EN
HORIZON DISPLAY
The integrated sensors of the camera show its orientation. These
indicators ensure exact camera orientation along the longitudinal
and transverse axes of critical objects, e.g. architecture.
▸
Select
Capture Assistants
▸
Select
in the submenu
Horizon
▸
Select
On
86
in the main menu
Two long lines to the left and right of the image center indicate the
longitudinal axis on screen.
– in zero position = green
– in tilted position = red
The transverse axis is indicated in level position by two green
double-lines immediately left and right of the image center. When
the camera is tilted, these lines are white and a short red line
appears above or below them.
