6GB10055.fm Page 1 Monday, August 2, 2004 12:33 PM
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Smeg S 800 TL

Summary of Contents for Smeg S 800 TL

  • Page 1: Table Of Contents

    6GB10055.fm Page 1 Monday, August 2, 2004 12:33 PM CONTENTS BEFORE USING THE WASHING MACHINE FIRST WASH CYCLE PRECAUTIONS AND GENERAL RECOMMENDATIONS DESCRIPTION OF THE WASHING MACHINE PREPARATION OF THE WASHING DETERGENTS AND ADDITIVES PROGRAMME SELECTION CLEANING THE FOREIGN BODY TRAP DRAINING RESIDUAL WATER CARE AND MAINTENANCE TROUBLESHOOTING GUIDE...

  • Page 2: Before Using The Washing Machine

    6GB10055.fm Page 2 Monday, August 2, 2004 12:33 PM BEFORE USING THE WASHING MACHINE 1.Remove the packaging and check a. Cut and remove the shrink-wrap. b. Remove the top protection and the protective corners. c. Remove the bottom protection by tilting and turning the washing machine on one rear bottom corner.

  • Page 3: First Wash Cycle

    6GB10055.fm Page 3 Monday, August 2, 2004 12:33 PM FIRST WASH CYCLE We recommend that the first wash cycle be carried out empty. This will remove any residual water used in the factory checks. 1. Turn on the tap. 2. Close the drum flaps. 3.

  • Page 4: Description Of The Washing Machine

    6GB10055.fm Page 4 Monday, August 2, 2004 12:33 PM DESCRIPTION OF THE WASHING MACHINE 1. Lid 2. Detergent dispenser 3. Drum flaps 4. Pump and foreign body trap 5. After-Sales Service sticker (behind the foreign body trap cover) 6. Mobility lever (depending on model) •...
  • Page 5 6GB10055.fm Page 5 Monday, August 2, 2004 12:33 PM Stain removal • Blood, milk, egg and other organic substances are generally removed by the enzyme phase of the programme. • To remove red wine, coffee, tea, grass and fruit stains etc. add a stain removing agent in detergents dispenser compartment chlorine bleach in compartment on model).
  • Page 6 6GB10055.fm Page 6 Monday, August 2, 2004 12:33 PM Loading the laundry 1. Open the machine lid. 2. Open the drum by pressing the button and keep your second hand on the big drum door at the same time. 3. Place the items of laundry in the drum one by one without compressing them.

  • Page 7: Detergents And Additives

    6GB10055.fm Page 7 Monday, August 2, 2004 12:33 PM DETERGENTS AND ADDITIVES Choice of the right detergents and additives The type of detergent depends on: • type of fabric (cottons, easy care/synthetics, delicate items, wool). Note: use only specific detergents for wool. •...

  • Page 8: Programme Selection

    6GB10055.fm Page 8 Monday, August 2, 2004 12:33 PM PROGRAMME SELECTION Preparation of wash cycle 1. Load the machine, close the drum flaps and check that they are properly locked. 2. Add detergents and additives into the dispenser to no more than the “MAX” level mark. Please refer to “Detergents and additives”.

  • Page 9: Cleaning The Foreign Body Trap

    6GB10055.fm Page 9 Monday, August 2, 2004 12:33 PM CLEANING THE FOREIGN BODY TRAP The washing machine is provided with a self-cleaning pump. The foreign body trap keeps objects like buttons, coins, safety-pins etc. which have been left in the laundry. 1.

  • Page 10: Draining Residual Water

    6GB10055.fm Page 10 Monday, August 2, 2004 12:33 PM DRAINING RESIDUAL WATER When should I drain residual water (draining problem)? • Before transporting (moving) the machine. • If the washing machine is installed in a room subject to sub- zero temperatures. It is best in this case to drain the machine after every wash.
  • Page 11 6GB10055.fm Page 11 Monday, August 2, 2004 12:33 PM Water inlet hose filter Check and clean regularly (at least two or three times a year). 1. Unplug the washing machine. 2. Turn off the tap. 3. Unscrew the hose from the tap. 4.

  • Page 12: Troubleshooting Guide

    6GB10055.fm Page 12 Monday, August 2, 2004 12:33 PM Washing machine exterior and control panel • Clean with a soft damp cloth. • If necessary, a neutral household cleaner can be applied (do not use aggressive or abrasive products). TROUBLESHOOTING GUIDE This washing machine is equipped with automatic safety functions which detect and diagnose faults at an early stage and allow you to react appropriately.
  • Page 13 6GB10055.fm Page 13 Monday, August 2, 2004 12:33 PM *Final spin results are poor. Note: the washing machine has an unbalance detection and correction system. If individual heavy items are loaded (a bathrobe, for example), this system may reduce the spin speed automatically or interrupt the spin if it detects too great unbalance at the start of the spin, in order to protect the washing machine.

  • Page 14: After-Sales Service

    6GB10055.fm Page 14 Monday, August 2, 2004 12:33 PM AFTER-SALES SERVICE Before contacting After-Sales Service: 1. Try to remedy the problem yourself (see “Troubleshooting Guide”). 2. Restart the programme to check whether the problem has solved itself. 3. If the machine continues to function incorrectly, call After-Sales Service.

  • Page 15: Installation

    6GB10055.fm Page 15 Monday, August 2, 2004 12:33 PM INSTALLATION Removal of transport bracket The washing machine is fitted with a transport bracket to avoid any possible damage during transport. Before using the washing machine, the transport bracket at the back MUST be removed. 1.
  • Page 16 6GB10055.fm Page 16 Monday, August 2, 2004 12:33 PM Adjust the feet Install the washing machine on a level surface, near to electrical, water and drain connections. If the floor is uneven, adjust the feet (do not insert pieces of wood, cardboard etc.
  • Page 17 6GB10055.fm Page 17 Monday, August 2, 2004 12:33 PM Water stop anti-flooding system (depending on model) • Screw the hose to the water supply tap. Turn the tap fully on and check the water-tightness of the connection. • The washing machine must not be connected to the mixing tap of a non-pressurized water heater! •...

  • Page 18: Electrical Connection

    6GB10055.fm Page 18 Monday, August 2, 2004 12:33 PM ELECTRICAL CONNECTION Do not use extension leads or multi sockets. Electrical connections must be made in accordance with local regulations. 1) Warning - this appliance must be earthed This appliance is normally supplied with a mains lead having a plug fitted in the factory which has been checked for correct earth continuity.
  • Page 19 S 800 TL Care Programme Labels Cotton with Prelavaggio Heavily soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and linen. prewash cotone Synthetic with Prelavaggio Heavily soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira), polyamide (Perlon, prewash sintetici Nylon) or blends with cotton.
  • Page 20 CONSUMPTION DATA Temperature Load Selector Programme (°C) (kg) Cotton Cotton Cotton Synthetic Synthetic Delicate Wool Silk Prewash cycle increases programme duration approximately 15 min. Consumption values were measured in normalized conditions in compliance with standard IEC/EN 60 456. Consumption data in the home may vary with respect to the values in the table in relation to the water supply pressure and temperature, the load and the type of wash.
