GREAT PLAINS 3N-4010F Series Operator's Manual

3-section 40-foot no-till drills
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Table of Contents
3N-4010F, 3N-4010HDF, and 3N-4020F
Read the operator manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit or
may depict similar models where a topic is identical.
ORIGINAL INSTRUCTIONS
© Copyright 2019
Table of Contents
Index
Operator Manual
3-Section 40-Foot No-Till Drills
Manufacturing, Inc.
www.greatplainsmfg.com
Printed 2019-03-08
Index
20476
EN
196-359M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3N-4010F Series and is the answer not in the manual?

Questions and answers

Related Manuals for GREAT PLAINS 3N-4010F Series

Summary of Contents for GREAT PLAINS 3N-4010F Series

  • Page 1 Table of Contents Index Operator Manual 3N-4010F, 3N-4010HDF, and 3N-4020F 3-Section 40-Foot No-Till Drills Manufacturing, Inc. www.greatplainsmfg.com Read the operator manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! 20476 Illustrations may show optional equipment not supplied with standard unit or may depict similar models where a topic is identical.

  • Page 2: Serial Number

    Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you or the dealer have added options not originally ordered with the machine, or removed options that were originally ordered, the weights and measurements are no longer accurate for your machine.

  • Page 3: Table Of Contents

    Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as it sees fit.
  • Page 4 3N-4010F, 3N-4010HDF, and 3N-4020F Cover Index Table of Contents Row Unit Down Pressure .........78 Marker Shear Bolt Replacement ......107 10HD Disk Blade Adjustments .........79 Marker Chain Length..........108 10HD Seed Firmer Adjustments.......80 Electric Clutch Lockup...........108 10HD Press Wheel Adjustments ......81 Hydraulic Drive Maintenance ........109 20 Series Row-Unit Adjustments........83 To change the element: .........109 20 Series Row-Unit Down Pressure......84...

  • Page 5: Important Safety Information

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information Important Safety Information Look for Safety Symbol The SAFETY ALERT SYMBOL indicates there is a potential hazard to personal safety involved and extra safety precaution must be taken. When you see this symbol, be alert and carefully read the message that follows it.
  • Page 6 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information Wear Protective Equipment  Wear protective clothing and equipment.  Wear clothing and equipment appropriate for the job. Avoid loose-fitting clothing.  Because prolonged exposure to loud noise can cause hearing impairment or hearing loss, wear suitable hearing protection such as earmuffs or earplugs.
  • Page 7 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information Use A Safety Chain  Use a safety chain to help control drawn machinery should it separate from tractor drawbar.  Use a chain with a strength rating equal to or greater than the gross weight of towed machinery.

  • Page 8: Transport Machinery Safely

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information Transport Machinery Safely Maximum transport speed for drill is 20 mph (32 kph). Some rough terrains require a slower speed. Sudden braking can cause a towed load to swerve and upset. ...
  • Page 9 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information Tire Safety Tire changing can be dangerous and should be performed by trained personnel using correct tools and equipment.  When inflating tires, use a clip-on chuck and extension hose long enough for you to stand to one side–not in front of or over tire assembly.

  • Page 10: Safety Decals

     Keep all safety decals clean and legible.  Replace all damaged or missing decals. Order new decals from your Great Plains dealer. Refer to this section for proper decal placement.  When ordering new parts or components, also request corresponding safety decals.

  • Page 11: Important Safety Information

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information 838-267C Daytime Reflectors On the outside edge of center walkboard each end; 2 total 20301 848-512C WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov 848-512C Danger: Read Manual 20301 On tongue at hitch; 1 total 818-590C Danger: Crushing Hazard...

  • Page 12: Table Of Contents Index Important Safety Information

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information 818-045C Warning: Pinch/Crush 20301 On transport wheel assembly; 4 total 20301 818-188C WARNING EXCESSIVE SPEED HAZARD To Prevent Serious Injury or Death: Do Not exceed 20 mph maximum transport speed.

  • Page 13: Table Of Contents Index Important Safety Information

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information 818-579C (Option) Warning: Pinch Point On marker, two with single, four with dual marker option; 2 or 4 total 20306l 818-580C (Option) Warning: Overhead Hazard On marker, two with single, four with dual marker option; 2 or 4 total 20306 818-398C...

  • Page 14: Table Of Contents Index Important Safety Information

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Important Safety Information 818-587C CAUTION Read Owner’s Manual before using machine. Stand clear when folding and unfolding markers. Stand clear when raising and lowering machine. Keep all safety shields and devices in place. Keep hands, feet, and clothing away from moving chains and sprockets.

  • Page 15: Introduction

    Table of Contents Index Introduction Introduction Great Plains welcomes you to its growing family of new product owners. Your 3-Section 40-Foot No-Till Drill has been designed with care and built by skilled workers using quality materials. Proper setup, maintenance, and safe operating practices will help you get years of satisfactory use.

  • Page 16: Using This Manual

    Great Plains parts. Always use the serial and model number when ordering parts from your Great Plains dealer. The serial number plate is located on the front of the left hand side of the center section as shown.

