Z – Zero Turning – Hydro Drive M – Mid Mount Mower Thank you for buying a SNAPPER Product! Before operating your machine, read this manual carefully and pay particular attention to the “IMPORTANT SAFETY INSTRUCTIONS” on Pages 2 - 4. Remember that all power equipment can be dangerous if used improperly.
If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-935-2967).
Page 3
7. Evaluate the terrain to determine what accessories and attachments are needed to properly and safely perform the job. Only use accessories and attachments approved by SNAPPER. 8. Keep people and pets out of mowing area. Immediately, STOP blades, STOP engine, and STOP machine if anyone enters the area.
14. Carefully release pressure from components with stored energy. 15. Have machine serviced by an authorized SNAPPER dealer at least once a year and have the dealer install any new safety devices. Never allow untrained personnel to service machine. 16. Use only genuine SNAPPER replacement parts...
These structures, when installed and used properly can offer additional security to the operator against serious injury in the event of a tip over accident. Operator Protective Structures may be required by local ordinances. Discuss your mowing application and ordinances with your local Snapper Dealer. TABLE OF CONTENTS...
FIGURE 1.1 1.2 NOMENCLATURE The nomenclature information above, Figure 1.1, shows the essential parts of the SNAPPER MID MOUNT Z- Its purpose, aside RIDER. It is recommended that all operators of this equipment become thoroughly familiar with the controls, components, and operation of this machine before operating.
Section 2 – SAFETY MESSAGES AND SYMBOLS BLADES ENGAGED “ON” BLADES DISENGAGED “OFF” “START” “RUN” BLADE SWITCH KEYSWITCH “STOP” HOUR METER MOTION CONTROL READ OPERATOR’S MANUAL MULTI-DIRECTIONAL BEFORE OPERATING MACHINE DANGER! ROTATING BLADES KEEP CHILDREN AND OTHERS OUT OF MOWING AREA DANGER! ROTATING BLADES...
Section 3 - OPERATING INSTRUCTIONS 3.1 PRE-START CHECK LIST Make the following checks and perform the service required before each start-up. 3.1.1. Check tires and add or release air as needed to bring pressure to 12 psi in drive tires. Pressure in front deck caster wheels should be 25 psi.
Replacement of electric clutch may be necessary. Return the machine to an authorized Snapper dealer for replacement. DO NOT CONTINUE to operate mower if blades fail to stop in 7 seconds. 2. Move engine speed control to the Turtle “SLOW”...
Section 3 - OPERATING INSTRUCTIONS 3.2.5. PARKING BRAKE 1. Engage parking brake by pulling the parking brake lever back to the engaged position. NOTE: Motion control lever (joystick) must be in the Neutral position to engage brake. See Figure. 3.6. NOTE: Engaging the parking brake locks the motion control lever (joystick) in the neutral position.
Section 3 - OPERATING INSTRUCTIONS 3.3 CUTTING HEIGHT ADJUSTMENT 1. Adjust cutting height as desired to any position, using deck lift lever. See Figure 3.8. NOTE: The engine does not have to be running to adjust cutting height. DECK LIFT LEVER SHOWN IN HIGH CUTTING HEIGHT POSITION FIGURE 3.8...
Section 4 - MAINTENANCE 4.1 INTRODUCTION To retain the quality of the SNAPPER mower, use genuine SNAPPER replacement parts only. Contact a local SNAPPER dealer for parts and service assistance. For the correct part or information for a particular SNAPPER mower, always mention the model and serial number.
Section 4 - MAINTENANCE 4.2.3. CHECK MOWER DRIVE BELT 1. Foot Rest Removal a. Lower deck to lowest setting. b. Remove footrest. See Figure 4.3. c. Removal of footrest will allow access to deck belt. FIGURE 4.3 2. Check Belt Tension The idler and spring provide proper belt tension and require no adjustment.
Reinstall reservoir cap. See Figure 3.6. IMPORTANT: DO NOT remove or service the transaxle fluid filters. This service should be made periodically by an authorized SNAPPER dealer. See the service schedule to determine the recommended change interval. OIL FILL...
