- Page 1 OPERATOR’S MANUAL 42”/48” Turbo Blower Assembly Mfg. No: 1691810 Mfg. No. 1691998 FORM 170460604 PRINTED IN U.S.A. 12/93-3ooccI...
- Page 2 HEX CAPSCREW PLAIN WASHER LOCKWASHER HEX CAPSCREW Shown below are actual size hex heads for standard screw sizes. Example: a l/4” screw has a 7116 head and.thus requires a 7716 wrench. To measure length, use the scale below. ~0000 6716” Head screw with screw with 34”...
- Page 3 Table of Contents Safety Decal ....... . Safety Rules ....... . Installation Lawn Tractor .
-
Page 4: Safety Rules
Safety Rules Read these safety rulesand the safety rules in yo,ur Operator’s Manual and follow them closely. Failure to obey these rules could result in loss of control of vehicle, severe personal injury to yourself, or damage to property or equipment. The triangle text signifies important cautions or warnings which must be followed. - Page 5 installation - Lawn ,Tractors N O T E Two spacers are packaged with turbo biower. Installation on tractor requires use of 4-l/16” spacer (see step 11); the 1/2”spacerwill not be used. 1. Remove mower deflector and arbor cover as follows: a.
- Page 6 NOTE Front belt stop should be installed facing outside of deck. ‘6. Install thefront belt stop (A, figure4) onto5/16- 18 x l-1/2 capscrew (installed in step 3) as shown. If removed, reinstall brake spring or spring anchor (F) before flange nut(G). Tighten nut (E) snug only - belt stop will be adjusted in step 8.
- Page 7 10. The baffle (A, figure 7) is installed in the blower housing for use with 42” mower. For use with 48” mower, remove the baffleand install in holes marked 48”. On42”and 48” mowersthecapscrewinstalled in next step is used in the hole occupied by a screw held in place by a retaining nut.
- Page 8 12. Install wing nut (D, figure 9) as follows: a. Remove existing hardware from front end of stone guard. b. From inside deck, install new 5/16-18 x 2-l/4 carriage bolt (F, figure 9). Then install the cup (A), 5/16 lockwasher (6). and 506 nut (C). Tighten the nut.
- Page 9 c. Place mower in low cut position. Raise the flap (A, figure 12) and push on the belt retainer (E) to obtain slack in the belt. Install the blower drive belt (D) in the top groove of pulley(B). d. Rotate the pivoting cover (A, figure 13) into place and attach the hook (B) to the clip (C) on the housing.
- Page 10 Installation - Front Cut Riders NOTES 1. Two spacers are packaged with the turbo blower. Installation on the Front-Cut Rider requires use of the l/2” spacer (see step 14). The 4-l/16” spacer will not be used. 2. The replacement right hand belt cover (seestep 15),along with thenew3/8-16x2-1M”capscrew for the right hand idler pulley (see step 4) is packaged with the collection system.
- Page 11 6. Remove the capscrew, lockwasher, and flat washer securing right hand arbor pulley. Retain the washers for reinstallation (step 9). Use a wood block to prevent blade from turning. SunRunnerNanguard Models 6. On early models without bet stop (A, figure 3) remove two self-tapping screws from arbor and install two .5/l 6-18 x l-1/2”...
- Page 12 9. Slip the mower drive belt (A, figure 5) around the bottom groove of double-groove pulley (B). Install pulley with hub down and secure with new 7/l 6-14 x 2-l /4” capscrew (D and E) removed in step 5. Make sure splines arecorrectlyalignedand torquecapscrewto55- 60 ft.
- Page 13 13. Install the new baffle (A, figure 8) in deck on stone guard using existing hardware. Hardware may be installed with nut to inside or nut to outside. 14. On new arbor cover, install on top of weld bolt (A, figure 9) the largest washer (B l-i/Z”...
- Page 14 16. Make sure that flat washer (F, figure 9) is on top of spacer assembly and install new arbor belt cover (A, figure 10) as shown in figure 10. Secure with flat washer (l-1/4” O.D.) and locknut (8). Belt cover should be free to pivot.
- Page 15 Operation WARNING For safety reasons, grass and debris should not be removed from any part of turbo or collection system until engine is shut off, key removed, and all moving parts have stopped. WARNING Before raising cart or twin-bag cover, shut off engine, remove key, and set parking brake.
- Page 18 .:::).‘,:,:::: ~._,,...
- Page 19 SIZE 8-32 8-36 lo-24 lo-32 l/4-20 l/4-28 5116-18 5116-24 318-16 318-24 7116-14 7116-20 l/2-13 112-20 9116-12 9116-18 518-11 518-18 314-10 3/4-16 718-g 718-14 1-12 NOTE: 1. These torque values are to be used for all hardware excluding: locknuts, self-tapping screws, thread forming screws, sheet metal screws and socket head setscrews.
