Smeg ALFA135V6 Owner's Handbook Manual

Smeg oven owner's handbook
Hide thumbs

Advertisement

Quick Links

1.
PRECAUTIONS FOR SAFETY AND USE _____________________ 22
2.
INSTALLING THE OVEN __________________________________ 24
3.
DESCRIPTION OF CONTROLS ____________________________ 27
4.
USING THE OVEN _______________________________________ 28
5.
CLEANING AND MAINTENANCE ___________________________ 34
6.
EXTRAORDINARY MAINTENANCE _________________________ 36
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
qualified engineer who is to install, commission and test the appliance.
INSTRUCTIONS FOR THE USER: these provide recommendations for
use, a description of the controls and the correct procedures for cleaning
and maintaining the appliance.

Table of Contents

21

Advertisement

loading

Related Manuals for Smeg ALFA135V6

Summary of Contents for Smeg ALFA135V6

  • Page 1: Table Of Contents

    Table of Contents PRECAUTIONS FOR SAFETY AND USE _____________________ 22 INSTALLING THE OVEN __________________________________ 24 DESCRIPTION OF CONTROLS ____________________________ 27 USING THE OVEN _______________________________________ 28 CLEANING AND MAINTENANCE ___________________________ 34 EXTRAORDINARY MAINTENANCE _________________________ 36 INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified engineer who is to install, commission and test the appliance.

  • Page 2: Precautions For Safety And Use

    1. PRECAUTIONS FOR SAFETY AND USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. TAKE GOOD CARE OF IT AND KEEP IT TO HAND THROUGHOUT THE OVEN'S LIFE CYCLE. WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE OVEN.
  • Page 3 SHOULD ALWAYS BE WORN. THE NAMEPLATE WITH THE TECHNICAL DATA, SERIAL NUMBER AND MARK IS IN A VISIBLE POSITION ON THE BACK OF THE OVEN. THIS NAMEPLATE MUST NEVER BE REMOVED. THE APPLIANCE IS INTENDED FOR PROFESSIONAL USE BY TRAINED STAFF.

  • Page 4: Installing The Oven

    EEC DIRECTIVES. 2.1 Electrical connection Check that the power supply voltage and size are as specified on the nameplate on the back of the oven. This nameplate must never be removed. The oven is fitted with a H07RN- F three-core cable for operation at 240-240V∼.
  • Page 5 3 mm, located in an easily accessible position close to the appliance itself. WARNING: if the mains voltage drops below 190 VAC there might be an impairment of the oven's performance; this is not due to the appliance itself. ∼...
  • Page 6 Instructions for the Installer 2.2 Safety thermostat The oven is fitted with a safety device tripped in case of a serious malfunction. To reset the safety device, call the after-sales service. The manufacturer declines all responsibility for injury or damage caused by failure to comply with the above regulations or deriving from tampering with even just one part of the appliance.

  • Page 7: Description Of Controls

    Instructions for the User 3. DESCRIPTION OF CONTROLS START BUTTON Use this button to set the time when turning on the appliance for the first time or after a power failure, scroll through preset programs and start cooking cycles. STOP BUTTON Use this button to set the time when turning on the appliance for the first time or after a power failure, scroll through preset programs and terminate cooking cycles.

  • Page 8: Using The Oven

    N.B. This power setting operation only has to be carried out the first time the oven is connected. The value set is saved and automatically used whenever the oven is switched on after this. To modify this setting or the...
  • Page 9 START + STOP together to return to the point described in section “4.3 Setting the time”. 4.5 Program selection This oven has 15 different cooking programs, including: 14 user-editable programs for humidified fan-mode cooking (P1 to P14); 1 manual editable program for fan-mode cooking.
  • Page 10 Instructions for the User To edit a humidified fan-mode program by entering the parameters exactly as required, turn the knob to one of the programs from P1 to P14. The display shows the parameters contained in the selected program. Hold down STOP for 2 seconds. A beeper sounds to indicate that the editing mode has been accessed, and the message Ut°C appears on the display.
  • Page 11 10 minutes, after which it will start to drop for a period up to a maximum time of 20 minutes, counted from when the beep sounded. After this the oven switches off).
  • Page 12 Instructions for the User above, or at the program temperature for cooking operations at below 100°C. After 20 minutes, the oven switches off. N.B. - during preheating and cooking, whenever the door is opened the message "door" will appear on the display and a beep will sound to warn the user that the door must be closed while these operations are in progress.
  • Page 13 STOP key. 4.11 Key to the oven's beep sounds All the beep sounds the oven emits are different from each other, in order to allow the user to identify exactly what the oven is doing. Parameter setting/modification menu = 1 single beep End of preheating and pause before start of cooking = 5 beeps followed by a pause of 2 seconds.

  • Page 14: Cleaning And Maintenance

    Instructions for the User 5. CLEANING AND MAINTENANCE Important: never point jets of water straight at the oven and do not use high- pressure water cleaners. Before carrying out any operation, disconnect the oven from the electricity supply. 5.1 Cleaning stainless steel To keep stainless steel in good condition, it must be cleaned regularly at the end of each day, after allowing it to cool.
  • Page 15 Instructions for the User 5.2 Cleaning the inside of the oven To keep the oven in good condition, it must be cleaned regularly at the end of each day, after allowing it to cool. Remove all removable parts. Remove the side runners by removing the hook "C" from the hole or pin "D"...

  • Page 16: Extraordinary Maintenance

    Instructions for the User 6. EXTRAORDINARY MAINTENANCE Occasionally, the oven will require minor servicing procedures or the replacement of parts subject to wear and tear, such as gaskets, light bulbs, etc. The specific operations for each procedure of this kind are provided below.
  • Page 17 6.3 Oven door gasket To allow thorough cleaning of the oven, the door gasket can be removed. Before removing the gasket, remove the oven door as described above. Once the door has been removed, lift the tangs at the corners as shown on the right.
