- Page 1 Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 HYDRO DRIVE ZTR 42" & 50" Revision IR, 10/6/2008 Parts Manual for AUSTRALIAN 150Z SERIES MODEL SC2142 (7800390) SC2450 (7800391) Manual No. 7006272 TP 400-5418-IR-HZ-N...
-
Page 3: Table Of Contents
PAGE GROUP Frame, Body & Seat Group Transmission Group Controls Group Engine Group (21 H.P.) Engine Group (24 H.P.) Wheel & Tire Group Decal Group Mower Lift Group (42" Deck) Mower Lift Group (50" Deck) 42" Mower Deck - Clutch & Support Group 42"... - Page 4 Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 5: Frame, Body & Seat Group
Frame, Body & Seat Group Item Part No Description 1733448A WELDMENT, Caster Yoke & Spindle- Black 1960160 WASHER, .75 ID x 1.60 OD x .05 Thick Flat (Black) 1611710 KLIPRING, External for .750 Dia. Shaft 1734135 CAP, Hub 1.481 I.D. x .62 Long Red Poly 1730186 BUSHING, Axle Pivot PM Yellow 1733426A... - Page 6 Frame, Body & Seat Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
- Page 7 Frame, Body & Seat Group Item Part No Description 1930594 SCREW, 1/4-20 x 3/4” Hex Flange Lock Black 7091591 BOLT, 5/16-18 x 1” Hex Flange Lock YZ 1728986 PAD, Footrest RH Black Vinyl w/Adhesive 1728987 PAD, Footrest LH Black Vinyl w/Adhesive 1960534 WASHER, .375 Flat (0.41 I.D.
- Page 8 Transmission Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 9: Transmission Group
Transmission Group Item Part No Description 1960223 BOLT, 5/16-18 x 1-1/4” Round Head Short Square Neck GR5, Black 1919381 WASHER, 5/16” Flat (.341 I.D. x 1.00 O.D. x .13 Thick) Black 1703900 SPACER, .323 I.D. x .500 O.D. x 0.270 Long Heat Treated 1960684 NUT, 5/16-18 Hex Keps Conical Washer, Black 1727555... - Page 10 Transmission Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
- Page 11 Transmission Group Item Part No Description 1721133 PULLEY, Idler 1924940 WASHER, .375 Flat (.41 I.D. x .87 O.D.) 1708352A BELT GUIDE 1923701 SCREW, 3/8-16 x 2” Hex Head Cap, GR5 7091553 SCREW, 3/8-16 x 1-3/4” Hex Head Cap, GR5 1931942 NUT, Push Pal, 3/8”...
- Page 12 Controls Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 13: Controls Group
Controls Group Item Part No Description 1726410 GRIP, Foam Handle Bar 1727796A TUBE, Handle 1960686 NUT, 5/16-18 Hex Flange Nyloc 1720452 CLAMP, Tube, Saddle 1919381 WASHER, 5/16” Flat (.341 I.D. x 1.00 O.D. x .13 Thick) Black 1960086 SCREW, 5/16-18 x 7/8” Truss Head Torx, Black 1917356 LOCKWASHER, Spring 5/16”... - Page 14 Controls Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
- Page 15 Controls Group Item Part No Description 1666697 SPACER, Powdered Metal 1921977 SCREW, 5/16-18 x 1-1/4” Hex Head Cap, GR5, Black 1715025 BUSHING 1919438 NUT, 5/16-18 Hex Lock Esna Light 1727603A WELDMENT, Pivot Control 1921221 SCREW, 5/16-18 x 1-1/2” Hex Head Cap, GR5, Black 1727918 SHOCK ABSORBER 1703805...
