Parts Manual for
YARD TRACTOR ELECTRIC CLUTCH
HYDRO DRIVE REAR DISCHARGE RMO
SERIES 0
MODEL
RD1840 (2690342)
RD18S40 (2690341)
McDonough, GA, 30253 U.S.A.
COPYRIGHT © 2005
Manual No.
06457
SNAPPER PRODUCTS, INC.
Revision IR,
6/7/2005
TP 400-5064-IR-TC-N
ALL RIGHTS RESERVED.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RD1840, RD18S40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snapper RD1840, RD18S40

Summary of Contents for Snapper RD1840, RD18S40

  • Page 1 Parts Manual for YARD TRACTOR ELECTRIC CLUTCH HYDRO DRIVE REAR DISCHARGE RMO SERIES 0 MODEL RD1840 (2690342) RD18S40 (2690341) McDonough, GA, 30253 U.S.A. COPYRIGHT © 2005 Manual No. 06457 SNAPPER PRODUCTS, INC. Revision IR, 6/7/2005 TP 400-5064-IR-TC-N ALL RIGHTS RESERVED.

  • Page 3: Table Of Contents

    PAGE GROUP Wheels & Tires Group Hood, Grille & Dash Group Steering Group Frame & Front Axle Group Controls Group Cruise Control Group Transmission Group - Tuff Torq K-46BF Seat Deck & Fuel Tank Group Engine Group - 18 HP INTEK Single Cyl. Engine Group - 18 HP &...

  • Page 4: Wheels & Tires Group

    Wheels & Tires Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 5 Wheels & Tires Group Item Part No Description 1722065 WHEEL & TIRE ASSEMBLY, Front, (Includes Ref. Nos. 2, 3, 4, 5 1722838 TIRE, 15 x 6, Super Turf 1664090 TUBE, Tire, Front, 4.10/3.50 1717056 BEARING, Ball 1722837 WHEEL, 4-1/2” x 6” 2172353 VALVE STEM &...

  • Page 6: Hood, Grille & Dash Group

    Hood, Grille & Dash Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 7 Hood, Grille & Dash Group Item Part No Description 1721804 PANEL, RH Side 1721804D PANEL, RH Side, Red 1721801 HOOD, no Louvers 1721801D HOOD, no Louvers, Red 1722110 HOOD, with Louvers 1722110D HOOD, with Louvers, Red 1960295 CAPSCREW, Hex Head Flange Lock,1/4-20 x 5/8 1960392 SCREW, Phillips Head, #10-24 x 1/2 1687056...

  • Page 8: Steering Group

    Steering Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 9 Steering Group Item Part No Description 1722318 STEERING WHEEL, Straight Shaft 1725024 CAP, Steering Wheel, Plain 1960540 PIN, Spring 1722749 COVER, Black Rubber 2176440 BUSHING 1721736 PLATE, Mounting Steering 1960114 WASHER 1933260 CAPSCREW, Hex Head Flange Lock, 3/8-16 x 3/4 1931211 NUT, Hex Whiz Lock, 3/8-16 1722459...

  • Page 10: Frame & Front Axle Group

    Frame & Front Axle Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 11 Frame & Front Axle Group Item Part No Description 1930645 NUT, Hex Flange Lock, 3/8-16 1960035 WASHER 2960646 NUT, Hex Flange, 5/8-11 1722212 PLATE, Axle 1724081 TOWER & SUPPORT ASSEMBLY 1923683 CAPSCREW, Hex Head Taptite, 3/8-16 x 3/4 1723528 SUPPORT 1664847 CAPSCREW, Hex Head Taptite, 5/16-18 x 3/4 1727396...
  • Page 12 Frame & Front Axle Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 13 Frame & Front Axle Group Item Part No Description 1723502 BUMPER, Chrome, Optional 1930591 CAPSCREW, Hex Whiz Lock, 5/16-18 x 3/4 1724801 PLATE, Axle Wear 1931277 NUT, Hex Falnge Whiz Lock, 5/16-18 1722199 SPINDLE, RH 1919394 WASHER 2932577 RETAINING RING Footnotes: YARD TRACTOR ELECTRIC CLUTCH SERIES 0...

  • Page 14: Controls Group

    Controls Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 15 Controls Group Item Part No Description 1721353 ROD, Brake 1721891 KNOB, Push On, Red 1930591 CAPSCREW, Hex Head Flange Lock, 5/16-18 x 3/4 1960687 NUT, Hex Flange, 3/8-16 ESNA 1721134 PULLEY ASSEMBLY, 3 OD, W/Bearing 1667811 SPACER 1922755 WASHER, 3/8 1710545 PULLEY, Idler 4 OD 1960315...
  • Page 16 Controls Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 17 Controls Group Item Part No Description 1722083 ACTUATOR, Switch 1921333 CAPSCREW, Hex Head, 5/16-18 x 1 1722070 PEDAL, Forward 1721675 PAD, Foot Pedal Forward 1721674 PAD, Foot Pedal Reverse 1722071 PEDAL, Reverse Footnotes: YARD TRACTOR ELECTRIC CLUTCH SERIES 0 Note Manual No.

