Snapper CLT23460, CLT24520, LT23420, LT24520, SLT23460, SLT24520 Parts Manual

Lt-100 series hydro drive electric clutch lawn tractor
Hide thumbs Also See for CLT23460, CLT24520, LT23420, LT24520, SLT23460, SLT24520:
Table of Contents

Advertisement

Quick Links

HYDRO DRIVE ELECTRIC CLUTCH
Briggs & Stratton Yard Power Products Group
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Revision E,
3/8/2008
Parts Manual for
LAWN TRACTOR
LT-100 SERIES
MODEL
CLT23460 (7800344)
CLT24520 (7800345)
LT23460 (7800207)
LT24520 (7800212)
SLT23460 (7800342)
SLT24520 (7800343)
Manual No.
TP 400-5330-E-TC-N
7006261

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLT23460, CLT24520, LT23420, LT24520, SLT23460, SLT24520 and is the answer not in the manual?

Questions and answers

Related Manuals for Snapper CLT23460, CLT24520, LT23420, LT24520, SLT23460, SLT24520

Summary of Contents for Snapper CLT23460, CLT24520, LT23420, LT24520, SLT23460, SLT24520

  • Page 1 HYDRO DRIVE ELECTRIC CLUTCH Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 Parts Manual for LAWN TRACTOR LT-100 SERIES Revision E, 3/8/2008 MODEL CLT23460 (7800344) CLT24520 (7800345) LT23460 (7800207) LT24520 (7800212) SLT23460 (7800342) SLT24520 (7800343) Manual No.

  • Page 3: Table Of Contents

    PAGE GROUP Hood / Seat Group Steering Group Main Frame Group Motion Drive Group Fuel Tank Group Engine Group 46" Mower Housing Assembly 46" Mower Deck Group 52" Mower Housing Assembly 52" Deck Blade Drive Assembly 52" Deck Housing Suspension Assembly Decals Electrical Group Wiring Schematic...
  • Page 4 Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...

  • Page 5: Hood / Seat Group

    Hood / Seat Group Item Part No Description 7091016 HWST 1/4CX5/8 721487 BEARING, STEERING 7101355 CONSOLE TRACTOR 1960392 SCREW, PHILLIPS HD 1732031 HOOD GUIDE, RH 1732030 HOOD GUIDE, LH (not shown) 1933896 NUT, HEX LOCK 10C W/ NYL INSERT BZ 7090952 SCREW, 1/4-20 THREAD CUTTING 7101493...
  • Page 6 Hood / Seat Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 7 HEADLIGHT ASSY (Includes #'s 59, 60, 61, & 62) 1728973 REFLECTOR, HEADLIGHT 1728974 LENS, HEADLIGHT 1723451 SOCKET, LIGHT 1677371 BULB, 12.8V (1141) 1728059D GRILLE, SNAPPER 7101810 INSERT, LIGHT BAR Footnotes: HYDRO DRIVE ELECTRIC CLUTCH LT-100 SERIES Note Manual No. 7006261 TP 400-5330-E-TC-N...

  • Page 8: Steering Group

    Steering Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 9 Steering Group Item Part No Description 729275 COVER, INTEGRA 727628 STEERING WHEEL (SOFT RIM) 720973 BELLOWS - STEERING POST 7101525 STEERING POST - 24.56” LONG 722867 CAPSCREW 5/16-18 721242 BEARING - LOWER 725138 GEAR PINION 720119 SNAP RING, 0.543”ID 722620 WASHER, FLAT 1.862X .765 X 16GA 721318 HUB CAP...

  • Page 10: Main Frame Group

    Main Frame Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 11 Main Frame Group Item Part No Description 7300869Z RAIL, FRAME LH 7300870Z RAIL, FRAME RH 722858 CAPSCREW 5/16-18 729075 SCREW, THREAD FORMING 10-24X.340MIN THREADS 7300876Z TOP, REAR PLATE 7300866Z PLATE, REAR 7300864Z PLATE, HITCH 7300689 PLATE, IDLER PULLEY HYDRO GEAR 7300741Z BRACKET, BATTERY SUPPORT 722616...
  • Page 12 Main Frame Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 13 Main Frame Group Item Part No Description 722580 WASHER, FLAT, 25/64 ID X 1 OD X 14 GA. 7300861Z HANGER, DECK RH 7300860Z HANGER, DECK LH 7300742Z AXLE, HANGER 720211 HHB, 5/16-24 X 2.75 BOLT 7500524 SECTOR GEAR ASSY (GEAR DRIVE - LT) 7090585 HFLN, 5/16-18 BZ 720103...

