Parts Manual for
LAWN TRACTOR ELECTRIC CLUTCH
HYDRO DRIVE RMO GRAINGER
MODEL
LT2044 (2690714)
McDonough, GA, 30253 U.S.A.
Briggs & Startton Yard Power Products Group
Manual No.
7006473
Copyright ©
2007
Briggs & Startton Corporation
Milwaukee, WI USA. All Rights Reserved
Revision IR,
6/6/2007
TP 400-5278-IR-TC-N

Advertisement

Table of Contents
loading

Related Manuals for Snapper LT2044 (2690714)

Summary of Contents for Snapper LT2044 (2690714)

  • Page 1 Parts Manual for LAWN TRACTOR ELECTRIC CLUTCH HYDRO DRIVE RMO GRAINGER MODEL LT2044 (2690714) McDonough, GA, 30253 U.S.A. Briggs & Startton Yard Power Products Group Manual No. 7006473 Copyright © 2007 Briggs & Startton Corporation Milwaukee, WI USA. All Rights Reserved Revision IR, 6/6/2007 TP 400-5278-IR-TC-N...

  • Page 3: Table Of Contents

    PAGE GROUP Wheels & Tires Group Hood, Grille & Dash Group Steering Group Frame & Front Axle Group Controls Group Transmission Group Seat Deck & Fuel Tank Group Engine Group Lift Group - Manual 44" Mower Deck - Housing, Arbors & Blades Group 44"...

  • Page 4: Wheels & Tires Group

    Wheels & Tires Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 5 Wheels & Tires Group Item Part No Description 1729708 WHEEL & TIRE ASSEMBLY, Front 1731951 TIRE, Turf 15 X 6.00 - 6 Saver TL 1664090 TUBE, Tire, Front 1726301 WHEEL & BUSHINGS ASSEMBLY, Front 1713167 BEARING 2812808 FITTING, Grease, 1/4-28 Thread 2172353 VALVE STEM &...

  • Page 6: Hood, Grille & Dash Group

    Hood, Grille & Dash Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 7 Hood, Grille & Dash Group Item Part No Description 1728031D HOOD, W/Scoop 1960295 CAPSCREW, Whizlock, 1/4-20 x 5/8 1731891 DUCT, Air Inlet Plastic 1960392 SCREW, Pan Head #10-24 x 1/2 1960674 PUSH NUT 1728090 KNOB, Cruise Lock Green Plastic 1727999 COVER, Steering Shaft Plastic 1664847 CAPSCREW, Hex Head, Taptite, 5/16-18 x 3/4...

  • Page 8: Steering Group

    Steering Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 9 Steering Group Item Part No Description 1725024 CAP, Steering Wheel, Plain 1960576 NUT, Hex Lock, ESNA Light, 5/8-18, Thin 1924366 WASHER, 5/8 1728069 STEERING WHEEL, w/Aluminum Insert 1611710 RING, Klipring Extension 1960114 WASHER 1729665 BUSHING, Steering 1931277 NUT, Hex, Flange Whizlock, 5/16-18 1727940A BRACKET, Sector Support 1930591...

  • Page 10: Frame & Front Axle Group

    Frame & Front Axle Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 11 Frame & Front Axle Group Item Part No Description 1728086 PIVOT, Hood Powdered Metal 1931277 NUT, Hex, Flange Whizlock, 5/16-18 1727982A SUPPORT, Muffler, Hood 14GA 1931335 CARRIAGE BOLT, 5/16-18 x 1 1930601 SCREW, Taptite, 5/16-18 x 5/8 2860744 CAPSCREW, Hex Head, 5/8-11 x 3-1/4 G5 1960035 WASHER, Flat, 5/8 1727904A...

  • Page 12: Controls Group

    Controls Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...

  • Page 13: Controls Group

    Controls Group Item Part No Description 1727259 PAD, Foot Pedal Reverse 1960223 CARRIAGE BOLT, 5/16-18 x 1-1/4 1727935 SPACER, Pivot Powdered Metal 1727246A PEDAL, Reverse 1728024 SPACER, Foot Pedal Powdered Metal 1931277 NUT, Hex, Flange Whizlock, 5/16-18 1728025 ACTUATOR, RMO Switch 20GA 1727898 ROD, Cruise Latch, 16.97LG 1728111...

  • Page 14: Transmission Group

    Transmission Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 15 Transmission Group Item Part No Description 1664847 CAPSCREW, Hex Head, Taptite, 5/16-18 x 3/4 1931277 NUT, Hex, Flange Whizlock, 5/16-18 1728120 ROD, Bypass, 11.44 LG Yellow 1722460 PIN, Quick 1960686 NUT, Hex Flange, 5/16-18 ESNA 1727903A SUPPORT, Transmission 1930591 CAPSCREW, Hex Head, Flange Whiz Lock, 5/16-18 x 3/4 1729589 TRANSMISSION ASSEMBLY, K46HD 1960586...

  • Page 16: Seat Deck & Fuel Tank Group

    Seat Deck & Fuel Tank Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 17 Seat Deck & Fuel Tank Group Item Part No Description 1730159 SEAT, Hi Back, Steel Pan 1919381 WASHER, Plain, 5/16 1727268 LATCH, Seat 20GA E-Coat 1960667 CAPSCREW, Hex Head Flange Dog Point, 5/16-18 x 1 1731300 SPACER, 0.32 ID x 1-1/2 OD x 3/10 THK Powdered Metal Yellow 1727265A SUPPORT, Seat 12GA 1960282...

