Snapper LT300 Series Parts Manual

Yard tractor electric clutch hydro drive rmo & acs "rd"
Hide thumbs Also See for LT300 Series:
Table of Contents

Advertisement

Quick Links

Parts Manual for
YARD TRACTOR ELECTRIC CLUTCH
HYDRO DRIVE RMO & ACS "RD"
LT300 SERIES
MODEL
RD18S40 (2690624)
RD18VG40 (2690623)
RD2140 (2690763)
Briggs & Stratton Yard Power Products Group
535 Macon Road
Manual No.
7006469
McDonough, GA, 30253 U.S.A.
800-935-2967
Revision A,
9/5/2008
TP 400-5273-A-TC-N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snapper LT300 Series

Summary of Contents for Snapper LT300 Series

  • Page 1 Parts Manual for YARD TRACTOR ELECTRIC CLUTCH HYDRO DRIVE RMO & ACS "RD" LT300 SERIES MODEL RD18S40 (2690624) RD18VG40 (2690623) RD2140 (2690763) Briggs & Stratton Yard Power Products Group 535 Macon Road Manual No. 7006469 McDonough, GA, 30253 U.S.A. 800-935-2967...

  • Page 3: Table Of Contents

    40" Mower Deck - Belt, Idle Arm & Hitch 40" Mower Deck - Housing, Arbors & Blade 40" Mower Deck - Height Adjustment & Roller Bar Hopper Group Deflector Group Decals Group Electrical Group YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Table Of Contents Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 4 Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...

  • Page 5: Wheels & Tires Group

    WHEEL, 7 x 7.96, W/ 3/4 OD Shaft 1722717A WASHER, Special 1960114 WASHER, 3/4 2827794 RING, “E” External Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note (Includes Ref. Nos. 2, 3, 4, 5) (Includes Ref. Nos. 6, 15, 16 & Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 6: Hood, Grille & Dash Group

    Hood, Grille & Dash Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 7 1723451 SOCKET ASSEMBLY, Seal 1722902 REFLECTOR, Headlight Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note (Includes Ref. Nos. 22, 23 & 24) (Used only on YT & LT models) (Used only on GT models) (Used only on Barons models) (Used only on Barons models) (Used only on Barons models) Manual No.

  • Page 8: Steering Group - Manual Steering

    Steering Group - Manual Steering Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 9 SCREW, Taptite, 5/16-18 x 3/4 1726304 STEER SHAFT 1960033 HAIRPIN CLIP 1960655 CARRIAGE BOLT, 5/16-18 x 1 1/4 1960636 NUT, 5/16-18 1611710 RING, Klipring 1933988 PUSHNUT, 5/16 Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 10: Steering Group

    Steering Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 11 CAPSCREW, Hex Head Taptite, 5/16-18 x 3/4 1723604 SHAFT ASSEMBLY 1960033 PIN, Cotter 1960655 CARRIAGE BOLT, 5/16-18 x 1 1/4 1960636 NUT, Hex, 5/16-18 1611710 RING, Clipring Extension 1933988 PUSHNUT, 5/16 Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 12: Frame & Front Axle Group

    Frame & Front Axle Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 13 1721918A HOOK, “J” 1721752 SPACER 1960086 SCREW, Torx Head, 5/16-18 x 7/8 1721805A BUMPER, Black, Steel, Standard Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note (Includes Ref. Nos. 22, 26, 27) (Includes Ref. Nos. 2) Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 14 Frame & Front Axle Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 15 1930591 CAPSCREW, Hex Whiz Lock, 5/16-18 x 3/4 1724801A PLATE, Axle Wear 1931277 NUT, Hex Falnge Whiz Lock, 5/16-18 1722199 SPINDLE, RH 1919394 WASHER 2932577 RETAINING RING Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 16: Controls Group

