- Page 1 DDC4000001 Digital Camera Model : DDC400 NOV. 2005...
-
Page 2: Table Of Contents
Contents Warning Function Test Troubleshooting Explode diagram Service Parts Lists Packing Diagram Firmware update procedure... -
Page 3: Warning
2. Warning If you are using AC power adapter, unplug the adapter from the AC power outlet after you have disconnected the camera. Do not touch the power plug during a thunderstorm if you are using the AC power adapter. This may cause an electrical shock. Do not insert or drop metallic or inflammable foreign objects into the camera through access points such as the memory card slot. -
Page 4: Function Test
3. Function Test TOOL/EQUIPMENT SD card*2, TV, AC adapter, lens-wiping paper USB cable, flower, accessory, computer OPERATION DESCRIPTION ITEM OPERATON DESCRIPTION Part I Take out the camera, open the battery cover and insert SD card. Camera cannot be powered on if insert the battery reversely. Insert battery rightly and power on. - Page 5 Make the spot test of 10 PCS from each section, trigger to take 30 pictures in forced flash mode and confirm if there is any abnormity, such as missing flash, hang on, power off automatically etc. Shift to landscape mode and take a piece of photo towards beyond (more than 3m) in flash off mode.
-
Page 6: Troubleshooting
4. Troubleshooting Item NG point NG Analyzing solution Charge Charging failure 1>. Check if connectors TP45-TP50 of J401 are Triggering cold solder, no solder, insufficient solder, System short-circuit, wrong solder, and etc. if there is any, remove the abnormity; 2>. If (1) is normal, check if U401 and related components and voltage are normal, remove the abnormity;... - Page 7 Aperture shift NG 1>. Check if lens connecting board contact NG, cold solder or insufficient solder, remove the abnormity; 2>. If (1) is normal, check if R80, R81, R82, R83, R85, R86 are cold solder or insufficient solder, remove the abnormity; 3>.
- Page 8 Power on without 1>. Check if two poles of buzzer are cold solder sound/ with or broken, remove the abnormity; abnormal sound 2>. Check if buzzer is ok, remove the abnormity; 3>. Check if R15, Q5, R8, R113 are cold solder, insufficient solder or NG, remove the abnormity.
- Page 9 Others USB connecting 1>. Check if USB connector is OK, remove the failure or can not abnormity; search the disk 2>. Check if USB_DTC related circuit is OK, remove the abnormity; 3>. Confirm if ASIC and related circuits are OK; remove the abnormity. TV play/ no sound/ 1>.
-
Page 10: Explode Diagram
5. Explode diagram 9R 744-3000 9R 747-3100 9Q 334-4600-99 9Q 344-7000 9Q 347-0100 9Q 344-8000 02411-0003-00 Reference only 9R746-6000 Part order; please refer to Sec 6 Service 9R 747-4100 Parts List Any alteration of parts number is conducted by sales representative. 9R 744-2000... -
Page 11: Service Parts Lists
6. Service Parts List Item Parts Name Pcs / set Premier P/N Remark MCU_DIP_PCB_ASY 9Q347-0100 STROBE_DIP_PCB_ASY 9R747-4100 SWITCH_DIP_PCB_ASY 9R747-3100 LENS ASSY 9R746-6000 BATTERY-HOLDER-SUB-ASM 9Q344-8000 BATTERY-COVER 9Q334-4600-99 FRONT-GRIP-SUB-ASM 9R744-2000 BACK-GRIP-SUB-ASM 9R744-3000 BATTERY-COVER-SUB-ASM 9Q344-7000 BUZZER 02411-0003-00... -
Page 12: Packing Diagram
Packing Diagram... - Page 13 Packing Part List Part name Part number HDPE BAG 04039-023-1 LB ASSURANCE TAPE 04238-765 OUT_CTN 9E539-602 PAD, VIVITAR 9E539-694 9E539-695 PAD, VIVITAR CD ROM 9P839-A00 STRAP 9Q338-000 KIT PAD 9Q339-200 9Q339-201 FCC LB 9R738-5000-00 KIT BOX 9R739-2400-00 SHEET 9R739-4800-00 9R739-4000-01 POUCH 9R739-3000-00...
-
Page 14: Firmware Update Procedure
Firmware Update Procedure To update this camera firmware, you will need to have 1. The new firmware file from Premier. 2. One SD card. 3. One card reader. Please follow the steps below to perform the update process: １. Change the update file name to “DC4345.bin”; ２.