  • Page 17: Preparation And Setup

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Preparation and Setup Preparation and Setup This section will help you prepare your tractor and drill for use. Before using the drill in the field, you must hitch the drill to a suitable tractor and level the drill. Pre-Setup Checklist 1.

  • Page 18: Make Hydraulic Connections

    Hydraulic Circuit Connections Refer to Figure 5 Great Plains hydraulic hoses are color coded handle grips to help you hookup hoses to your tractor outlets. Hoses that go to the same remote valve are marked with the same color.

  • Page 19: Preparation And Setup

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Preparation and Setup Older Style Hoses with Color Ties Refer to Figure 7 To distinguish hoses on the same hydraulic circuit, refer plastic hose label. hose under extended-cylinder symbol feeds a cylinder base end. The drive is compatible only with closed center, PC (pressure The hose under a retracted-cylinder symbol feeds a compensated) closed or LS (load sensing) hydraulic systems.

  • Page 20: Initial Setup

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Preparation and Setup Initial Setup The following items need to be done for first use, and some need to be re-done if the tractor changes. Initial Tractor Setup Veris Controller The standard Veris hydraulic drive, controller module and DICKEY-john radar are factory-installed on the drill.

  • Page 21: Point Row

    Install any that were not pre-installed. Scrapers (Option) If scrapers were ordered, and not dealer-installed, install them now per the instructions in one of the following manuals, which are available on the Great Plains Figure 11: 122-259K 20162 website if not ordered or included: 10 &...
  • Page 22 Refer to Figure 175 through Figure 180 on pages 126 and 128 4. Check measurement against value recommended by Great Plains. Figure 12 18878 Refer to Figure 12 Adjusting Marker Extension If the marker extensions need adjustment: 5. Loosen the nuts...

  • Page 23: Install Weight Brackets (Option)

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Preparation and Setup Install Weight Brackets (Option) If weight brackets were ordered, and were not dealer-installed, install them now. Two kits (4 brackets) are supported, accepting five standard 100 pound (45 kg) “suitcase” tractor weights each, for a maximum additional weight of 2000 pounds (907 kg).
  • Page 24 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Preparation and Setup Install Mid-Wing Brackets Refer to Figure 16 5. Select two: 806-172C U-BOLT 3/4-10 X 10 1/32X11 1/2 From the centerline of the inside U-Bolt installed at step 1, measure toward drill center, approximately: ...

  • Page 25: Operating Instructions

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Operating Instructions This section covers general operating procedures. It assumes that setup items have been completed. Experience, machine familiarity and this information leads to efficient operation and good working habits. Always operate farm machinery with safety in mind.

  • Page 26: Transport Locks

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Lift / Lower Machine Damage Risk: Lower only when the drill is unfolded. The drill must be raised and locked up for folding and unfolding. The drill has six rephasing lift cylinders that raise and lower the opener frame.

  • Page 27: Folding The Drill

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Folding the Drill Machine Damage Risk: Fold only when the drill is raised and locked up. Fold the drill on level ground with the tractor in neutral. If your drill has markers, be certain they are folded and their control switches are off before folding.

  • Page 28: Unfolding The Drill

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Unfolding the Drill Machine Damage Risk: Unfold only when the drill is raised and locked up. Unfold the drill on level ground with the tractor transmission in neutral. Figure 23 21844 Unfold: Drive/Lock Selector Valve Crushing, Pinch-Point and Overhead Hazards:...

  • Page 29: Transport

    Machine is not grounded. At higher voltages, electrocution can occur without direct contact. Great Plains recommends transporting the drill without seed loaded. Although designed for highway movement with full seed boxes, the additional weight of seed may...

  • Page 30: Pre-Transport Checklist

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Pre-Transport Checklist Before transporting the drill, check and observe the following items. Make sure the weight of the tractor equals or exceeds the value specified for your drill configuration. Marker Checklist Complete Markers must be folded.

  • Page 31: Loading Seed

    Watch your step when walking on drill ladder and walkboard. Falling from drill could cause severe injury or death. Great Plains recommends loading materials after the drill has been transported to the planting ground. Seed is heavy. A full load of dense seed adds over 6000 pounds (2780 kg) to the drill.

  • Page 32: Seed Cup Door

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Planting Seed Rate Seed rate on this family of drills is controlled by: • Seed rate handles. • Seed cup door handles. • Rate set by the hydraulic drive console. Set Seed Rate Handle Refer to Figure 27 There are main box seed rate handles for each section of...

  • Page 33: Row Unit

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions About Hydraulic Drive Rate Before it can control seed rate, the console must be: • configured with information about your drill and intended planting speed, • configured with a calibration number for the seed and rate range, and;...

  • Page 34: Point Row Switches

    A Point Row troubleshooting chart is found on page 91. Refer to Figure 31  The Pump switch has no function on 3N-40 drills configured by Great Plains. Unless connected to field-installed equipment, leave it off. When Not Planting or Calibrating Set the Master switch OFF when you do not intend to meter seed.

