Important:
0
Each time after spray vacuum cleaning the
vacuuming hose should be cleaned of particles
of dirt and fluff if necessary.

Dismantling the spray vacuuming components

(Detach the spray suction nozzle's pressure hose
0
from the shut-off valve by turning the coupling
piece anti-clockwise to unlock it.
Pull the shut-off valve out of the track located
on the vacuuming pipe or on the spray suction
nozzle for upholstery. Remove the spray suction
nozzle from the vacuuming pipe or handle.
0 Detach the pressure hose from the motor head
by actuating the quick disconnect coupler's
release button so that the connecting piece for
the pressure hose detaches itself.
Remove the clips from the vacuuming hose.
Prior to being reassembled, all appliance parts
0
must be totally dry.
Coil the cable in large loops and hang it on the
cable cradle located on the carry handle.
52
