1
INSTRUCTIONS FOR SAFE AND PROPER USE _______________________________34
2
INSTALLATION OF THE APPLIANCE_________________________________________36
3
DESCRIPTION OF CONTROLS _____________________________________________38
4
USE OF THE COOKING HOB _______________________________________________40
5
USE OF THE OVEN _______________________________________________________41
6
ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) __________________43
7
CLEANING AND MAINTENANCE ____________________________________________45
8
EXTRAORDINARY MAINTENANCE __________________________________________47
THESE INSTRUCTIONS ARE VALID ONLY FOR THE END USER COUNTRIES WHOSE
IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS MANUAL.
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified technician who must carry out a
suitable check of the gas system, install the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice, description of the commands and the
correct procedures for cleaning and maintenance of the appliance.
@
Further information about the products can be found at www.smeg.com
Index
33
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Smeg SCB66MFB
Summary of Contents for Smeg SCB66MFB
-
Page 1: Table Of Contents
INSTRUCTIONS FOR THE USER: these contain user advice, description of the commands and the correct procedures for cleaning and maintenance of the appliance. Further information about the products can be found at www.smeg.com Index... -
Page 2: Instructions For Safe And Proper Use
Introduction 1 INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKER. - Page 3 Introduction THE APPLIANCE IS DESIGNED FOR USE BY ADULTS. DO NOT ALLOW CHILDREN TO GO NEAR OR PLAY WITH IT. IF THE APPLIANCE IS TO BE POSITIONED ON A PLATFORM IT MUST BE INSTALLED IN SUCH A WAY AS TO PREVENT IT FROM SLIPPING OFF THE FORMER. ATTENTION: IN CASE OF A CRACK BEING DETECTED IN THE GLAZED CERAMIC HOB, IMMEDIATELY DISCONNECT FROM MAINS AND CONTACT THE NEAREST SERVICING CENTRE.
-
Page 4: Instructions For The Installer
Instructions for the installer 2 INSTALLATION OF THE APPLIANCE It is the law that all appliances are installed by competent persons. This appliance may be installed next to a wall which is higher than the appliance as shown in the diagram showing the correct installation conditions. -
Page 5: Electrical Connection
Instructions for the installer 2.1 Electrical connection Make sure that the power line voltage matches the specifications indicated on the rating plate located inside the storage compartment. This rating plate must never be removed. If the appliance is connected to the supply by means of a fixed connection, install a multipolar cut-out device on the line, with contact opening distance equal to or greater than 3 mm, located near the appliance and in an easily reachable position. -
Page 6: Description Of Controls
3 DESCRIPTION OF CONTROLS All the cooker controls and commands are on the front panel. FRONT RIGHT-HAND COOKING ZONE REAR RIGHT-HAND COOKING ZONE REAR LEFT-HAND COOKING ZONE FRONT LEFT-HAND COOKING ZONE Before using the oven check that the electronic programmer is showing the symbol “6.1 Clock adjustment”. - Page 7 Instructions for the user ELECTRIC OVEN THERMOSTAT KNOB Selection of cooking temperature is carried out by turning the knob clockwise to the required temperature, between 50° and 260°C. If the appliance has an electric oven, the warning light will come on when the oven is heating up.
-
Page 8: Use Of The Cooking Hob
4 USE OF THE COOKING HOB 4.1 Cooking zones The appliance features 4/5 cooking zones of different diameter and power. Their position is clearly indicated by circles and the heat given off is defined by the markings on the glass surface. The 5 cooking zones are of the HIGH-LIGHT type and come on after a few seconds of being activated. -
Page 9: Warnings And General Advice
Instructions for the user 5 USE OF THE OVEN For those models with electronic programmer, before using the oven make sure that the display shows the symbol For those models with analogue clock and timer, place on the symbol 5.1 Warnings and general advice Before using the oven for the first time, pre-heat it to maximum temperature (250°C) long enough to burn any manufacturing oily residues which could give the food a bad taste. -
Page 10: Storage Compartment
Never store flammable materials such as rags, paper or the like. The compartment is intended only for holding the metal accessories of the range. Never open the storage compartment when the oven is on and still hot. The temperature inside may be very high. -
Page 11: Electronic Programmer (Only On Equipped Models)
Instructions for the user 6 ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) LIST OF FUNCTIONS MINUTE-COUNTER KEY COOKING TIME KEY END-OF-COOKING KEY DECREASE TIME KEY INCREASE TIME KEY 6.1 Clock adjustment When using the oven for the first time, or after a power failure, the display flashes regularly and indicates . -
Page 12: End Of Cooking
Instructions for the user 6.4 End of cooking When cooking is over, the oven will automatically switch off and, at the same time, an intermittent alarm will sound. After switching off the alarm, the display will once again show the right time together with the symbol , indicating that the oven has returned to manual operation mode. -
Page 13: Cleaning And Maintenance
Instructions for the user 7 CLEANING AND MAINTENANCE 7.1 Cleaning stainless steel and enamelled versions To maintain stainless steel in good condition it must be cleaned regularly after each use, once it has cooled down. 7.1.1 Ordinary Daily Cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids. -
Page 14: Door Glass
Instructions for the user 7.3 Cleaning of oven For best oven upkeep clean regularly after having allowed to cool. Take out all removable parts. Clean the oven grill with hot water and non-abrasive detergent. Rinse and dry. 7.4 Door glass The door glass should always be kept clean. -
Page 15: Extraordinary Maintenance
Instructions for the user 8 EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. Before any intervention, disconnect the power supply of the device. 8.1 Replacement of light bulb Remove cover A by twisting anticlockwise, replace bulb B with another similar bulb (25 W).