  • Page 35: Press Wheels

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Field Operations This section presumes that all pre-operation checks have been made on drill, and drill is hitched and loaded with seed. Final Field Checklist q Drill unfolded and raised. q Selector valve set to hydraulic drive.

  • Page 36: Marker Operation (Option)

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Marker Operation (Option) Markers are on a separate hydraulic circuit on the drill. 4. Reverse hydraulic lever; left marker raises while right Before operating markers, make sure they are properly marker stays up.

  • Page 37: Parking

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Operating Instructions Parking Following these steps when parking the drill for periods of less than 36 hours. For longer periods, see Storage, the next topic. 1. Spot the drill on firm, level ground. 2.

  • Page 38: Hydraulic Drive Operation

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Hydraulic Drive Operation Drive Operational Requirements Hydraulic System: Closed Center, pressure compensated or load sensed systems only Drive will not operate on Open-Center hydraulic systems Minimum Hydraulic Pressure 2250 psi Maximum Hydraulic Pressure 3000 psi Maximum Required Flow...

  • Page 39: Speed Calibration

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Controller Menu ON / VR set= * spd= out= ______ _._ PRESET RATES FUNCTION PRESET FUNCTION CALIBRATION selected NUMBER * PRESET 1 VARIABLE RATE FUNCTION FUNCTION FUNCTION recipe format RAWSON NOMINAL PRESET 2 RAWSON...

  • Page 40: Console Functions

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Console Functions Refer to Figure 36 (depicting the console in Manual mode) • ON/VR button: turns drive system on. Press twice for VR (Variable Rate) mode. • OFF button: used to shut off Console.

  • Page 41: Hydraulic Drive Field Operations

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Hydraulic Drive Field Operations Refer to Figure 37 1. Turn on Controller Console by pressing the ON/VR button. Green light above ON/VR button illuminates when power is on. Pressing the ON/VR button twice puts the unit in VR mode.

  • Page 42: Rowcount

    SeedRate = 50 (lbs/ac) amount at a single row. RowCount = 48 1.04 = 50 / 48 Great Plains suggests sampling an amount that is at SampleSize is 1.04 lbs least  lb (0.1 kg), and requires at least 100 seconds.

  • Page 43: Hydraulic Drive Calibration

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Hydraulic Drive Calibration source: ./charts/veris40fc-cal.ods -> Export as .pdf -> convert to .eps in Illustrator. 2019-03-08 Table of Contents Index 196-359M...

  • Page 44: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 39 4. Set the Point Row switch box for Calibration mode: • LEFT section switch on. • CENTER and RIGHT section switches off. • Master switch to “CAL”...

  • Page 45: Hydraulic Drive Operation

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 42 13. Press Function button until the Calibration window appears as shown. 14. Press  arrow button to enter calibration mode. Figure 42 28251 Initiate Sample Calibration Refer to Figure 43 15.

  • Page 46: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 45 16. Enter drill width (swath), in feet (ENGLISH mode) or meters (METRIC mode), using   arrow buttons. Press FUNCTION button to advance to next window. Swath values for various row spacings are found in the charts beginning on page 126.

  • Page 47: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Prime Seed Meters Before running an actual calibration, it is important that the seed cups be filled with seeds, and the flutes primed to deliver seed at first rotation. Step 19 through step 30 executes a short calibration to do this.

  • Page 48: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 51 22. Press FUNCTION. The console beeps and displays this screen, indicating that the drive is about to operate, and all personnel must be cleared from the area near the hydraulic drive, chains and shafts.

  • Page 49: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 54 27. When the sample run-time has expired, the motor stops, the indicator above the ENGAGE button goes out, and the console displays the estimated sample generated (based on actual motor performance, which may vary slightly from calculations).

  • Page 50: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Full Calibration Make sure the seed meter cups are full, and seed can flow at initial motor rotation. To prime the cups, see page Refer to Figure 56 31. Turn the console on with the ON/VR button. Check, and as necessary, repeat step 1 through step 18.

  • Page 51: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 59 35. Press FUNCTION. The console beeps and displays the next screen indicating that the drive is about to operate, and all personnel must be cleared from the area near the hydraulic drive, chains and shafts.

  • Page 52: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 62 39. When the sample run-time has expired, the motor stops, the indicator above the ENGAGE button goes out, and the console displays the estimated sample generated (based on actual motor performance, which may vary slightly from calculations).

  • Page 53: Refer To Figure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 64 42. A new calibration number is suggested, along with the old calibration number. Figure 64 28263 New/Old Calibration Number Refer to Figure 65 43. Press FUNCTION button to advance to the choice window.

  • Page 54: Speed Calibration

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Speed Calibration In order to fine-tune the default speed calculation or to convert to radar speed signal, the controller may be calibrated as follows: 1. Set two flags 400ft apart (100 meters if in metric mode).
  • Page 55 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 70 5. Begin driving at a normal field speed; when the tractor passes the first flag, press ENGAGE. Figure 70 28268 At First Flag Refer to Figure 71 6.
  • Page 56 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Refer to Figure 73 8. The display shows the error or difference between the traveled distance and the distance calculated by the Controller. Figure 73 28271 Distance Variance Refer to Figure 74 9.