  • Page 14: Motion Drive Group

    Motion Drive Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 15 Motion Drive Group Item Part No Description 7101669 TRANSAXLE, HYDRO GEAR #310-0610 7101569 ASSY, WHEEL & TIRE, 22X9.50-12 (incl. next 3 items) 7101568 TIRE, 22X9 50-12 2PLY K358 7101567 RIM, 12X7 INT W/3 5 LG HUB SILVER 7012234 VALVE STEM, TR 412 7101563 ASSY, WHEEL &...
  • Page 16 Motion Drive Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 17 Motion Drive Group Item Part No Description 7200130 SPACER, AXLE 722598 WASHER, 3/4 I.D. x 1-1/4” Flat 7400248Z WELDMENT, FOOT CONTROL 1721675 PAD, FORWARD FOOT 720049 BOLT CARRIAGE, 5/16-18 X .62 727933 SPRING, Extension 7101454 ROD - FRONT DRIVE (3/8-24) 7500602Z WELDMENT, IDLER ARM 722451...

  • Page 18: Fuel Tank Group

    Fuel Tank Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 19 Fuel Tank Group Item Part No Description 7101521 FUEL TANK, TRACTOR W/CAP (SNAPPER) 721049 FUEL CAP 7300653Z TANK BRKT 7091016 HWST 1/4CX5/8 722866 SCREW .25-20 X0.59 HEX Footnotes: HYDRO DRIVE ELECTRIC CLUTCH LT-100 SERIES Note Was 727333 Manual No. 7006261...

  • Page 20: Engine Group

    Engine Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 21 Engine Group Item Part No Description * ENGINE, 23HP B&S ELS 2-CYL, Mod. 44L777-0125-B1 * ENGINE, 24HP B&S ELS 2-CYL, Mod. 44M777-0113-E1 720663 SCREW, TORX HEAD 5/16-18 X 5/8 YZ 721180 MUFFLER 7102402 EXHAUST TUBE RH 7102403 EXHAUST TUBE LH 1727817 THROTTLE ASSY, DUAL LEVER 720045...
  • Page 22 46" Mower Housing Assembly Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...

  • Page 23: Mower Housing Assembly

    46" Mower Housing Assembly Item Part No Description 7300671D MOWER DECK HOUSING, 46” 722397 NUT-NYLOCK RING - PULLEY 9/16-18 726069 S.S. PULLEY 46” 7101744 PULLEY 721447 JACKSHAFT HOUSING ASSY 726958 SHAFT, SPLINED 726957 BALL BEARING, JACKSHAFT 726959 JACKSHAFT HOUSING 721095 FITTING - LUBRICATION (1/4-28 Self-Tap) 720097 SHOULDER BOLT, 3/8-16X1.06...
  • Page 24 46" Mower Housing Assembly Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 25 46" Mower Housing Assembly Item Part No Description 722382 NUT, BLADE, 9/16-18 ZINC PLATE YELLOW CHROMATE 720908 GUIDE, SCREW 7300809D BRACKET, RIGHT GAUGE WHEEL 7300920D BRACKET, FRONT DECK 720053 CARRIAGE BOLT 720372 BOLT RETAINER Footnotes: HYDRO DRIVE ELECTRIC CLUTCH LT-100 SERIES Note Manual No.
  • Page 26 46" Mower Deck Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...

