Safety Instructions & Operator's Manual for
EUROPEAN
21" CAST ALUMINUM DECK
WALK MOWERS
SERIES 3
Models
ELP21703BDV (7800255)
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Actual sustained engine power will likely be lower due to operating limitations and environmental factors. Please refer to 'Engine Power Rating Information' for
further details.
Manual No. 7101608 (I.R. 8/30/2007)
TP 100-5281-IR-WB-N
Advertisement
Table of Contents
Related Manuals for Snapper ELP21703BDV
Summary of Contents for Snapper ELP21703BDV
- Page 1 SERIES 3 Models ELP21703BDV (7800255) NOTE: Specifications are correct at time of printing and are subject to change without notice. * Actual sustained engine power will likely be lower due to operating limitations and environmental factors. Please refer to ‘Engine Power Rating Information’ for further details.
-
Page 2: Product Registration
Serial Number ______________________________________________________________ Engine Model_________________________Type__________________Trim___________________ It is very important that you register your purchase with Snapper to ensure warranty coverage. Please mail your product registration card to: Snapper at P.O. Box 777, McDonough, Georgia 30253. Or you may register online at www.snapper.com. -
Page 3: Table Of Contents
Table of Contents Operator Safety ..........2 Important Operator Safety Instructions . -
Page 4: Operator Safety
If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-935-2967). Protection for Children Tragic accidents can occur if the operator is not alert to the presence of children. -
Page 5: Operation
10. DO NOT test for spark by grounding spark plug next to spark plug hole; spark plug could ignite gas exiting engine. 11. Have machine serviced by an authorized SNAPPER dealer at least once a year and have the dealer install any new safety devices. -
Page 6: Decal Identification
Decal Identification Mfg. No. WALK BEHIND LAWN MOWER SIMPLICITY MFG - SNAPPER MCDONOUGH, GA 30253 USA (1) Serial Tag: A. Manufacturing (Part) Number B. Description/Model Number C. Serial Number D. Manufacturer Information E. Sound Power (2) Warning Instructions: A. Read, understand and follow instructions and warnings in the operator’s manual, as well as on the mower, engine and attachments before operating. - Page 7 Decal Identification (Continued) (3) Engine Speed Control: Indicates direction to increase engine RPM (rabbit), decrease engine RPM (turtle). (5) Operator Presence Control (OPC): Arrow points to the OPC bail. When bail is rotated rearward, the engine may be started and will run as indicated by the engine with rotating arrow.
-
Page 8: Features And Controls
Features and Controls IMPORTANT The figures and illustrations in this manual are provided for reference only and may differ from your specific model. Contact your Snapper dealer if you have questions. Features and Controls Oil Fill Cap and Dipstick Fuel Filler Cap... -
Page 9: Starting And Operation
Operation Pre-Start Check List Make the following checks and perform the service required before each start-up. 1. Check the guards, deflectors, grass bag, adapter, and covers to make sure all are in place and securely tightened. 2. Check the blade control (A, Figure 1), wheel drive control (B), and ground speed control (C) to insure they work freely. -
Page 10: Propelling Mower
DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. www.snapper.com... -
Page 11: Cutting Height Adjustment
Operation (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Cutting Height Adjustment 1. -
Page 12: Installing The Grass Catcher
Inspect frequently and replace worn or damaged components immediately. Grass Catcher bags used on SNAPPER products are made of woven fabric, and are subject to deterioration and wear during normal usage. Check condition of bag before each use. -
Page 13: Maintenance
Maintenance Maintenance - Introduction To retain the quality of the mower, use genuine SNAPPER replacement parts only. Contact a local SNAPPER dealer for parts and service assistance. For the correct part or information for a particular mower, always mention the model and serial number. -
Page 14: Check Mower Blade
5. Lubricate all exposed metal with a light coating of oil to prevent corrosion. 6. Loosen the handle knobs. Carefully fold the handles forward, “flexing” the control cables to prevent cable damage. 7. Store the mower in a shed or other dry area, protected from weather. www.snapper.com... -
Page 15: Mower Blade Replacement
Maintenance (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Wear heavy leather gloves when handling or working around cutting blades. -
Page 16: Wheel Drive Control Adjustment
IMPORTANT: DO NOT over-tighten the wheel drive control. DO NOT operate if the control or drive does not function properly. Contact your local SNAPPER Dealer for assistance. IMPORTANT: If the machine creeps forward after the wheel drive control is released, the cable is too tight and must be readjusted to eliminate all forward movement. -
Page 17: Belt Service
Maintenance (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Wear heavy leather gloves when handling or working around cutting blades. -
Page 18: Service Schedule
Parts Manual for 21” Cast Aluminum Deck Walk Behind Mower Series 3 REF. EACH Page 7 Page 11 Page 12 Engine Manual Engine Manual Engine Manual Engine Manual Pages 12, 15 Pages 12 - 14 Page 7 Page 11 EACH SEASON 7100999 7100976 7046518 7026428 7029492 7006204 www.snapper.com... -
Page 19: Troubleshooting
1. Damaged transmission Traction 2. Drive belt requires replacement or adjustment. 3. Insufficient lubrication in transmission/differential. 3. Contact authorized SNAPPER dealer. Cutting Grass Improperly 1. Cutting height too low or high. 2. Engine speed too slow. 3. Forward ground speed too fast. -
Page 20: Warranty
For ninety (90) days from purchase date for the original purchaser’s commercial, rental, or other non-residential use, SNAP- PER, through any authorized SNAPPER dealer will replace, free of charge, any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both. -
Page 21: Slope Guide
Slope Guide... - Page 22 Notes www.snapper.com...
- Page 23 Notes...
- Page 24 (temperature, humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this Series engine. Snapper Products 535 Macon Street McDonough, GA 30253...
