, WI 53074-0997 www.MasseyLawn.com © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. Printed in USA. P R O D U C T S 535 Macon Street McDonough, GA 30253 www.Snapper.com...
