Snapper ECLP21 551HV Safety Instructions & Operator's Manual

Snapper ECLP21 551HV Safety Instructions & Operator's Manual

21” cast aluminum deck walk behind mowers commercial model series 1
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL DESIGNATION
SELF PROPELLED MODEL
CUTTING WIDTH
ENGINE HP
SERIES DESIGNATION
ENGINE TYPE
ENGINE OPTIONS
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 2003
SNAPPER PRODUCTS INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
21" CAST ALUMINUM DECK
MODEL NUMBER EXPLANATION
E
C
L
P
WALK BEHIND MOWERS
COMMERCIAL MODEL
21
55
1
H
SERIES 1
MODELS
ECLP21551HV
V
E - European Model
C - Commercial Model
L - Aluminum Deck
P - Self-Propelled Model
21 - 21" Cutting Width
55 -5.5 HP Engine
1 - Series Designation
H -Honda Engine
V - Over Head Valve
MANUAL No. 7-5522 (I.R. 3/11/03)