  • Page 57: Varying Rates With Pre-Set Function

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Varying Rates with Pre-set Function The Precision Population Controller allows you to pre-set three different rates, and then change rates on-the-go by toggling from one rate to another rate with the ...

  • Page 58: Rawson

    24 ft (7.32m) from hitch pin to seed tubes; Add the distance from the GPS to the hitch pin. Enter the total in the Following Distance window. Enter the Swath Width of the Great Plains unit. 6. Under the CTRL tab, enter the Nominal Rate as follows: Divide the highest rate on your recipe by 1.6.

  • Page 59: Gp Precision Population Settings

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation GP Precision Population Settings 1. Connect SiteMate computer to Console using 9-pin serial cable , as shown in Figure 80. Follow instructions on page 38 to set Calibration Number. Refer to Figure 81 2.

  • Page 60: Seed

    SRAM or Flash card that is compatible with the PF 3000. PF3000 Settings: 2. Press SETUP key. Press SWATH key. Set swath to that of your Great Plains Precision Seeding System. 3. Press SETUP key. Press VEHICLE key. Figure 83: PF3000: 28322 Set Primary speed sensor to GPS.

  • Page 61: Precision Population Settings

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Hydraulic Drive Operation Precision Population Settings 1. Connect PF3000 to Console using 9 pin serial cable per Figure 83 on page 56. 2. Set Calibration Number per page 38. Refer to Figure 84 3.

  • Page 62: Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Adjustments Planting Depth To get full performance from your drill, you need an understanding of all component operations, and many provide adjustments for optimal field results. Setting nominal planting depth, and achieving it consistently, is affected by multiple adjustable drill The 3N-4010F, 3N-4010HDF and 3N-4020F have functions, from greatest to least effect they are:...

  • Page 63: Frame Level

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Frame Level When beginning planting, check frame level with row units in level ground. If one or both wings are angled up or down, check and adjust the following items: • “Level Frame Side to Side” on page 101 •...

  • Page 64: Tool Bar Height

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Frame Height without 27213 Frame-Mounted Coulters Use these instructions with a drill having no coulters, or having unit-mounted coulters (UMC). Adjustments to individual unit-mounted coulters themselves (10HD models only) are on page 75. If the drill has frame-mounted coulters, use the height procedure on page 62.

  • Page 65: Umc

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments drill raised (actuator plunger not in contact with down-stop). Loosening the down-stop with circuit active and drill lowered results in rapid lowering of the frame. Height Mis-setting Risk: Make sure the drill is level and the lift system bled and re-phased before adjusting the tool bar height. If the center section does not consistently stop at the set height, or the wings do not run at the same height as the center, the lift system may have air or be out of phase (above), or the wings may not be level.

  • Page 66: Frame-Mounted Coulters

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Frame-Mounted Coulters The factory configuration of frame-mounted coulters (FMC) is that they run about 1in (2.5cm) deeper than the opener blades. Based your conditions experience, you can readjust the depth drill-wide, or just at some rows.
  • Page 67 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Crushing Hazard: Make all down-stop adjustments with circuit in neutral and drill raised (actuator plunger not in contact with down-stop). Loosening the down-stop with circuit active and drill lowered results in rapid lowering of the frame. Height Mis-setting Risk: Make sure the drill is level and the lift system bled and re-phased before adjusting the tool bar height.

  • Page 68: Individual Frame-Mounted Coulter Depth

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 7. Measure the depth at which the coulters are running. Measure only in non-tire-track rows where the coulter springs are not in compression (arm is at full extension). If the coulters are at the desired depth, ...

  • Page 69: Frame-Mounted Coulter Force

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Frame-Mounted Coulter Force Coulter springs are set to 400 lbs (181 kg). In normal operation at target running depth, the spring is at full extension. It compresses briefly as obstructions are encountered.

  • Page 70: Implement Lift Switch Adjustment

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Implement Lift Switch Adjustment Refer to Figure 95 A switch on the drill turns seed metering off (via the electric clutches) when the drill is raised. To adjust the height at which seed metering stops, follow these steps. 1.

  • Page 71: Tractor Weight

    Each bracket accepts up to five standard weights, about 500 lbs (227 kg) per wing, or 1000 lbs (454 kg) per kit. Great Plains recommends loading no more than two sets of brackets, representing 2000 lbs (907 kg) total. Do not add weight to the center section. It is always heavier than even a fully weighted wing, and never requires additional weights.

  • Page 72: Red

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Marker Adjustments This section covers marker items that may need adjustment for current conditions, and assumes that the markers are installed, set to the correct initial extension and in proper working order. See also: •...

  • Page 73: Support

    (which depicts a row unit fully populated with all optional accessories supported for use with the 3N-4010F drill) From front to back, a Great Plains 10 Series row unit can include the following capabilities (some optional): 1. Dual Down Pressure Springs: standard...

