Working with the nozzles when spray vacuuming

The nozzles are all attached to the vacuuming pipe by pressing and
twisting and are removed by pulling and twisting.
Spray suction nozzle for carpet
For using water when cleaning carpeting
0 Attach the wide transparent nozzle to the end of
the lower vacuuming pipe press the pressure
hose attached to it into the clamping pieces
located on the vacuuming pipes or secure the
pressure hose to the stainless steel pipe using
pipe clips.
0 Attach the coupling piece located at the upper
end of the pressure hose to the shut-off valve
and lock it by turning it clockwise.
To detach the pressure hose from the shut-off
valve, turn the coupling piece anti-clockwise to
unlock it and remove it from the shut-off valve.

Hard flooring adapter

For using water when cleaning hard floors made
of ceramic, stone or synthetic materials.
48
