- Page 1 CVMDP-1080P CV/SV to Full HD Mini DisplayPort Scaler Operation Manual CVMDP-1080P...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 3 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
Table of Contents Introduction…………………………………………………..………. Applications……………………..…………………………....…. Package Contents…………………………..…………….....… System Requirements……...…………………..….…………..……. Features……………………………………………..……..……… Specifications..………………………………………...………...…. Operation Controls and Functions………………...……..……… Front Panel ................Rear Panel …………………………………………..……..… Connection and Installation …….…………………..…..…..…... Output Resolution Chart…………………………………..……..…... -
Page 5: Introduction
1. Introduction This scaler box is designed to display your Composite video/S-Video images on the Mini DisplayPort with better viewing resolutions. It can upscale any Composite video/S-Video ’ s input source into Mini DisplayPort output with wide- range resolutions. Additionally, this device can also transfer audio for user to enjoy both HD images and sound consistently. -
Page 6: Specifications
6. Specifications Input Ports Composite video/S-Video, Audio R/L RCA jack Output Ports Mini DisplayPort, R/L phone jack Output Resolution VGA, 480p, 576p, 720p,1080i and 1080p@50/60 Input signal levels Video at 1 Vp-p, 75 Ω Y: 1.0 Vp-p(75 Ω ) C: 0.286 Vp-p(75 Ω ) Audio R/L: 0.5Vrms Video System NTSC, PAL... -
Page 7: Operation Controls And Functions
7. Operation Controls and Functions The following sections describe the hardware components of the unit. 7.1 Front Panel POWER button: Press this button once to power on the unit, press again ① to power off. This device has last memory ’ s function and will record your last input selection. -
Page 8: Connection And Installation
8. Connection and Installation DVD / Vido player LCD TV / HD MONITOR i Pod/itoch 9. Output Resolution Chart Mini DisplayPort output resolution 640 X 480 60HZ 480P 720 X 480 60HZ 576P 720 X 576 50HZ 720P 1280 X 720 60HZ / 50HZ 1080I 1920 X 1080... - Page 9 Acronyms Acronym Complete Term Composite video S-Video HDTV High-Definition Television NTSC National Television System Committee Phase Alternating Line High Quality Image enhancer Three-Dimensional...
- Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20091109 MPM-CVMDP1080P...