  • Page 18: Engine Group

    Engine Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...

  • Page 19: Engine Group

    Engine Group Item Part No Description * ENGINE, 20HP Briggs & Stratton (Mod. 40G777-0400-E1) 1717473 VALVE, Shut Off Oil Drain 1731970 SEAL, Short 1728058A SHIELD, Heat 1930601 SCREW, Hex Washer Head Taptite 5/16-18 x 5/8 1727997A SHIELD, Heat 1727994 MUFFLER 1727976A BRACKET, Muffler Mount 1727979...

  • Page 20: Lift Group - Manual

    Lift Group - Manual Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 21 Lift Group - Manual Item Part No Description 1730264 DECAL, Height Of Cut 1960252 CARRIAGE BOLT, 1/4-20 x 5/8 G5 1727985A QUADRANT, Lift Height 12GA 1930641 NUT, Hex Flange Whiz, 1/4-20 1722302 GRIP 1728070 ROD, Lift Handle E-Coat, 17.7 LG 1921333 CAPSCREW, Hex Head, 5/16-18 x 1 1960044...

  • Page 22: 44" Mower Deck - Housing, Arbors & Blades Group

    44" Mower Deck - Housing, Arbors & Blades Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 23 44" Mower Deck - Housing, Arbors & Blades Group Item Part No Description 1714419 NUT, Hex, Flange, 9/16-8 1713675 WASHER, Belleville 1713098 PULLEY, RH Arbor & LH Arbor, 4-1/4 1713613 HUB, Pulley, RH 1732543 SPACER 1713199A COVER, Arbor Housing 1705897 BEARING 1707335 GASKET, Foam...
  • Page 24 44" Mower Deck - Housing, Arbors & Blades Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 25 44" Mower Deck - Housing, Arbors & Blades Group Item Part No Description 1960633 BOLT Footnotes: LAWN TRACTOR ELECTRIC CLUTCH Note Manual No. 7006473 TP 400-5278-IR-TC-N...

  • Page 26: 44" Mower Deck - Belt, Idler Arm & Hitch Group

    44" Mower Deck - Belt, Idler Arm & Hitch Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 27 44" Mower Deck - Belt, Idler Arm & Hitch Group Item Part No Description 1960339 NUT, Hex Flange Center Locking, 3/8-16 1924356 WASHER, Plain, 13/32 x 1-1/2 x 1/8 1730090A ARM, Idler 7GA 1714255 SPACER 1921972 CAPSCREW, Hex Head, 3/8-16 x 2-1/2 1924940 WASHER, 3/8 2171247...

  • Page 28: 44" & 50" Mower Deck - Height Adjustment & Roller Bar Group

    44" & 50" Mower Deck - Height Adjustment & Roller Bar Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 29 44" & 50" Mower Deck - Height Adjustment & Roller Bar Group Item Part No Description 2176012 CLIP, Pin, Safety 1730221A HANGER, Front Mower 1960379 NUT, ESNA, Lock, 1/2-13 (Thin) 1679166 SPACER 1731414 PIN, Hitch 1730097 ROD, Bail Mowers Yellow 1731899A PLATE, PIVOT Lock 10 GA 1931277...

  • Page 30: Decals Group

    Decals Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 31 DECAL, Snapper, RH Hood Stripe 1722806 DECAL, Ignition Switch Symbol, White/Black 1731419 DECAL, Steering Wheel Icon 1730264 DECAL, Height of Cut 1731955 DECAL, Snapper Rear Stripe, Silver/ 8.5LG 1730202 DECAL, Transmission Tow/ Release Lever 1730172 DECAL, Fuel Level 1730170 DECAL, Tunnel 1733251...

  • Page 32: Electrical Group

    Electrical Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 33 Electrical Group Item Part No Description 1686734 SWITCH ASSEMBLY, Ignition, 6-Pole 2101025 WASHER, 5/8 1960547 LOCKWASHER, Internal Tooth, 5/8 1717549 NUT, Hex, Flange, 5/8-32 1717550 COVER, Ignition 1717163 IGNITION KEY (Set of 2) 1716951 SWITCH, Headlights, 2 Terminal 1722611 PLUG, Hole, Square 1728068 METER, Hour, LCD 1960353...
  • Page 34 Electrical Group Manual No. 7006473 LAWN TRACTOR ELECTRIC CLUTCH TP 400-5278-IR-TC-N...
  • Page 35 Electrical Group Item Part No Description 1716549 CABLE, #6 x 10 Long, with 2 Ring Terminals, Battery to Solenoid 1931277 NUT, Hex, Flange Whizlock, 5/16-18 1728026A SUPPORT, RMO Switch 1931333 CARRIAGE BOLT, 5/16-18 x 3/4 1677296 BOOT, Insulator 1685215 BATTERY 1732004 SWITCH, Push Button (NO), Reverse Pedal 2816622...
  • Page 38 Parts Manual for LAWN TRACTOR ELECTRIC CLUTCH HYDRO DRIVE RMO GRAINGER IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs &...