  • Page 74: Series Row Unit Down Pressure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 10 Series Row Unit Down Pressure Refer to Figure 102 The ideal amount of down-force causes the press wheels to compress any loose surface soil, but not press a trench into subsoil. To assess down-force, operate the drill for a short distance on typical ground (with or without seeding), and stop.

  • Page 75: Series Disk Blade Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Adjusting 10 Series Down-Force Refer to Figure 104 An adjuster cam sets row unit spring down pressure individually for each row unit. This is useful for penetrating hard soil and planting in tire tracks. Cam Notch Pounds zero (out of notch)

  • Page 76: Series Seed Firmer Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Adjusting 10 Series Disc Contact Sharp Object Hazard: Row unit disk blades may be sharp. Use caution when making adjustments in this area. Refer to Figure 107 1. Raise the drill and install the transport locks. 2.

  • Page 77: Series Opener Depth

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 10 Series Seed-Lok™ Lock-Up Optional Seed-Lok firming wheels provide additional seed-to-soil contact. The wheels are spring loaded and do not require adjusting. In some wet and sticky conditions the wheels may accumulate soil. To avoid problems associated with this, you can lock-up the firmers.

  • Page 78: Scraper

    (which depicts a row unit fully populated with all optional accessories supported for use with the 3N-4010HDF drill) From front to back, a Great Plains 10HD Series row unit can include the following capabilities (some optional): 1. Unit-Mounted Coulter (UMC): optional UMCs are used instead of frame-mounted coulters and are often preferred where soils are not rocky.

  • Page 79: Unit-Mounted Coulter Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Unit-Mounted Coulter Adjustments Unit-mounted coulters (UMC) are an optional alternative to frame-mounted coulters. Only one type of coulter may be installed. See page 121 for ordering information.  Unit-Mount Coulters are not factory-installed. Check alignment and depth prior to first use.
  • Page 80 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 10HD Coulter Row Alignment Refer to Figure 114 For both frame- and unit-mounted coulters, the ideal alignment is for the blade to prepare a furrow directly ahead of the opener discs. As a check on coarse alignment, sight along the coulter blade centerline , the gap between the opener blades...

  • Page 81: Hd Row Unit Down Pressure

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 10HD Row Unit Down Pressure Refer to Figure 102 The ideal amount of down-force causes the press wheels to compress any loose surface soil, but not press a trench into subsoil. To assess down-force, operate the drill for a short distance on typical ground (with or without seeding), and stop.

  • Page 82: Row Unit Down Pressure

     With 4-spring rows, do not set all rows so high that planting becomes uneven or gauge wheels lift off 4-Spring 10HD Cam Down-Force Settings ground. a. Contac your Great Plains dealer for update kit information. 2019-03-08 Table of Contents Index...

  • Page 83: Hd Disk Blade Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 10HD Row Unit Lock-Up When seeding is shut off, individual row 10HD Series row units can be locked up to reduce wear. The opener shank has a hole in the opener shank that accepts an optional pin to block parallel arm movement.

  • Page 84: Hd Seed Firmer Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Adjusting 10HD Disc Contact Sharp Object Hazard: Row unit disk blades may be sharp. Use caution when making adjustments in this area. Refer to Figure 107 1. Raise the drill and install the transport locks. 2.

  • Page 85: Hd Press Wheel Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 10HD Seed-Lok™ Lock-Up Optional Seed-Lok firming wheels provide additional seed-to-soil contact. The wheels are spring loaded and do not require adjusting. In some wet and sticky conditions the wheels may accumulate soil. To avoid problems associated with this, you can lock-up the firmers.
  • Page 86 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 10HD Press Wheel Spacing Double V Press Wheel Adjustment Refer to Figure 125 The double-V closing wheels can be moved inward and outward to alter how they close the seed trench and press soil over the seed.

  • Page 87: Seed Tube

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 20 Series Row-Unit Adjustments Refer to Figure 126, which depicts a 20 Series row unit fully populated with all features supported on 3N-4020F drill (excepting Seed-Lok). From front to back, they are: 1.

  • Page 88: Side Depth Wheels

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 20 Series Row-Unit Down Pressure Refer to Figure 127 An adjuster cam sets row unit spring down pressure individually for each row unit. This is useful for penetrating hard soil and planting in tire tracks. Cam Notch Pounds zero (out of notch)

  • Page 89: Series Disk Adjustments

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 20 Series Disk Adjustments See also “20 Series Opener Maintenance” on page 111. Opener Disc Contact Region Refer to Figure 130 Opener disc angle and stagger is not adjustable, but disc-to-disc spacing is, and may need attention as discs experience normal wear.
  • Page 90 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments Refer to Figure 134 To adjust side gauge wheels: 1. Raise planter slightly removing weight from side gauge wheels. 2. Loosen hex-head bolt . Move wheel and arm out on O-ring bushing. 3.

  • Page 91: Tension Screw

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 20 Series Seed Firmer Adjustments 20 Series row units include a seed flap, and accept one of two optional firmers. Sharp Object Hazard: Row unit disk blades may be sharp. Use caution when making adjustments.