Section 4 - MAINTENANCE 4.5 ANNUALLY (END OF EACH SEASON) (Continued from previous Page) 4.5.2. FUEL FILTER Service fuel filter as instructed below. Turn key to “OFF” position. Engine MUST be stopped and MUST be cold before removing filter. Clamp fuel line to prevent fuel spillage or perform filter change when fuel tank and fuel line are empty.
Section 4 - MAINTENANCE 4.6 DECK REMOVAL (Continued from previous page) 4. Remove shoulder bolts, washers and nuts from front and rear lift arms. See Figure 4.10. SHOULDER BOLT, WASHER & FIGURE 4.10 5. Pull lock collar back and slide power transfer shaft away from power take off shaft (located on power unit below hydro pumps).
However, if there is difficulty in making these adjustments and repairs, it is recommended that these repairs be made by an authorized SNAPPER dealer. 5.2.1. MOWER DECK ADJUSTMENT (LEVELNESS) SIDE to SIDE and FRONT to REAR...
Page 19
Section 5 - ADJUSTMENTS & REPAIR 5.2.1. MOWER DECK ADJUSTMENT (LEVELNESS) (Continued) 6. Loosen the nuts and bolts that secure both front and rear deck support brackets on the high side of deck. Located above each support bracket, on the top part of the power unit frame, are three shim plates.
18 to 22 pounds of force to set the brake. If this adjustment does not result in proper braking action contact your authorized SNAPPER dealer for corrective action. See Figure 5.3. WARNING Do not operate this machine if the brakes are not...
Section 5 - ADJUSTMENTS & REPAIR 5.5.2. BLADE SHARPENING 1. Remove blade. See Figure 5.5. BEVELED WASHER FIGURE 5.5 2. Inspect condition of blade. See Figure 4.4. 3. If blade is in good condition, sharpen at 22 to 28 degrees. DO NOT sharpen beyond original cutting edge.
Section 5 - ADJUSTMENTS & REPAIR WARNING Shield the positive terminal with terminal cover located on battery harness. This prevents metal from touching the positive terminal, which could cause sparks. Cables must be connected to battery terminals in the proper position. RED (Positive) cable must go to the ( + ) terminal.
Section 5 - ADJUSTMENTS & REPAIR State of Charge 100% Charged w/ Sulfate Stop 100% Charged 75% Charged 50% Charged 25% Charged 0% Charged 5.7.4. BATTERY TESTING There are two types of battery tests: Unloaded and Loaded. The unloaded test is the procedure that will be discussed.
5.8 MOWER SPINDLES (Field Serviceable Spindles) BEARING REPLACEMENT In the event that a spindle bearing requires replacement, the SNAPPER Field Serviceable Spindles have been designed so that no special tools or presses are required. 1. Remove belt. Loosen blade nut and remove.
CORRECTIVE ACTION 1. Service battery. 2. Replace fuse. 3. Clean and check connections for good contact. 4. Contact authorized SNAPPER dealer. 1. Move blade engagement switch to “OFF”. 2. Set park brake. 3. Fill fuel tank with fresh fuel. 4. Move choke control to “CHOKE” position.
Page 26
5. Replace traction drive belt. 1. Move blade switch to the “ON” position. 2. Replace clutch belt. 3. Replace mower belt. 4. Contact authorized SNAPPER dealer. 5. Contact authorized SNAPPER dealer. 6. Connect power transfer shaft or repair damage. 1. Bring to proper pressure.
For two (2) years from purchase date for the original purchaser's use, SNAPPER, through any authorized SNAPPER dealer will replace, free of charge (except for taxes where applicable), any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both.
Date of Purchase _______________________________________________________ Retailer _______________________________________________________________ Retailer’s Phone Number________________________________________________ It is very important that you register your purchase with Snapper to ensure warranty coverage. Please mail your product registration card to: Snapper at P.O. Box 777, McDonough, Georgia 30253. Or you may register on line at www.snapper.com.
Read, Understand, and Follow all warnings and instructions in this manual, the engine manual, and on the machine, engine and attachments. If you have any questions about your Snapper product, contact your local authorized Snapper dealer or contact Snapper Customer Service at Snapper, McDonough, GA.