  • Page 27: Mower Deck Group

    46" Mower Deck Group Item Part No Description 721222 KNOB 720161 WASHER FLAT, 1.0 X .328 X 16GA 721250 FRICTION PAD 721402 PIN - HANGER 3/8-16 X 1.25 7300749D LINK, LIFT 722579 WASHER - FLAT, 1.0”OD X 0.550” 720069 HAIR PIN, .56D-.092T 720098 SHOULDER BOLT, 3/8-16 X .600OD X.95L 7300826D...
  • Page 28 46" Mower Deck Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 29 46" Mower Deck Group Item Part No Description 7300767D BRACKET, FRONT SUSPENSION 7300871D STIFFENER 720390 COTTER PIN 721453 ROLLER 720983 DEFLECTOR, INSIDE 720982 DEFLECTOR, CHUTE 720360 CAP, PUSH ON 722504 SPRING - TORSION 721017 ROD, DEFLECTOR Footnotes: HYDRO DRIVE ELECTRIC CLUTCH LT-100 SERIES Note Manual No.
  • Page 30 52" Mower Housing Assembly Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...

  • Page 31: Mower Housing Assembly

    52" Mower Housing Assembly Item Part No Description 7300937D BLADE HOUSING 52" 722858 CAPSCREW 5/16-18 720049 BOLT CARRIAGE, 5/16-18 X .62 720139 HEX NUT, 5/16-18 FLANGE SER YZ 720145 NUT, HEX FLANGE LOCK, 5/16-18 NC 7300808D BRACKET GAGE WHEEL RH REAR 720097 SHOULDER BOLT, 3/8-16X1.06 7300862D...
  • Page 32 52" Deck Blade Drive Assembly Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...

  • Page 33: Deck Blade Drive Assembly

    52" Deck Blade Drive Assembly Item Part No Description 721447 JACKSHAFT HOUSING ASSY 7300943D BRACKET, PULLEY COVER 721446 SPACER, PULLEY 726957 BALL BEARING, JACKSHAFT 726958 SHAFT, SPLINED 726959 JACKSHAFT HOUSING 721095 FITTING - LUBRICATION (1/4-28 self-Tap) 720142 NUT, HEX FLANGE, 3/8-16 NC 725179 BLADE ADAPTER 721334A...
  • Page 34 52" Deck Housing Suspension Assembly Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...

  • Page 35: Deck Housing Suspension Assembly

    52" Deck Housing Suspension Assembly Item Part No Description 721380 WINGNUT 720161 WASHER FLAT, 1.0 X .328 X 16GA 721402 PIN - HANGER 3/8-16 X 1.25 7300921D LINK, LIFT 720142 NUT, HEX FLANGE, 3/8-16 NC 720098 SHOULDER BOLT, 3/8-16 X .600OD X.95L 7300826D BRACKET, REAR SUSPENSION 721197...
  • Page 36 Decals Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...

  • Page 37: Decals

    DECAL-Umber (not shown) 7101664 DECAL-No Step (not shown) 7101665 DECAL, Danger Do Not Operate w/o Deflector (not shown) 7102210 DECAL, Height of Cut Snapper (not shown) 724023 DECAL, Deck Level (not shown) 724026 DECAL, Gage Wheel Leveling (not shown) Footnotes:...

  • Page 38: Electrical Group

    Electrical Group Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 39 Electrical Group Item Part No Description 7101446 HARNESS, WIRING, HYDRO TCT, ELEC PTO 721516 SWITCH, LIMIT, NO, SNAP-IN 721249 SWITCH, LIMIT, NO/NC, SNAP-IN 720123 WINGNUT, 1/4-20 NC-2 TAP 720349 CABLE, BAT 8GA 12.00L - BLACK 720057 CARRIAGE BOLT, 0.63L X 1/4-20 2A 720588 BOOT, BATTERY POSITIVE 720348...

  • Page 40: Wiring Schematic

    Wiring Schematic Manual No. 7006261 HYDRO DRIVE ELECTRIC CLUTCH TP 400-5330-E-TC-N LT-100 SERIES...
  • Page 41 Wiring Schematic Item Part No Description Wiring Schematic for Harness # 7101446 Footnotes: HYDRO DRIVE ELECTRIC CLUTCH LT-100 SERIES Note Manual No. 7006261 TP 400-5330-E-TC-N...
  • Page 44 IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 www.snapper.com Copyright © 2008 Briggs & Stratton Corporation Milwaukee, WI USA. All Rights Reserved Manual No. 7006261...