  • Page 18: Cruise Control Group

    Cruise Control Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 19 Cruise Control Group Item Part No Description 1960666 CAPSCREW, Torx Socket Head, 1/4-20 x 7/8 1722303 KNOB, Cruise 1920397 NUT, Hex ESNA Lock, 1/4-20 1723258 LEVER & BRACKET ASSEMBLY, Cruise 1960103 WASHER 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 926192 WASHER, 9/16 x 1-1/4 x 1/8 1709043 SPACER 1931342...

  • Page 20: Transmission Group - Tuff Torq K-46Bf

    Transmission Group - Tuff Torq K-46BF Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 21 Transmission Group - Tuff Torq K-46BF Item Part No Description 1960676 SCREW, Pan Head Torx Taptite, 1/4-20 x 1-1/4 1704351 FASTENER, Panel 3/4 Head 1722173 PAD, Footrest, RH Black Vinyl Textured 1722174 PAD, Footrest with Differential Lock, LH Black Vinyl Texture 1960637 NUT, Hex KEPS, 3/8-16 1928352...
  • Page 22 Transmission Group - Tuff Torq K-46BF Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 23 Transmission Group - Tuff Torq K-46BF Item Part No Description 1924940 WASHER, 3/8 1726057 ROD, Brake 1727473 ARM & PIN ASSEMBLY, Speed Control 1921333 CAPSCREW, Hex Head, 5/16-18 x 1 G5 1723267 BRACKET & PIN ASSEMBLY, Brake 1729277 SPRING, Compression 2176440 BUSHING, Nylon 2927794...

  • Page 24: Seat Deck & Fuel Tank Group

    Seat Deck & Fuel Tank Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 25 Seat Deck & Fuel Tank Group Item Part No Description 1722129 BRACKET, Seat 1725019 SEAT, 15” Back, Snapper Logo 1722128 SUPPORT, Seat 2172434 CLIP, Wire 1709256 WASHER, Spring 1714263 SPRING, Compression 1919438 NUT, Hex Lock ESNA, 5/16-18 1717051 SPRING, Compression...

  • Page 26: Engine Group - 18 Hp Intek Single Cyl

    Engine Group - 18 HP INTEK Single Cyl. Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 27 Engine Group - 18 HP INTEK Single Cyl. Item Part No Description 1723467 MUFFLER GASKET 1917356 LOCKWASHER, 5/16 2960660 CAPSCREW, Socket Head, 5/16-18 x 7/8, G8 1723165 HOSE, Oil Drain ENGINE, 18HP Briggs & Stratton INTEK Single, Model 31H777, 1722950 SEAL, Circle 1722388 BULKHEAD...

  • Page 28: Engine Group - 18 Hp & 20 Hp Vanguard Twin Cyl

    Engine Group - 18 HP & 20 HP VANGUARD Twin Cyl. Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 29 Engine Group - 18 HP & 20 HP VANGUARD Twin Cyl. Item Part No Description 1722625 MUFFLER GASKET 1917356 LOCKWASHER, 5/16 2960660 CAPSCREW, Socket Head, 5/16-18 x 7/8, G8 1728125 SCREW, Pan Head Trox, #10-32 x 5/8 1728126 CLAMP, Throttle Cable 1727696 PLATE, Limiter RPM 1723165...

  • Page 30: Lift Group

    Lift Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 31 Lift Group Item Part No Description 1722302 GRIP, Black Vinyl 1722024 ROD, Lift Lever 1930645 NUT, Hex Flange Lock, 3/8-16 1924940 WASHER 1722460 PIN, Quick 2162085 SPRING, Compression 1723866 NUT, Push, 3/8 1923341 CAPSCREW, Hex Head, 1/4-20 x 3/4 1722313 COVER, W/Lift Icon, models without cruise 1722284 QUADRANT...

  • Page 32: Mower Deck - Belt, Idle Arm & Hitch

    40" Mower Deck - Belt, Idle Arm & Hitch Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...

  • Page 33: Nut, Hex Flange Lock

    40" Mower Deck - Belt, Idle Arm & Hitch Item Part No Description 1725557 V-BELT 2101096 PULLEY, 4-1/2 OD 1919439 NUT, Hex Lock ESNA, 3/8-16 1719842 STOP, Belt 1924940 WASHER 2157081 SPACER 1719965 GRIP, Black 1720444 IDLER ARM ASSEMBLY, w/Bushings 1960614 CAPSCREW, Hex Head, 3/8-16 x 3, G8 1922755...

