Snapper ER195517B Safety Instructions & Operator's Manual

Snapper ER195517B Safety Instructions & Operator's Manual

European 19” steel deck walk mowers series 17
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL DESIGNATION
CUTTING WIDTH
E – European Model
R – Recycling Model
19 – 19" Cutting Width
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 2003
SNAPPER PRODUCTS INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
E
R
19" STEEL DECK
WALK MOWERS
19
55
17
17 - Series Designation
55 – 5.5 HP (Engine Horse Power)
B – Briggs & Stratton Engine
EUROPEAN
SERIES 17
MODEL
ER195517B
B
BRIGGS & STRATTON
SERIES DESIGNATION
ENGINE HORSE POWER
MANUAL No. 7-5722 (I.R. 5/6/03)