- Page 16 Engine Group (21 H.P.) Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 17: Engine Group (21 H.p
Engine Group (21 H.P.) Item Part No Description * ENGINE, 21 HP, B&S, ELS AUSTRALIA, Mod. 33M777-0114- 7300919A HEAT SHIELD, Inner 1936228 SCREW, 5/16-18 x 3/4” Hex Head Cap, GR8 1917356 LOCKWASHER, Spring 5/16”, Black 1732259 WELDMENT, Exhaust Pipe 1731214 GASKET, Exhaust B&S 1960295 SCREW, 1/4-20 x 5/8”... - Page 18 Engine Group (21 H.P.) Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
- Page 19 Engine Group (21 H.P.) Item Part No Description 1921332 SCREW, 5/16-18 x 3/4” Hex Head Cap, Black 7100416 CABLE, Choke, 54” 7090390 WASHER, 3/8” Internal Tooth Lock 7091630 NUT, 3/8-24 Hex 7075449 CONTROL, Throttle B&S Intek 7090999 SCREW, 1/4-20 x 5/8” Pan Head Taptite Torx 7091195 SCREW, #10-16 x 3/4”...
- Page 20 Engine Group (24 H.P.) Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 21: Engine Group (24 H.p
Engine Group (24 H.P.) Item Part No Description 7027266 SCREW, 7/16-20 x 3” Hex Head Cap, GR5 (w/Nyloc Patch) 1918199 LOCKWASHER, Spring, .438 1708264 WASHER, Hex, .453 I.D. x 1-1/2” 2832747 TIE, Self Locking 3-5/8” Long 1717664 CLUTCH, Ogura JD-11 2828635 SCREW, 3/8-16 x 1-1/4”... - Page 22 Engine Group (24 H.P.) Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
- Page 23 Engine Group (24 H.P.) Item Part No Description 1932377 NUT, 5/16-18 Hex Whiz Lock Flange Footnotes: Note: * Purchase engine components directly from engine manufacturer dealer. Note: ** See Frame, Body & Seat Group for fuel tank assy. HYDRO DRIVE ZTR 42" & 50" 150Z SERIES Note Manual No.
- Page 24 Wheel & Tire Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 25: Wheel & Tire Group
Wheel & Tire Group Item Part No Description 1726383 ASSY, Wheel & Tire, 18 x 8.50-8 “Superturf” (incl. 2 & 3) 1734878SM RIM, 18 x 8.50-8, 4 Hole 1734877SM TIRE, 18 x 8.50 4 Ply “Superturf” 7091772 SCREW, 7/16-14 x 6” Hex Head Cap, GR5 1734841 TUBE, Caster 7090839... - Page 26 Decal Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 27: Decal Group
DECAL- LH Handle Control ZTS 7500 7102578 DECAL, Parking Brake, ZT 1734184 DECAL, Belt/Blade ZT 1734273 DECAL, Hot Surfaces 7102865 DECAL, New Snapper Stripe, RH 7102864 DECAL, New Snapper Stripe, LH 1733458 DECAL, Height-Of-Cut 7102577 DECAL, 150Z 21HP SNAPPER ZT 1734347... - Page 28 Mower Lift Group (42" Deck) Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 29: Mower Lift Group (42" Deck
Mower Lift Group (42" Deck) Item Part No Description 1922007 NUT, 7/16-14 Hex Jam 1734042 TRUNNION, 1/2-13 Thread 1733381 ROD, Bail (7/16-14 Thread, 2 Places) 1733535A ARM, Mower Lift L.H. 720107 SHOULDER BOLT, 5/16-18 1931277 NUT, 5/16-18 Hex Flange Lock, Small - Black 1960251 NUT, 3/8-16 Hex Center Lock Jam 721221... - Page 30 Mower Lift Group (50" Deck) Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 31: Mower Lift Group (50" Deck
Mower Lift Group (50" Deck) Item Part No Description 1922007 NUT, 7/16-14 Hex Jam 1734042 TRUNNION, 1/2-13 Thread 1733381 ROD, Bail (7/16-14 Thread, 2 Places) 1733535A ARM, Mower Lift L.H. 720107 SHOULDER BOLT, 5/16-18 1931277 NUT, 5/16-18 Hex Flange Lock, Small - Black 1960251 NUT, 3/8-16 Hex Center Lock Jam 721221... - Page 32 42" Mower Deck - Clutch & Support Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 33: Mower Deck - Clutch & Support Group