  • Page 92: Press Wheel Stagger

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Adjustments 20 Series Press Wheels Attached to the rear of each row-unit is one of several press wheel options. To provide consistent seed firming, the press wheels are free to move downward from their normal operating position.

  • Page 93: Troubleshooting

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting Troubleshooting General Drill Troubleshooting Problem Cause Solution Check seed rate setup and calibration, page Planting too much Incorrect seed rate. Seed cup door not correctly set for seed size. Adjust seed cup doors, page 28. Actual field size is different.

  • Page 94: Seed Cups

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting Problem Cause Solution Excessive field speed. Reduce field speed. Uneven seed depth Planting conditions too wet. Wait until drier weather. Seed-Lok building up with dirt. Lock up Seed-Lok, pages 73, 81, 87. Damaged or missing seed flaps.

  • Page 95: Hydraulic Drive

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting Problem Cause Solution Foreign matter lodged in seed cup sprockets. Clean out seed cup sprockets. Seed cup sprockets locked up or seed drive shaft twisted Remove build-up by disassembling each seed Build-up of dried liquid insecticide in seed cup and scraping the foreign substance from cups.

  • Page 96: Speed

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting power/comm cable to cab console and external Excessive torque in drive system. Disconnect controller. main drive chain to check for rotation under zero load. Check for a problem with the mechanical d.
  • Page 97 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting b. Check radar gun angle. c. Check power to system. Less than 12 Vdc power will cause drive to behave erratically - often problem manifests itself in speed loop. 8. Drive shuts off while planting: a.

  • Page 98: Calibration Troubleshooting

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting Calibration Troubleshooting: If the time to run for calibration is less than 4 seconds, the cab console will display TIME TOO LOW. Pressing the FUNCTION button will bring up the ENTER TARGET AMOUNT screen.

  • Page 99: Hydraulic Drive Troubleshooting Flow Chart

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting Hydraulic Drive Troubleshooting Flow Chart 23250 2019-03-08 Table of Contents Index 196-359M...

  • Page 100: Hydraulic Drive Electronics Troubleshooting

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting Hydraulic Drive Electronics Troubleshooting 23249 2019-03-08 Table of Contents Index 196-359M...

  • Page 101: Gps Troubleshooting

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Troubleshooting GPS Troubleshooting Troubleshooting GPS with SiteMate 1. No Rx rate appears on SiteMate • Re-check planter monitor settings: calibration number, row spacing, number of rows, swath • Has field been selected? Select VRT file (see width, seed, etc.

  • Page 102: Troubleshooting Gps With Pf3000

    GPS signal, or are you outside of field? 2. No Actual Rate appears on the PF3000. • Actual rate cannot be logged using the PF3000 with the Great Plains Precision Population Controller. 3. Target Rate appears on PF3000 but not on GP Controller Console.

  • Page 103: Maintenance And Lubrication

    3. Inflate tires per “Tire Inflation Chart” on page 124. 4. Replace any worn, damaged or illegible safety decals. Order new decals from your Great Plains dealer. “Safety Decals” on page 6. 5. Clean or replace any fittings that will not take grease.

  • Page 104: Shim

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Seed Cleanout Refer to Figure 140, which depicts the seed cup door handle in a normal operating position. 1. For large quantities of remaining seed, use a bucket to scoop out from above, as this may be easier than collecting under row units.

  • Page 105: Level Frame Side To Side

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Level Frame Side to Side All frame sections must be level to maintain even seeding depth. Before using the drill in the field, follow these steps to make sure the drill is level side-to-side. Periodic frame-leveling adjustments should not be necessary, but if you are having problems with uneven depth, check drill levelness and follow these procedures.

  • Page 106: Box Alignment

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Box Alignment To check and adjust box alignment: 1. Unfold drill (see “Unfolding the Drill” on page 24) and place a block ahead of each wing caster wheel. Pull drill forward against blocks to rock frames back. Pull forward until stop bolts are firmly against toolbars.

  • Page 107: Tongue

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Tongue Spacer Block If the folded drill does not pull straight, wanders back and forth while being towed, or fails to latch during folding, it may be necessary to replace or adjust one or more tongue spacer block assemblies.

  • Page 108: Bleeding Hydraulics

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Bleeding Hydraulics To function properly, the hydraulics must be free of air. If During initial implement setup (which may have been hydraulics have not been bled, they will operate with done by your dealer) or if you replace a hydraulic jerky, uneven motions and could cause wings to drop component, complete the following procedures.

  • Page 109: Bleeding Fold Hydraulics

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Bleeding Fold Hydraulics Review hydraulic bleeding warnings and advisories on page 104. 1. Check hydraulic fluid level in tractor reservoir and fill to proper level. Add fluid to system as needed while cycling new cylinders.

  • Page 110: Sequence Valve

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Marker Maintenance Overhead Hazard: You may be injured if hit by a folding or unfolding marker. Markers may fall quickly and unexpectedly if the hydraulics fail. Never allow anyone near the drill when folding or unfolding the markers.

