- Page 1 Instructions for Use Washing machine...
-
Page 2: Table Of Contents
Thank you for your confidence in purchasing our washing machine, and congratulations on the excellent choice. Your new washing machine meets the requirements of modern treatment of laundry. It is rational in the consumption of energy, water and washing agents. Our appliances are friendly to the environment. -
Page 3: Description Of Washing Machine
Description of washing machine 1. Front panel 2. Detergent dispenser 3. Door 4. Filter lid Technical information (depending on model) 5. Adjustable legs 6. Water outlet hose 7. Water inlet hose 8. Mains power cable Dimensions (w x d x h): 600 mm x 600 mm x 850 mm Depth with door open: 106 cm Weight (net): 90 kg... -
Page 4: Cautions
Cautions • Be sure to remove transport brackets prior first use of the appliance. Attempted operation of the blocked machine may result in irreparable damage which is not covered by the manufacturer’s warranty! • When connecting your washing machine to water supply, be sure to use brand new water inlet hose and appropriate sealing gaskets (attached). • Do not locate the machine in a room with temperature below 0°C. Parts of the machine may be damaged if frozen. • Install the washing machine in a perfectly horizontal position, on solid flat concrete floor. • Follow the instructions for correct installation and water and mains connections. • Never immerse the end of the drain hose into the draining water. • Prior starting the washing cycle lock the door by pressing them at the designed spot. • Door may not be open during the washing cycle. • Use only detergents and softeners for machine wash. Manufacturer may not assume responsibility for any damage and eventual discoloring of gaskets and plastic components as a consequence of incorrect use of bleach and/or coloring agents. •... - Page 5 Before connecting the appliance read these instructions carefully. Repairing the failure arising from inappropriate connections or use of the appliance is not covered by the guarantee. The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic...
-
Page 6: Installation And Connection
Installation and connection Package removal Removal of transport brackets In removing the wrapping be careful not to damage the appliance with a sharp object. Before connecting the appliance, let it warm up to room temperature (wait for two hours). • Our appliances are packed in environmentally friendly materials which may be recycled, deposited or decomposed without any threat to... - Page 7 Leveling the appliance Water inlet connection • Put the appliance in horizontal position by turning the adjustable legs. The legs are adjustable up to +/- 1 cm. After the adjustment tighten the nuts firmly (A) - towards the bottom of the machine! Vibrations, moving of the appliance and loud operation due to incorrect setting of the adjustable feet shall not be covered by this warranty.
- Page 8 Water outlet connection Connect the appliance to the mains supply • Fix the outlet hose to run into the sink or the bathtub, or connect it directly to the wall drain outlet (diameter min. cm). • Wall drain must be installed properly and must enable occasional cleaning. • Fasten the outlet hose support with a piece of rope led through the hose elbow, to prevent the hose from slipping to the floor.
-
Page 10: Operation
Operation A - program selector B - Rinse hold button C - START/PAUSE button Washing procedure Signal LED’s: - ON/OFF (orange) • Open the door of the machine • Load the laundry into the drum • Close the door • Open the water inlet faucet • Select the program • Add washing and treatment agents (detergent and softener) •... - Page 11 Washing machine Washing machine operation operation Pay attention to the labels on the clothes, indicating the recommending washing mode (see table of textile treatment symbols on the last page of these instructions). Program is selected by turning the program selector (A) from the “0” position to the desired washing program. The ON/OFF signal LED starts flashing. The program selector (A) may be turned in both directions, and the appropriate program selected according to the type of laundry washed and the required washing temperature (see Program Chart for help). You may select basic or partial programs.
- Page 12 skirts, blouses) and curtains. Wool Especially gentle program for washing wool and garments made from mixture of other fabrics with wool, appropriately marked for machine washing. - Selection of additional function Rinse hold • This function is switched on after the selection of a basic program by pressing the button (B). It may also be switched on during the operation, prior last rinse. Indicator LED above the button is on. • The function is switched off by pressing the same button again - signal LED is off. • The program stops at the end of last rinse, prior spinning: laundry remains soaked in water and prevents crease, if you are unable to remove it from the drum immediately after the end of washing cycle. Indicator LED above the button is flashing. • The selected program is completed by pushing the START/PAUSE button (C), but you may also apply additional programs (drain or spin), but you must first return the program selector to the “0”...
- Page 13 Rinse Independent program for rinsing delicate laundry, without intermediate spinning and with short final spin. You may use it for rinsing manually washed delicate laundry or for extra rinsing for people with skin sensitive to detergents. Softener This program is intended for softening, bleaching or impregnating of washed laundry. It is completed with spinning at max. 1000 RPM. Rinse hold Use it when the washing program was interrupted or if drain function was engaged, and you only wish to the water out of the drum, without spinning. Spin Intensive spinning for non-delicate laundry at high spin RMP. - Adding washing and softening agents (see Tips for washing and energy saving) •...
- Page 14 Start the operation Start the operation Interruptions Interruptions • Push the START/PAUSE button (C). The ON/OFF LED stops flashing, the machine starts operating after a few seconds. If the door is not properly closed after starting the operation, the ON/OFF LED starts flashing again after a few seconds. When you close the door, the machine initiates the selected program. • In case you would like to alter the washing program after the initiated washing operation, turn the program selector for one second to the position “0”, followed by the selection of a new program. Switching the machine off deletes any previously selected additional functions - Rinse hold, so they have to be reactivated. - End of operation Flashing ON/OFF LED indicates that the program was completed. • Extract the laundry from the drum and remove any alien objects from the door gasket. • Leave the door ajar to allow the interior to dry. • Close the water inlet faucet. •...
