10. Air Cleaner Element

A: REPLACEMENT
NOTE:
Do not attempt to clean the air cleaner element.
The filter paper of the element is wetted with a
special non-flammable slow-evaporating viscous
liquid. It is resistant to cold weather and has a long
service life. Dirt adhering to this filter paper forms
porous laminations with the viscous liquid, which
function as a filtration layer to reduce dust penetra-
tion into the filter paper. If this filter paper is
cleaned, the filtration layer thus formed will be lost
along with the viscous liquid.
1. 2.5 L MODEL
SA07687A2005
1) Remove bolt (A) which install air cleaner case
to stays.
2) Remove the clip (B) above the air cleaner case.
3) Remove air cleaner.
4) Install in the reverse order of removal.
Tightening torque:
32.3 N·m (3.3 kgf-m, 23.9 ft-lb)
CAUTION:
Fasten with a clip after inserting the lower tab
of the case.
AIR CLEANER ELEMENT
SA07687
SA07687A20
GI0032
H2M2947A
PM-17
Periodic Maintenance Services
2. 3.0 L MODEL
SA07687A2006
1) Remove the clip (A) above the air cleaner upper
cover.
2) Remove air cleaner.
3) Install in the reverse order of removal.
NOTE:
Before installing air cleaner upper cover, align
holes with protruding portions of air cleaner
lower case, then secure upper cover to lower
case.
B2M4401B
B2M4403