    Controls Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 17 1919381 WASHER 1919438 NUT, Hex Lock ESNA, 5/16-18 1927557 NUT, Hex Flange Lock, 5/16-18 1722535A PEDAL, Brake 1721577 PAD, Brake Pedal 1931334 CARRIAGE BOLT, 5/16-18 x 7/8 Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 18 Controls Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 19 PAD, Foot Pedal Forward 1721674 PAD, Foot Pedal Reverse 1722071A PEDAL, Reverse 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 1931348 CARRIAGE BOLT, 3/8-16 x 3/4 1726087A SUPPORT, Idler Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 20: Cruise Control Group

    Cruise Control Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 21 SWITCH, Push, Neutral Start, Gray 1722080 SPACER 1919326 WASHER 1919381 WASHER 1919438 NUT, Hex ESNA Lock, 5/16-18 1677746 SPRING, Compression 1722460 PIN, Quick 1723099 ROD, Cruise Return Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 22: Transmission Group - Tuff Torq K-46Bf

    Transmission Group - Tuff Torq K-46BF Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 23 PIN, Cotter 1727552 SHAFT & ARMS ASSEMBLY, Control 1666697 SPACER, Powered Metal 1727407 V-BELT, Drive Belt 1924856 CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 1/2 1727215A ACTUATOR, Switch Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 24 Transmission Group - Tuff Torq K-46BF Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 25 CAPSCREW, Hex Head, 5/16-18 x 1 G5 1723267 BRACKET & PIN ASSEMBLY, Brake 1729277 SPRING, Compression 2176440 BUSHING, Nylon 2927794 RING, E Retaining 1727712 TRANSMISSION ASAEMBLY, Tuff Torq K46BF Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 26: Seat Deck & Fuel Tank Group

    Seat Deck & Fuel Tank Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 27 Seat Deck & Fuel Tank Group Item Part No Description 1722129A BRACKET, Seat 1725019 SEAT, 15” Back, Snapper Logo 1722128A SUPPORT, Seat 2172434 CLIP, Wire 1709256A WASHER, Spring 1714263 SPRING, Compression 1919438 NUT, Hex Lock ESNA, 5/16-18 1717051 SPRING, Compression...

  • Page 28: Engine Group - 18 Hp Intek Single Cyl

    Engine Group - 18 HP INTEK Single Cyl. Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 29 1722389A DUCT, Muffler Top 1723897A GUARD, Manifold Pipe 2172434 CLIP, Wire 1722390A DUCT, Muffler Extension Footnotes: Note* See your local Briggs & Stratton distributor for parts and service. YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 30 Engine Group - 18 HP & 20 HP VANGUARD Twin Cyl. Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...

  • Page 31: Engine Group - 18 Hp & 20 Hp Vanguard Twin Cyl

    NUT, Speed, 1/4-20 1935255 NUT, Speed, 5/16-18 1722389A DUCT, Muffler Top 1722390A DUCT, Muffler Extension Footnotes: Note* See your local Briggs & Stratton distributor for parts and service. YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 32: Engine & Electric Clutch Group - 21Hp Briggs & Stratton, Vanguard

    Engine & Electric Clutch Group - 21HP Briggs & Stratton, Vanguard Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 33 CAPSCREW, 3/8-16 x 1 1732396 PLATE, RMP Limiter 1728125 SCREW, Pan Head Torx 1728126 THROTTLE CABLE - Clamp Footnotes: Note* See your local Briggs & Stratton distributor for parts YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 34 40" Mower Deck - Belt, Idle Arm & Hitch Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...

  • Page 35: Mower Deck - Belt, Idle Arm & Hitch

    NUT, Spiral Flange Toplock, 3/8-16 1721425 WASHER & LOCK NUT ASSEMBLY, 3/8-16 1674671 SPRING, Extension 1726387A ARM, Idler 1666697 SPACER 1930601 CAPSCREW, Hex Head Taptite, 5/16-18 x 5/8 1724626 BELT, Timing Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 36 40" Mower Deck - Housing, Arbors & Blade Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...