42" Mower Deck - Clutch & Support Group Item Part No Description 2108765 BOLT, Shoulder (Gage Wheel) 3/8-16 x 2.781 x 3/4” 1960170 WASHER, .51 I.D. x 1.0 O.D. x .10 Thick 1714760 WHEEL, Gage (2” Wide, 3.92 Dia.) 1732258A BRACKET, Gage Wheel L.H. - Page 34 42" Mower Deck - Housing & Arbor Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 35: Mower Deck - Housing & Arbor Group
42" Mower Deck - Housing & Arbor Group Item Part No Description 1730100D HOUSING, 42” Deck (Red) 721339 ASSEMBLY, Deflector Chute 1960093 PUSH NUT, 3/8” Pal Cap 721371 ROD, Deflector 720154 SPRING, Torsion 721369 BRACKET, Hinge 1931333 BOLT, 5/16-18 x 3/4” Round Head Short Square Neck, GR5 1960686 NUT, 5/16-18 Hex Flange Nyloc 1732354... - Page 36 50" Mower Deck - Clutch & Support Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 37: Mower Deck - Clutch & Support Group
50" Mower Deck - Clutch & Support Group Item Part No Description 1732204 * V-BELT (HA Sect., 91.10 Effective Length) Kevlar 1734131 * V-BELT (HA sect., 73.12 Effective Length) 1922918 SCREW, 3/8-16 x 3-1/4” Hex Head Cap, GR5 1924940 WASHER, .375 Flat (.41 I.D. x .87 O.D.) 2101096 PULLEY, 4-1/2”... - Page 38 50" Mower Deck - Housing & Arbor Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 39: Mower Deck - Housing & Arbor Group
50" Mower Deck - Housing & Arbor Group Item Part No Description 1714419 NUT, 9/16-18 Hex Flange (non-locking) 1713675 WASHER, Belleville 1732951 PULLEY, Deep Groove, 4.6 1713158 HUB, Double Pulley 1713098 PULLEY 1713533 HUB, Double Pulley 1713197 HUB, Pulley, Center & R.H. 1655729 HOUSING, Arbor Top 7013313... - Page 40 50" Mower Deck - Housing & Arbor Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
- Page 41 50" Mower Deck - Housing & Arbor Group Item Part No Description 1705449 DEFLECTOR, Discharge 7101082 SPRING, Torsion Chute 44” & 50” Decks 1706709 ROD, Deflector, Front 1920397 NUT, 1/4” Hex Lock Esna Light 1960633 BOLT, 1/4-20 x 1-1/2” Round Head Square Neck, GR5 Footnotes: HYDRO DRIVE ZTR 42"...
- Page 42 Electrical Group Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 43: Electrical Group
Electrical Group Item Part No Description 7022886 SWITCH, Push Button (NO/NC) Snap-In 1716061 SWITCH ASSEMBLY, Ignition 1960547 LOCKWASHER, Internal Tooth 5/8” Thin 1717549 NUT, 5/8-32 Hex Flange (Ignition Switch Die Cast) 1717550 COVER, Ignition Switch 1717163 KEYS (set of two) 1731185 HOUR METER, No Alarms 1722611... - Page 44 Wiring Schematic Manual No. 7006272 HYDRO DRIVE ZTR 42" & 50" TP 400-5418-IR-HZ-N 150Z SERIES...
-
Page 45: Wiring Schematic
Wiring Schematic Item Part No Description 7102581 HARNESS, Wiring Footnotes: HYDRO DRIVE ZTR 42" & 50" 150Z SERIES Note Manual No. 7006272 TP 400-5418-IR-HZ-N... - Page 48 IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 www.snapper.com Copyright © 2008 Briggs & Stratton Corporation Milwaukee, WI USA. All Rights Reserved Manual No. 7006272...
