- Page 1 ELECTRONIC TYPEWRITER Wordsmith 200 Instruction Manual Designs and specifications are subject to change without notice.
-
Page 2: Parts Description
PARTS DESCRIPTION PLATEN KNOB PRINT CARRIER TOP COVER PLATEN PAPER BAIL POWER SWITCH PAPER RELEASE LEVER PRINT COVER KEYBOARD COVER LCD LCD CONTRAST ADJUSTER POWER SWITCH PRINT WHEEL PRINT WHEEL RELEASE LEVER PRINT WHEEL COVER RIBBON GUIDE PRINT HAMMER BRACKET RIBBON CORRECTION TAPE... -
Page 3: Keyboard Layout
KEYBOARD LAYOUT 1. * MARGIN RELEASE 12. * IMPRESSION SET 13. * LINE SPACE SET 14. * PITCH SET 15. * INDENT SET/CLEAR 16. * SPELL CHECK ON/OFF 17. * TW/WP MODE SET 18. * MODE SET 19. * STATUS 10. -
Page 4: Table Of Contents
CONNECT POWER ... 4 Setting ... 4 CHANGING ... 5 Changing The Ribbon Cassette ... 5 Changing The Print Wheel ... 5 Changing The Correction Tape ... 6 BASIC FEATURES Selecting Pitch ... 7 Selecting Line Spacing ... 7 Setting Impression ... 7 Setting Margins ... -
Page 5: Connect Power
CONNECT POWER Power cord is located in the compartment located at the rear of the typewriter. And the power switch is located on the right side of typewriter near the rear. 1) Pull down the rear compartment door and connect the power cord to a proper AC outlet. -
Page 6: Changing
CHANGING Changing The Ribbon Cassette 1) Move the print carrier to the center of the platen using the 2) Hold the ribbon cassette on both sides and lift up the front portion (where the ribbon is exposed) to remove the cassette. 3) To insert a new cassette, place the back end of the cassette on the cassette holder on the carrier and gently press down on the front of the cassette unit it clicks into place. -
Page 7: Changing The Correction Tape
Changing The Correction Tape 1) Move the print carrier to the center of the platen using the 2) To replace the correction tape, lift out the typing ribbon cassette (see Changing The Ribbon Cassette) and remove the two spools of the lift off tape by pulling them outwards. -
Page 8: Basic Features
BASIC FEATURES Selecting Pitch There are three pitches available for typing the change the typing pitch. When the typewriter is turned on. PICA mode is selected. The selection sequence is the following: PICA ELITE MICRO The chosen pitch will be displayed. -
Page 9: Shift And Shift Lock
• Margin Release To move the carrier or type a character beyond margins press the (MARGIN RELEASE) key. • Hot Zone The hot zone starts six (6) spaces before the right margin. A beep will sound when the hot zone is reached. Shift and Shift Lock To type uppercase characters or symbols, press either the left or right For continuous upper case typing, press the... -
Page 10: Backspacing
Backspacing There are three different backspace function. • Backspace To move the carrier or cursor one space backward, press the • Micro Backspace Press the CODE MICRO (1/60 inch) • Express To move carrier or cursor to the left margin, press the Index &... -
Page 11: Tab
2) Type the text. The characters you type will be displayed. 3) To print the text, press the Right Margin Flush Your typewriter can automatically Print the text flush with the right margin. 1) Press the CODE The carrier will move to the right margin. -
Page 12: Correction
CORRECTION Your typewriter has a one line correction memory. You can automatically correct any mis-typed character within the correction memory. Correcting One Character To correct the last typed character, press the The carrier will then be backspaced and the character will be erased. -
Page 13: Advanced Operation
ADVANCED OPERATION There are three advanced modes in your typewriter: AUTO, LP and JUST. The mode is changed circularly when you press the quence is following: AUTO JUST AUTO (Automatic Return Mode) In this mode, the carrier will automatically returned to the left margin every time bar or the HYPHEN key is pressed in the hot zone. -
Page 14: Word Processor Mode
WORD PROCESSOR MODE Pre-Description The WP mode will make your typing easier and more efficient. Repetitive phrases, terminology and entire letters can be stored, edited and recalled (printed) at will. There are six sub-modes in WP mode. They are dp, np, edit, prn, Is and del. You can toggle between WP and TW modes by pressing the 1 : dp 4 : prn... -
Page 15: Prn (Print)
4. prn (Print) If you press the key, you an print a file. The first file name will be displayed. Press key to select or the cursor key ( RETURN use cursor & RET utilisez le curseur et RET nom: aaa name: aaa After selecting the printing file, the following message will be displayed. -
Page 16: Mark Begin
(MARK) key. (MARK) key. key, and the typewriter will switch to insert mode. In key again to go back to replace mode. In this mode -15-... -
Page 17: Cursor Movement
5. Cursor Movement • One character left: • One line up: INDEX • To the first column: CODE of the current line • To the start of file: CODE 6. Search To search a text press the the display for which text you would like to search. Type the Text, then press the key. -
Page 18: Trouble Shooting
If any operating difficulties arise, check the list below before returning your typewriter for service. 1. Typewriter remains at a stand with the - Make sure the power cord is still power switch set to on. 2. Printing is faint or does not appear. -
Page 19: Specification
* NOTE: The power source is adjusted by manufacturer according to the power regulation of final destination. * NOTE: POWER CORD (New Zealand Only) If the electrical supply cord of this typewriter is damaged, it must be replaced by the special cord SP-502. 12 “ (305 mm) 9 “... - Page 20 Smith Corona Corporation 842 Bennie Road P.O. Box 2090 Cortland, NY 13045-2090 1-800-448-1018 7301171...
