GRIGLIA ELETTRICA DA INCASSO
CON ROCCIE VULCANICHE
E DOSATORE D'ENERGIA
GRIL ELECTRIQUE ENCASTRABLE
AVEC ROCHES VOLCANIQUES
ET DOSEUR D'ENERGIE
BUILT-IN ELECTRIC GRILL
WITH VOLCANIC ROCKS
AND ENERGY REGULATOR
ELEKTRISCHER EINBAUGRILL
MIT VULKANGESTEINE
UND ENERGIEREGLER
PARRILLA ELÉCTRICA EMPOTRABLE
CON ROCAS VOLCÁNICAS
Y DOSIFICADOR DE ENERGIÁ
ELEKTRISCHE INBOUWGRILL
MET VULKANISCH GESTEENTE
EN ENERGIEDOSERING
Istruzioni per l'uso
Mode d'emploi
Directions for use
Gebrauchsanweisung
Modo de empleo
Gebruiksaanwijzing
Advertisement
Table of Contents
Related Manuals for Smeg SEGR530X
Summary of Contents for Smeg SEGR530X
-
Page 1: Quelques Suggestions
GRIGLIA ELETTRICA DA INCASSO CON ROCCIE VULCANICHE E DOSATORE D’ENERGIA GRIL ELECTRIQUE ENCASTRABLE AVEC ROCHES VOLCANIQUES ET DOSEUR D’ENERGIE BUILT-IN ELECTRIC GRILL WITH VOLCANIC ROCKS AND ENERGY REGULATOR ELEKTRISCHER EINBAUGRILL MIT VULKANGESTEINE UND ENERGIEREGLER PARRILLA ELÉCTRICA EMPOTRABLE CON ROCAS VOLCÁNICAS Y DOSIFICADOR DE ENERGIÁ... -
Page 2: Table Of Contents
Indice Istruzioni per l’installazione Installazione ad incasso Messa in servizio Alcuni suggerimenti Manutenzione Index Installation instructions Fitting Assembly Some suggestions Maintenance Index pagina Instructions pour l’installation Encastrement Mise en service Quelques suggestions Entretien Inhaltsverzeichnis page Installationsanweisungen Einbau Inbetriebnahme Einige Vorschläge Reinigung page Seite... -
Page 3: Installation Instructions
Installation This grill uses 2.500 watts at its maximum position. Therefore, before connection, make sure that your electric wiring system is at least fitted with a 16-ampere fuse. It is also necessary to provide a bipolar cut-off device in your power supply circuit, where the opening of the contacts is more than 3 mm. -
Page 4: Fitting
Fitting This grill is built into a work surface or kitchen unit by simply cutting a hole the corresponding shape. Any support may be suitable : brickwork, timber, metal, granite, laminate, etc. Dimensions of appliance : 503,50 x 306 mm Dimensions of hole cut in work surface : 480 x 275 mm... -
Page 5: Assembly
Assembly 1. Protective bowl 2. Volcanic rock 3. Heating element 4. Hinge 5. Grill 6. Thermostat 7. on/off indicator light 8. Bolt... - Page 6 The fitting plate is fixed into the work surface. When the grill is placed in position in your work surface, you can fill the protective bowl with volcanic rocks, leaving the element raised. The rock layer must be carefully formed, so that the rocks are evenly distributed and do not project beyond the top of the protective bowl.
- Page 7 Hinge : the « drainer » position The aluminium hinge which permits the turning of the element during maintenance is fitted with a stainless steel securing bolt. This piece runs to the left and secures the element, which is held in the vertical position during the time necessary for cleaning.
-
Page 8: Some Suggestions
Some suggestions Before any utilization, preheat for 5 to 10 minutes in position 6. Position the knob according to the type of food to be cooked. These positions may vary in relation to the quantity used, and the personal taste of the consumer. PREPARATION THERMOSTAT POSITION... -
Page 9: Maintenance
Maintenance Before any maintenance, disconnect the appliance and let it cool. All the pieces can be maintained quickly : The grill : you can clean it easily when it is still warm. Proceed as for the rest of your dishes : a little detergent is enough. Do not hesitate to put it in the dish-washer.
