MODEL DESIGNATION
SELF-PROPELLED
CUTTING WIDTH
E – European Model
M – Middle Market
21 – 21" Cutting Width
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 2001
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
E
M
R
P – Self Propelled Model
R – Recycling Model
21" STEEL DECK
P
21
60
17
60 – 6.0 HP (Engine Horse Power)
17 - Series Designation
B – Briggs Engine
EUROPEAN
WALK MOWERS
"M" MODEL
SERIES 17
PROPELLED MODELS
EMRP216017B
B
SERIES DESIGNATION
ENGINE HORSE POWER
MANUAL No. 7-4268 (I.R. 1/18/01)
ENGINE TYPE
