Ethernet (AUI and 10BaseT) Connectors

3
Table 3-2.
Pin
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
3-14
The MVME760 provides both AUI and 10BaseT interface via the
front panel of the MVME760 transition module. The AUI interface
and the 10BaseT interface are provided through a standard 2-row
DB15 connector and an RJ45 connector respectively.
Each pin connection, signal mnemonic, and signal description for
the AUI connector is listed in Table 3-2. The AUI connector shield is
tied to chassis ground.
AUI Connector Pin Assignments (MVME760)
Signal
Mnemonic
GND SIGNAL GROUND.
C+ COLLISION + (Input) - a signal to indicate that
multiple stations are contending for access to
the transmission medium.
T+ TRANSMIT + (Output) - this line is intended to
operate into terminated transmission lines.
GND SIGNAL GROUND.
R+ RECEIVE + (Input) - a data input sourced by
the MAU.
GND SIGNAL GROUND.
Not used.
GND SIGNAL GROUND.
C- COLLISION - (Input) - part of a differential
pair.
T- TRANSMIT - (Output) - part of a differential
pair.
GND SIGNAL GROUND.
R- RECEIVE - (Input) - part of a differential pair.
+12VF +12 Vdc Power -(1.1A Polyswitch)
GND SIGNAL GROUND.
Not used.
Signal Name and Description