  • Page 111: Marker Shear Bolt Replacement

    This prevents damage to the marker. If the shear bolt fails, replace it with a bolt of identical size and grade, or one of similar strength. The supplied bolt is Great Plains part: 802-589C HHCS  -14X2 GR5 This is a ...

  • Page 112: Marker Chain Length

    2. Insert three M8-1.25x14mm long metric bolts 3. Lock-up bolts are not supplied with the drill. They are separately available from Great Plains. Order quantity 9 of part: 802-782C HHCS M8X1.25X14 GR8.8  Use only 14mm length bolts or machine damage will occur.

  • Page 113: Hydraulic Drive Maintenance

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Hydraulic Drive Maintenance As with any hydraulic system, contamination is the most common cause performance problems pre-mature wear. Make a special effort to properly clean quick couplers prior to attaching the hoses to tractor. Filter: All fluid is filtered through the high pressure filter (p/n 18574) and it provides protection to the hydraulic components of your drive if properly maintained.

  • Page 114: Seed Flap

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Row Unit Maintenance Seed Flap Replacement (s/n 1066TT-) Refer to Figure 157 To replace a seed flap use a needle nose or similar tool and squeeze the tabs together. Pull plastic seed flap down out of metal bracket If replacing with 817-349C:...

  • Page 115: Hd Opener Maintenance

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication 10HD Opener Maintenance 10HD Disk Spreader-Scraper Refer to Figure 159 To perform this inspection (and replacement), it may be necessary to remove one or both opener disk blades. 1. With unit raised, remove bolt holding on one or both blades.
  • Page 116 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication 5. To prevent plugging loosen clamp bolt and slide arm inward to take up gap between side wheel and disk blade. 6. Adjust side gauge wheels. See “Side Gauge Wheel Adjustments”...

  • Page 117: Lubrication

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Lubrication Intervals (operating hours) Multi-purpose Multi-purpose Multi-purpose Inspection at which service oil lubricant grease lubricant spray lubricant is required 34208 Grease Bank (Option) Up to 14 zerks each bank, 2 banks each of 3 sections; 6 banks total;...

  • Page 118: Rockshaft

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Rockshaft 1 zerk each of 3 pivots, 1 zerk each lower cylinder pin; 5 total Type of Lubrication: Grease Quantity: Until grease emerges 27190 Lift Cylinder Pins 1 zerk each rod-end cylinder pin, 1 cylinder each parallel arms set, 2 cylinders at rockshaft;...
  • Page 119 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Wing Flex Pivots 1 zerk each of 2 pivots; 2 total Type of Lubrication: Grease Quantity: Until grease emerges 27191 Rear Axle Pivot 1 zerk Type of Lubrication: Grease Quantity: Until grease emerges 20282 Transfer Drive Shafts...
  • Page 120 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Wing Frame Vertical Pivots 1 zerk each of 2 pivots; 2 total Type of Lubrication: Grease Quantity: Until grease emerges 27189 Marker(s) (Option) 3 zerks per marker; 3 or 6 total Type of Lubrication: Grease Quantity: Until grease emerges 20306...
  • Page 121 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Maintenance and Lubrication Drive Chains 20318 Required 1 chain per section; 3 total Type of Lubrication: Chain Lube Quantity: Coat thoroughly Coulter Hub Bearings Season- 1 zerk each hub; 48 or 64 total Type of Lubrication: Grease Quantity: Until resistance is felt 12454...

  • Page 122: Options

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Options Options Hitch Options One hitch is selected upon initial order of an 3N-4010F, 3N-4010HDF and 3N-4020F Drill, and includes the spring wire loop, safety chain, and all fasteners. Additional hitches may be ordered for conversion in the field, and include extra hitch mounting bolts, lock washers and nuts.

  • Page 123: Transport

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Options Dual Weight Kit If unusual soil conditions require more weight for coulter penetration, one or two weight bracket kits are available, each kit containing tow brackets (one for each wing). The brackets attach to the wing mainframe, and accept up to five standard “suitcase”...

  • Page 124: Seed Tube

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Options Coulter Tines Frame-mounted coulters on your implement can be equipped with optional trash tines. The tines help guide the residue under the coulters and openers to prevent plugging. Order one kit per row. Row Spacing Part Numbers 7.5-Inch Rows, Coulter Tine Update Kit...

  • Page 125: Hd Unit-Mounted Coulters

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Options 10HD Unit-Mounted Coulters Unit-mount coulters (UMCs) are available only for models 3N-4010HDF, and are an alternative to frame-mounted coulters (page 119). Only one type of coulter at a time can be installed. UMCs attach directly to the 10HD row unit, and the coulter blade maintains a precise relationship to the opener disk (seeding) depth.

  • Page 126: Seed Firmers

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Options Inside Carbide Scrapers When planting in moist or sticky soils, these scrapers are useful in preventing build-up that might otherwise impair opener disc performance. scrapers spring-loaded, and require no adjustment. Order one per row. The 122-259K kit is not compatible with Seed-Lok.