  • Page 34: Mower Deck - Housing, Arbors & Blade

    40" Mower Deck - Housing, Arbors & Blade Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 35 40" Mower Deck - Housing, Arbors & Blade Item Part No Description 1724600 COVER, Arbor, RH 1721132 GUARD, Extension 1675044 RIVET, Pop 1960096 WASHER 1703273 HOUSING, Arbor, Bottom w/Lube Fitting 1704314 FITTING, Lube 1722396 ARBOR SHAFT & BEARING ASSEMBLY 1707335 GASKET 1655729 HOUSING, Arbor, Top...

  • Page 36: Mower Deck - Height Adjustment & Roller Bar

    40" Mower Deck - Height Adjustment & Roller Bar Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 37 40" Mower Deck - Height Adjustment & Roller Bar Item Part No Description 1921977 CAPSCREW, Hex Head, 5/16-18 x 1-1/4 1960044 WASHER 1960236 SPACER 1723305 SHAFT & BAR ASSEMBLY 1924366 WASHER 1722036 ROLLER 1668513 ROLLER 1717675 ROLLER 1602946 SPACER 1919381 WASHER 2960643 NUT, Hex Flange Lock, 5/16-18...
  • Page 38 40" Mower Deck - Height Adjustment & Roller Bar Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 39 40" Mower Deck - Height Adjustment & Roller Bar Item Part No Description 1922606 CAPSCREW,Hex Head, 3/8-16 x 1-3/4, GR8 1915726 NUT, Hex, 5/8-11 2118053 PIN, Round Head Drilled, 3/8 x 2 1706645 TRUNNION 1920397 NUT, Hex Lock ESNA, 1/4-20 1720599 LATCH, “U”...

  • Page 40: Deflector Group

    Deflector Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 41 Deflector Group Item Part No Description 1960074 CLIP, Hair Pin 1919381 WASHER, 5/16 1723683 PIN, Clevis 1724935 DEFLECTOR & PINS ASSEMBLY 1720391 DECAL, Danger Operating without Catcher 1960252 CARRIAGE BOLT, 1/4-20 x 5/8 G5 1724864 DEFLECTOR, 16GA 1960685 NUT, Hex KEPS Conical Washer, 1/4-20 Footnotes: YARD TRACTOR ELECTRIC CLUTCH SERIES 0...

  • Page 42: Hopper Group

    Hopper Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 43 Hopper Group Item Part No Description 1727486 ROD & TABS ASSEMBLY, Bagger Front 1960685 NUT, Hex KEPS Conical Washer, 1/4-20 1960353 WASHER, 1/4 1931320 CARRIAGE BOLT, 1/4-20 x 1-1/4 1921333 CAPSCREW, Hex Head, 5/16-18 x 1 G5 1917356 LOCKWASHER, Spring 5/16 1919326 WASHER, 5/16 1931317...
  • Page 44 Hopper Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 45 Hopper Group Item Part No Description 1724652 ROD, Foot Pedal Bagger Release, 11.66 Long, 2 Bends 1919438 NUT, Hex Lock ESNA Light, 5/16-18 NC-3B 1727580 PIVOT ASSEMBLY, Latch 1928352 NUT, Hex Flange Whiz Lock, 3/8-16 Large 1921965 CAPSCREW, Hex Head, 3/8-16 x 3/4 G5 1727419 BACKPLATE ASSEMBLY 1723182...

  • Page 46: Decals Group

    Decals Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...

  • Page 47: Decals Group

    Decals Group Item Part No Description 1725240 DECAL, RD1840 1725065 DECAL, Hood Stripe, Snapper, LH 1727713 DECAL, Belt & Blade 1722806 DECAL, Ignition Switch 1723713 DECAL, Crusie / Lift 1723310 DECAL, Hopper Lever 1725061 DECAL, Snapper 1724680 DECAL, Latch Release...

  • Page 48: Electrical Group

    Electrical Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 49 Electrical Group Item Part No Description 1721810 HEADLIGHT ASSEMBLY, 4 Bulb 1722669 HARNESS, Headlight 1722887 SWITCH, PTO Push/Pull w/Symbols 1921959 CAPSCREW, Hex Head, 1/4 x 5/8 1722739 SOLENOID 1726556 MODULE, RMO (Includes Ref. No. 7) 1726557 KEY, RMO Module Plastic 1727185 KEY, w/Hang Tag for RMO Module 1722611...
  • Page 50 Electrical Group Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH TP 400-5064-IR-TC-N SERIES 0...
  • Page 51 Electrical Group Item Part No Description 1960607 PIN, Clevis 1960221 CLIP, Hair Pin 1727427 SUPPORT, Actuator 14GA, E-Coat 1960536 SCREW, Hex Washer Head Plastite, 1/4 x 1/2 1716368 SWITCH, Operator Presents, Seat 1929000 SCREW, Hex Washer Head Taptite, 1/4-20 x 3/8 1726810 BRACKET, Switch Mounting, RMO 1704379...
  • Page 54 YARD TRACTOR ELECTRIC CLUTCH HYDRO DRIVE REAR DISCHARGE RMO SERIES 0 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