  • Page 37: Mower Deck - Housing, Arbors & Blade

    1713675 WASHER, Bellville 1714419 NUT, Hex Flange 9/16-18 1726826 ARBOR SHAFT & BEARINGS ASSEMBLY, 40" 1732960A SHIM, Cover L.H. 1732961A SHIM, Cover R.H. 1732301 COVER, Arbor L.H. Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 38 40" Mower Deck - Height Adjustment & Roller Bar Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...

  • Page 39: Mower Deck - Height Adjustment & Roller Bar

    WASHER, 5/16 1933988 NUT, Push Pal 5/16 Diameter Thread 1665374 STRAP 1664847 SCREW, Hex Washer Head Taptite 5/16-18 x 3/4 1720931A BRACKET, Height of Cut 1719929 UPSTOP Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 40 40" Mower Deck - Height Adjustment & Roller Bar Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 41 CLIP, Hair Pin 1920161 NUT, Hex Jam 5/16-18 1708088A CHAIN, Link 1960033 CLIP, Hair Pin 1731382 TRUNNION 1731384 ROD, Height Adjusting 1930645 NUT, Hex Flange 3/8-16 Two-Way Lock Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 42: Hopper Group

    Hopper Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 43 WASHER, 5/16 1724651A LATCH, Release 10GA 1921333 CAPSCREW, Hex Head, 5/16-18 x 1 G5 1919326 WASHER, 5/16 1666697 SPACER, Powdered Metal 1714263 SPRING, Compression 1923360 PIN, Cotter Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 44 Hopper Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 45 1713855 KNOB, Bagger Release 1666969 PIN, Klik 5/164 1727523A HANDLE, Tube, 39.75 Long 1723359 GRIP, Hopper Lift Rod 1727406 TRANSITION, Hopper Black 1723181A BRACKET, Latch RH, 7GA Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 46: Deflector Group

    Deflector Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 47 DEFLECTOR & PINS ASSEMBLY 1720391 DECAL, Danger Operating without Catcher 1960252 CARRIAGE BOLT, 1/4-20 x 5/8 G5 1724864A DEFLECTOR, 16GA 1960685 NUT, Hex KEPS Conical Washer, 1/4-20 Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...

  • Page 48: Decals Group

    Decals Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 49 Decals Group Item Part No Description 1725128 DECAL, RD2140 1725240 DECAL, RD1840 1725065 DECAL, Hood Stripe, Snapper, LH 1727713 DECAL, Belt & Blade 1722806 DECAL, Ignition Switch 1723713 DECAL, Crusie / Lift 1723310 DECAL, Hopper Lever 1725061 DECAL, Snapper 1724680...

  • Page 50: Electrical Group

    Electrical Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 51 CARRIAGE BOLT, 1/4-20 x 5/8 G5 1727428 PIVOT, Actuator 14GA, E-Coat 1960103 WASHER, 3/8 960293 NUT, Wing Lock, 1/4-20 Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note (Includes Ref. No. 7) (Includes Ref. Nos. 1) Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 52 Electrical Group Manual No. 7006469 YARD TRACTOR ELECTRIC CLUTCH TP 400-5273-A-TC-N LT300 SERIES...
  • Page 53 CAPSCREW, Hex Head, 1/4-20 x 3/4 G5 2921319 WASHER, 1/4 2916964 LOCKWASHER, Spring 1/4 1713535 BOOT, Insulator Red, Cable Terminal 2925094 TIE, Self Locking, 7-5/16 1726889 HARNESS, Wiring Lower Footnotes: YARD TRACTOR ELECTRIC CLUTCH LT300 SERIES Note Manual No. 7006469 TP 400-5273-A-TC-N...
  • Page 56 Parts Manual for YARD TRACTOR ELECTRIC CLUTCH HYDRO DRIVE RMO & ACS "RD" LT300 SERIES IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD...

This manual is also suitable for:

Rd18vg40Rd2140Rd1840, rd18s40
