3.1.13-100

DTC P000A, P0010, P0012, P2088, P2089

DTC Description
Fault Code
P000A
P0010
P0012
P2088
P2089

2. Possible Sources

Fault
Test Tactics
Code
P000A
P0010
Hardware circuit
P0012
inspect
P2088
P2089
3. Diagnosis
Test Conditions
1. General inspection
CS35 2013.04
Electronic Control System - ME7
Description
Slow reaction of intake VVT
Open circuit of the VVT intake
control valve circuit
The intake VVT is not in the
default location when starting
Short circuit to ground of the
VVT intake control valve circuit
Short circuit to power supply of
the VVT intake control valve cir-
cuit
Setting Conditions (Control
• Short to ground or open circuit
• Short circuit to power supply
• Intake VVT hydraulic control valve circuits consist
of the following:
• Supply voltage: main relay provides reference volt-
age to terminal 2 of intake control valve wiring har-
ness connector E02 through terminal 45 of wiring
harness connector C01 fuse EF23.
• ECM control ground circuit: ECM positions the ter-
minal 1 on intake control valve wiring harness con-
nector E02 to low electric potential through
terminal 48 of ECM wiring harness connector E01.
Strategy)
Details/Results/Actions
A. Inspect the intake control valve wiring harness
connector E02 for loose or poor contact.
B. Check if the intake control valve is properly
installed.
Is it normal?
Y
Go to step 2.
N
Repair the fault.
3.1.13-100
Definition
Fault
• Intake control valve circuit
fault
• Intake control valve fault
• ECM