  • Page 127: Seed-Lok® Seed Firmer

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Options Seed-Lok® Seed Firmer Factory-installed Seed-Lok firmers are included in numerous drill opener bundles. For post-delivery installation, order one kit per row. Description Part Number 10 Series Seed-Lok 122-252K 10HD Series Seed-Lok 122-151K 20 Series Seed-Lok 122-193K...

  • Page 128: Tires

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Appendix Appendix Specifications and Capacities 3N-4010F- 3N-4010HDF- 3N-4020F- -4810 -6475 -4810 -6475 -4810 -6475 Operating Width 40 ft (12.2m) 480in (1219cm) 484in (1229cm) 480in (1219cm) 484in (1229cm) 480in (1219cm) 484in (1229cm) Swath Number of Rows Row Spacing Nominal...

  • Page 129: Torque Values Chart

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Appendix Torque Values Chart Bolt Head Identification Bolt Head Identification Bolt Bolt 10.9 Size Size Grade 2 Grade 5 Grade 8 Class 5.8 Class 8.8 Class 10.9 ft-lb ft-lb ft-lb ft-lb ft-lb in-tpi ft-lb mm x pitch...

  • Page 130: Row Spacings

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Appendix Row Spacing Data The diagrams in this section show useful measures that Use this data for calibration (page 38), setting marker vary between machine models, row spacings, and extension (page 18), and shutting off rows for modified modified row spacings.
  • Page 131 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Appendix -4810 Models Row Spacings -4810 Standard Spacing Span: 470in (1194cm) Swath: 480in (1219cm) Rows: 48 openers (all used) Row Spacing: 10in (25.4cm) Figure 176: -4810 28242 Standard Spacing: 48 single 10in Rows; all rows used -4810 as “-2420”...
  • Page 132 3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Appendix -6475 Models Row Spacings -6475 Standard Spacing Span: 476.5in (1210cm) Swath: 484in (1229cm) Rows: 64 openers (all used) Nominal Row Spacing: 7.5in (19.1cm) Swath-Averaged Row Spacing: 7.56in (19.2cm) Figure 179: -6475 28242 Standard Spacing: 64 single 7.5in Rows;...

  • Page 133: Hydraulic Diagram

    3N-4010F, 3N-4010HDF, and 3N-4020F Table of Contents Index Appendix Hydraulic Diagram 20452 2019-03-08 Table of Contents Index 196-359M...

  • Page 134: Warranty

    90 days for commercial or rental purposes. This War- ranty is limited to the replacement of any defective part by Great Plains Manufacturing, Incorporated and the installation by the dealer of any such replacement part.
  • Page 135 3N-4010F, 3N-4010HDF, and 3N-4020F Cover Table of Contents Index Index chain, safety ........13 Tires Not A Step .....9 change rates, Veris ......37 Warning accident ....2 checklists High Pressure Fluid Hazard ...8 address ..........12 final field ........31 deeper planting adjuster cam maintenance .......

  • Page 136: Operation

    3N-4010F, 3N-4010HDF, and 3N-4020F Cover Table of Contents Index Farmworks ..........54 hydraulic bleeding ......104 METRIC ..........41 FCC 47 CFR Sec. 2 ....21 hydraulic connections ......14 millet ...........39 FCC 47 CFR Sec. 2.1091 ....16 hydraulic drive ........29 milo .............39 fescue ..........39 monitor, shaft ........120...

  • Page 137: Operation

    3N-4010F, 3N-4010HDF, and 3N-4020F Cover Table of Contents Index press wheel stagger ......88 seed rate handles ......28 stagger, press wheel press wheels ......83 seed rate, field check ......49 20 Series ........88 20 Series ........88 seed trench sticky conditions .........87 prime cups ..........43 20 Series ........
  • Page 138 3N-4010F, 3N-4010HDF, and 3N-4020F Cover Table of Contents Index unit mounted coulters ......60 veristech.com ........16 19798..........93 unit-mounted coulter ......75 VER-21568, module .....34 19799..........92 Unit-Mounted Coulters ....59 VR button ........... 36 198-126H, tool ........71 units of measure .........41 VR (Variable Rate) ......36 19856..........109 198-960A, scraper .....
  • Page 139 3N-4010F, 3N-4010HDF, and 3N-4020F Cover Table of Contents Index 804-023C, washer ....... 19 805-033C, lock-up pin ......121 806-172C, bolt ........19 806-172C, U-bolt ........20 817-087C, plug .........120 817-348C, label ......14 818-045C, decal ........8 818-055C, SMV ........6 818-188C, decal ........8 818-339C, decal ........8 818-398C, decal ........9 818-557C, decal ........7 818-579C, decal ........9...
  • Page 140 Great Plains, Mfg. 1525 E. North St. P.O. Box 5060 Salina, KS 67402...

This manual is also suitable for:

3n-4010f-4810483n-4020f series3n4010hdf-4810483n4010hdf-6475643n-4020f-4810483n-4020f-647564 ... Show all

Table of Contents