- Page 15 spin) to empty the water and terminate the program. Pause button By pressing the START/PAUSE button (C) program may be suspended at any time. After certain time you may open the door if there is no water in the drum, otherwise this is not possible. Program is continued by pressing the START/PAUSE button (C). • Failures Program is suspended in case a failure occurs. Signal LED’s are flashing (see cf. Troubleshooting). • Power failure At electric cutout the program is interrupted, however, after the power supply has been re- established, the program operation automatically proceeds. If a power failure occurs when the drum is still full of water, be careful not to open the door before you pump the water out.
-
Page 16: Tips For Washing And Energy Saving
Tips for washing and energy saving • Before washing sort out the laundry according to the type, degree of dirtiness and color fastness. • Prior selecting the washing program consult the sewn tab with information on a particular piece of laundry (see Maintenance chart on the last page). • Wash separately the new colored textile products for the first time. • Wash heavily soiled laundry in small quantities or add more detergent. • Treat stubborn stains with special stain remover, it will save energy. - Page 17 Hardness Degree of hardness scale °dH(°N) 1 - Soft 2 - Medium 7-14 3 - Hard 14-21 4 - Extra hard >21 In case of hard water add detergent according to the Chart for degree 1 and add appropriate quantity of water softener (see manufacturer’s instructions). • If you do not apply the program which includes the pre-wash feature, you may add washing detergent directly into the drum. • If you use thick liquid softener it is recommended to dilute it with water, to prevent clogging of dispenser compartment ducts. • Washing machine is equipped with the dispenser partition gate, so you may pour liquid detergent also into the central compartment. If you use powder detergent the gate is lifted up, and in case of liquid detergent it is slid down. • Liquid detergents are intended for main wash only, without pre-wash.
-
Page 18: Cleaning And Maintenance
Cleaning and maintenance Disconnect the washing machine from the mains before cleaning! • The casing should be cleaned with soft cloth and mild detergent. • The interior of the drum and the door gasket is cleaned by washing at 60°C without laundry and adding half quantity of detergent. • If necessary, clean the detergent dispenser. Pull it out from its casing completely by pressing the flap (see Fig.). • If necessary, clean the cover of the bung under the running water. - Page 19 • Wash it under running water using a brush, and dry it. Remove any leftover dried detergent from the bottom of the casing. • Clean the entire rinsing area of the washing machine with a brush, especially the nozzles on the upper side of the rinsing chamber. • Clean frequently the water inlet hose screen under running water. • After each wash wipe the door rubber gasket. This will prolong its useful life. • Open the filter lid using flat screwdriver or similar tool. • Filter needs occasional cleaning, especially following heavily shaggy or old laundry. Before cleaning, drain any water from the machine via drain pipe.
- Page 20 • Turn it anti-clockwise, pull it out and clean under running water. • Insert the filter back as shown on the picture (arrow and pointer), and tighten by turning it in clockwise direction. To ensure good sealing the gasket surface (A) must be dirt free.
-
Page 21: Failures
Failures The washing machine automatically monitors the execution of particular functions during the operation, and reports any detected failures. In such cases both signal LED’s start flashing in certain sequence. Flashing sequence changes in accordance with the nature of the detected failure. In some cases you may attempt removing certain failures yourself, so count the number of flashes, repeating after certain pauses. The machine signals failures immediately after detecting them and stops the program, except for heater failure, where the machine completes the washing program without heating water. Failures: In certain cases you may remove the failure yourself: 2 - two flashes: door is not correctly closed; 3 - three flashes: inappropriate water intake; 7 - seven flashes: inappropriate water outlet. In all other instances mark the number of flashes indicating the failure, switch off the machine and call nearest authorized service center (LED’s continue flashing until you switch the machine off). Interferences from the ambient (for example electrical wiring) could induce signalization of different faults. In such cases: - switch the appliance off, and wait for a few seconds; - switch the appliance back on and repeat the washing program. If the fault repeats, call authorized service shop. Warranty shall not apply in case of failures due to interferences from the environment (lightning stroke, power supply circuit faults, natural disasters). - Page 22 Failure Possible cause The machine does not Machine is not powered. work (symbols are not illuminated). Washing program Door is not properly closed. does not start (ON/ OFF LED is flashing). Water does not enter the Disturbed water inlet. machine (after approx. 8 min the machine reports failure -3 flashes). Water is leaking from Filter is not tightly screwed in. the machine. Inlet pipe is not tightly screwed to the machine or to the water faucet.
- Page 23 Failure Possible cause Laundry is stained You used liquid detergent or after washing. detergent for colored laundry which does not contain whitener. White powdery It is not the consequence of bad residues on the rinsing, but because of neo- laundry. phosphate detergents containing non soluble components (zeolites) for water softening. Such substances may be deposited upon the laundry. Detergent residues in Low water flow pressure. the dispenser. Some detergents may stick to the dispenser rather hard if it is wet. Softener is not Sucking cover is not correctly completely rinsed, positioned or is clogged.
-
Page 24: Tables
Tables Program chart - 6 kg Basic program Cotton - white Cotton - color Cotton + prewash Cotton Cotton - quick wash Synthetic Synthetic Synthetic - quick wash Delicate Delicate Wool Partial programs Rinse Softener Drain Spin possible Water cons. 1200 1000 1000 1300 Energy cons. 2,10 1,1 ... -
Page 25: Maintenance Chart
Maintenance chart Normal wash Max. washing temp. 95°C Delicate wash Whitening Whitening in cold water Ironing Hot iron max. 200°C Dry cleaning Dry cleaning in all solvents Drying Place on flat surface Max. Max. Max. washing washing washing temp. temp. temp. 60°C 0°C 30°C Hot iron max. Hot iron max.
