MODEL DESIGNATION
SELF PROPELLED MODEL
CUTTING WIDTH
ENGINE HP
SERIES DESIGNATION
ENGINE TYPE
ENGINE OPTIONS
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 1999
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
21" CAST ALUMINUM DECK
MODEL NUMBER EXPLANATION
E
C
L
WALK BEHIND MOWERS
COMMERCIAL MODEL
P
21
60
1
R
SERIES 1
MODELS
ECLP21601RV
V
E - European Model
C - Commercial Model
L - Aluminum Deck
P - Self-Propelled Model
21 - 21" Cutting Width
60 - 6.0 HP Engine
1 - Series Designation
R -Robin Engine
V - Over Head Valve
MANUAL No. 7-2135 (REV. 1, 9/17/99)
