European 21” cast aluminum deck “m” model walk mowers series 1
Hide thumbs
Table of Contents

Advertisement

Quick Links

MODEL DESIGNATION
SELF-PROPELLED
CUTTING WIDTH
E – European Model
L
Aluminum Deck Model
-
21 – 21" Cutting Width
50 - 5.0 HP (Engine Horse Power)
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense!
COPYRIGHT © 1999
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
21" CAST ALUMINUM DECK
MODEL NUMBER EXPLANATION
E
M
L
M – Middle Market
P – Self Propelled Model
WALK MOWERS
P
21
60
60 – 6.0 HP (Engine Horse Power)
1 - Series Designation
E – Electric Start Model
KW - Kawasaki Engine
V - Over Head Valve Engine
EUROPEAN
"M" MODEL
SERIES 1
SELF-PROPELLED &
ELECTRIC START
MODELS
EMLP21501KWV
EMLP21601
EMLP21601E
1
E
ENGINE OPTIONS
SERIES DESIGNATION
ENGINE HORSE POWER
MANUAL No. 4-7193 (REV. 1, 9/16/99)
