Instructions for Use
Thank you for your trust and for buying this appliance. We hope it will
successfully serve the purpose for many years.
The upright freezer for domestic use is intended for freezing fresh
food and for long-term storing of frozen food (up to one year),
depending on the kind of food.
Upright Freezer
Instructions for Use
60-62
63-64
65-66
67-68
69-70
71
72-73
74-75
59
Advertisement
Table of Contents
Related Manuals for Smeg CV10B
Summary of Contents for Smeg CV10B
-
Page 1: Table Of Contents
Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. The upright freezer for domestic use is intended for freezing fresh food and for long-term storing of frozen food (up to one year), depending on the kind of food. -
Page 2: Before Putting Into Use
Before Putting Into Use • Before connecting the appliance to the mains supply, leave it for about 2 hours to stand in place where it will later on be installed. This will reduce the possibility of malfunctions in the cooling system that might have occurred due to transport handling. - Page 3 (See We Care for the Environment). • Heating element incorporated in the appliance, all around the rim, is controlled by the operation of the compressor and it prevents the door gasket to freeze on to the freezer housing. Instructions for Use...
- Page 4 Avoidopeningthe freezer in case of failure or power supply interruption! In case the interruption is extended over longer period of time 14 hours, take food out of the freezer and use it, or make sure that it remains frozen (if you have and additional appliance).
-
Page 5: Placing And Installation
Placing and Installation Choosing the Right Place Place the appliance in dry and regulary ventilated room. Allowed ambient temperature depends on the model (class) of the appliance and is stated on the rating plate of the appliance. Class SN (sub-normal) N (normal) ST (sub-tropical) T (tropical) -
Page 6: Connection To Power Supply
Connection to Power Supply Connect the appliance with the cable and plug to the power supply socket outlet with a ground terminal (safety socket). Required nominal voltage and frequency are indicated in the rating plate. The connection to the mains supply and earthing have to be made according to current standards and regulations. -
Page 7: Description Of The Appliance
Description of the Appliance Freezing Compartment (1) is used for freezing fresh foods. Storing Compartment (2) is used for storing packages of frozen foods. Control Panel (3) See Operation Controls Instructions for Use... - Page 8 Indicating Pointers (4) On the front side of the basket and on the freezing compartment door there are movable pointers, that will help you keep order in the appliance. Use two pointers of the same colour - one for the kind of food and the other for the months the package was loaded into the appliance.
-
Page 9: Operation Control
Operation Control The freezer is controlled with the thermostat knob. 1. Red control light 2. Yellow control light 3. Thermostat knob Mode of Operation Continuous operation - the yellow light is on. The cooling system operates continuously - the Super function. This mode is selected when you want to freeze large amounts of fresh foods and in case you want to deep freeze already frozen foods. - Page 10 Thermostat settings towards min help you save energy provided that the freezer is loaded with smaller amount of frozen foods. Changes of the ambient temperature affects temperature in the interior of the appliance. Choose correct setting of the thermostat knob.
-
Page 11: Use
Switch the appliance on and set the thermostat knob to the position for continuous operation. (Red and yellow control light are on). When the red light goes off, wait for a couple of hours and load the freezer with packages of fresh foods. -
Page 12: Storing Frozen Foods
Packages of frozen foods should be carried well wrapped covered and as soon as possible stored in the freezer. A temperature rise shortens the storage time of commercially frozen foods. Approximate Storage Time forFrozen Foods... -
Page 13: Maintenance And Cleaning
Maintenance and Cleaning Freezer Defrosting When the frost layer in the freezer is 3-5 mm thick, you should clean the freezer. • 24 hours before defrosting set the thermostat knob to the position for continuous operation (the yellow light is on) so that the food packages are well cooled. -
Page 14: Changing The Direction Of Opening The Door
Changing the Direction of Opening the Door If you find the direction of opening the door on your appliance inconvenient, you can change it. Holes on the opposite side have already been prepared in the factory and are now plugged. •... - Page 15 1 Lower hinge with foot 2 Foot 3 Fasttener 4 Handle Instructions for Use...
-
Page 16: Trouble Shooting Guide
(assure adequate air circulation behind the appliance and wipe the dust from the condenser). The Freezer Door is Hard to Open If you want to open the door that has just or recently been closed, you may find them hard to open. The reason why this happens is, that when you open the door, warm air gets into the appliance and when it is cooling, the underpressure seals the door. - Page 17 something is wrong with the appliance and it has no influence on the lifetime of the appliance. Gradually the noise is reduced. • Sometimes unusual and stronger noise is heard, which is rather unusual for the appliance. This noise is often a consequence of inadequate placing.
