SWITCHING
OVERVIEW
The SMC Edge-Core ES4710BD is a high performance, 10-slot, Layer 3 chassis
switch which supports IPv4/IPv6. It can operate with single or dual manage-
ment modules. The Slots can be any combination of network interface mod-
ules and 1 or 2 management modules. With redundant power supplies, fans,
and management modules, the SMC Edge-Core ES4710BD ensures continuous
operation and is a fully redundant system. All parts of the system are hotswap-
pable meaning that all components can be added or exchanged without inter-
FEATURES
The SMC EdgeCore ES4710BD supports high port density perfor-
mance.
Up to 4 10G Ports per module
Full Layer 3 support
IPv6 Routing Support
www.smc.com
ES4710BD
Edge-core™ Chassis Core Routing Switch
rupting the whole system. The ES4710BD is ideal for the core of a campus,
enterprise networks or for the aggregation layer of an IP metropolitan net-
works.
BENEFITS
Supports up to 32 10G ports or 384 Gigabit ports, providing fl exibility and high
port density.
10G modules support up to 4 ports for link to L3 Gigabit switches or L2 Gigabit
switches, aggregating them to the core layer, and preventing bottlenecks in Gigabit
switches
Supports RIP, OSPF and BGP4+ for Unicast routing and DVMRP and PIM-DM/SM
for multicast routing. VRRP is included for added redundancy
The SMC EdgeCore ES4710BD supports IPv6 routing in hardware for maximum
performance

Advertisement

Table of Contents
loading

  Also See for SMC Networks Edge-core ES4710BD

  Related Manuals for SMC Networks Edge-core ES4710BD

  Summary of Contents for SMC Networks Edge-core ES4710BD

  • Page 1 Edge-core™ Chassis Core Routing Switch OVERVIEW The SMC Edge-Core ES4710BD is a high performance, 10-slot, Layer 3 chassis switch which supports IPv4/IPv6. It can operate with single or dual manage- ment modules. The Slots can be any combination of network interface mod- ules and 1 or 2 management modules.
  • Page 2: Technical Specifications

    • Storage: -40 to 70 °C (-40 to 158 °F) HUMIDITY • Operating: 10% to 90% (non-condensing) AC INPUT • 90 to 264 V, 50-60 Hz L2 SWITCH FEATURES • Auto negotiation for port speed and duplex mode • Flow Control: • Provides IEEE 802.3x for full duplex mode •...
