Summary of Contents for SMC Networks EZ-Stream SMC2304WBR-AG

  • Page 3: User Guide

    EZ-Stream Universal 2.4GHz/5GHz Wireless Cable/DSL Broadband Router User Guide From SMC’s EZ-Stream line of Broadband Routers 38 Tesla Irvine, CA 92618 Phone: (949) 679-8000 December 2003 Revision No: R01 F1.0...
  • Page 4 COPYRIGHT Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 | Introduction ......1 Features and Benefits ......1 Package Contents .
  • Page 6 ABLE OF ONTENTS Fixed-IP xDSL ......29 PPPoE ....... . 29 Point-to-Point Tunneling Protocol (PPTP) .

  • Page 7: Chapter 1 | Introduction

    CHAPTER 1 | I Congratulations on your purchase of the EZ-Stream Universal 2.4GHz/ 5GHz Wireless Cable/DSL Broadband Router. SMC is proud to provide you with a powerful yet simple communication device for connecting your local area network (LAN) to the Internet. 1.0 | Features and Benefits •...

  • Page 8: Package Contents

    Introduction 1.1 | Package Contents After unpacking the EZ-Stream Wireless Router, check the contents of the box to be sure you have received the following components: • EZ-Stream Universal 2.4GHz/5GHz Wireless Cable/DSL Broadband Router • Power adapter • One CAT-5 Ethernet cable •...

  • Page 9: Chapter 2 | Getting To Know The Ez-Stream Wireless Router

    CHAPTER 2 | G OUTER 2.0 | Hardware Description The Router can be connected to the Internet or to a remote site using its RJ-45 WAN port. It can be connected directly to your PC or to a local area network using any of the Fast Ethernet LAN ports. Access speed to the Internet depends on your service type.
  • Page 10 Getting to Know the EZ-Stream Wireless Router The following figures show the components of the Router: Figure 2-1. Front and Rear Panels Item Description LEDs Power, WLAN, WAN, and LAN ports status indicators. (See “LED Indicators” on page 5.) Use this port to connect to your PC. Ports Reset Use this button to reboot the router or restore the default factory...

  • Page 11: Led Indicators

    2.1 | LED Indicators The EZ-Stream Wireless Router includes status LED indicators, as described in the following figure and table. Figure 2-2. Status LED PWR (Green) WLAN - 11a (Green) WLAN - 11b/g (Green) WAN (Green) LAN - 1, 2, 3, 4 Link/ACT (Green) Speed...

  • Page 12: Chapter 3 | Installing The Ez-Stream Wireless Router

    CHAPTER 3 | I OUTER Before installing the EZ-Stream Universal 2.4GHz/5GHz Wireless Cable/DSL Broadband Router, verify that you have all the items listed under “Package Contents” on page 2. If any of the items are missing or damaged, contact your local SMC distributor. Also be sure that you have all the necessary cabling before installing the Router.

  • Page 13: Attach To Your Network Using Ethernet Cabling

    Warning: Do not plug a phone jack connector into any RJ-45 port. This may damage the Router. Instead, use only twisted-pair cables with RJ-45 connectors that conform with FCC standards. Internet Access SMC2304WBR-AG Device Wireless Gateway SOHO Office or Residence...

  • Page 14: Attach To Your Network Using Radio Signals

    Installing the EZ-Stream Wireless Router Figure 3-2. Making the LAN Connections 3.2 | Attach to Your Network Using Radio Signals Install a wireless network adapter in each computer that will be connected to the Internet or your local network via radio signals. SMC currently offers several wireless network cards, including the SMC2802W wireless PCI and SMC2835W wireless PC cards.
  • Page 15 Attach to Your Network Using Radio Signals The wireless infrastructure configuration not only extends the accessibility of wireless PCs to the wired LAN, but also increases the effective wireless transmission range for wireless PCs by retransmitting incoming radio signals through the Router. A wireless infrastructure can be used for access to a central database, or for connection between mobile workers, as shown in the following figure:...

  • Page 16: Attach The Ez-Stream Wireless Router To The Internet

    Installing the EZ-Stream Wireless Router 3.3 | Attach the EZ-Stream Wireless Router to the Internet If Internet services are provided through an xDSL or cable modem, use unshielded or shielded twisted-pair Ethernet cable (Category 3 or greater) with RJ-45 plugs to connect the broadband modem directly to the WAN port on the Router.

  • Page 17: Chapter 4 | Configuring Client Tcp/Ip

    CHAPTER 4 | C If you have not previously installed the TCP/IP protocols on your client PCs, refer to the following section. If you need information on how to configure a TCP/IP address on a PC, refer to “Setting Up TCP/ IP”...

  • Page 18: Windows 2000

    Configuring Client TCP/IP Select Microsoft in the manufacturers list. Select TCP/IP in the Network Protocols list. Click the OK button to return to the Network window. The TCP/IP protocol will be listed in the Network window. Click OK. The operating system may prompt you to restart your system.

  • Page 19: Setting Up Tcp/Ip

    Double-click Protocol. Choose Internet Protocol (TCP/IP). Click the OK button to return to the Network window. The TCP/IP protocol will be listed in the Network window. Click OK to complete the installation procedure. 4.1 | Setting Up TCP/IP To access the Internet through the Router, you must configure the network settings of the computers on your LAN to use the same IP subnet as the Router.

  • Page 20: Configuring Your Computer In Windows 95/98/Me

    Configuring Client TCP/IP Note: These settings may be changed to suit your network requirements, but you must first configure at least one computer as described in this chapter to access the Router’s web configuration interface. See “Configuring the EZ-Stream Wireless Router” on page 25 for information on configuring the Router.) If you have not previously configured TCP/IP for your computer, refer to“Configuring Client TCP/IP”...
  • Page 21 On the Network window Configuration tab, double-click the TCP/IP entry for your network card. Click the IP Address tab. Click the “Obtain an IP address“ option. Next click on the Gateway tab and verify the Gateway field is blank. If there are IP addresses listed in the Gateway section, highlight each one and click Remove until the section is empty.
  • Page 22 Configuring Client TCP/IP On the Network Properties Window, click the OK button to save these new settings. Note: Windows may ask you for the original Windows installation disk or additional files. Check for the files at c:\windows\options\cabs, or insert your Windows CD-ROM into your CDROM drive and check the correct file location, e.g., D:\win98, D:\win9x.

  • Page 23: Configuring Your Computer In Windows Nt 4.0

    Configuring Your Computer in Windows NT 4.0 From the Windows desktop click Start/Settings/Control Panel. Double-click the Network icon. Click on the Protocols tab. Double-click TCP/IP Protocol. Click on the IP Address tab. In the Adapter drop-down list, be sure your Ethernet adapter is selected.
  • Page 24 Configuring Client TCP/IP Click on “Obtain an IP address from a DHCP server.” Click OK to close the window. Windows may copy files and will then prompt you to restart your system. Click Yes and your computer will shut down and restart. Obtain IP Settings From Your EZ-Stream Wireless Router Now that you have configured your computer to connect to the Router, it needs to obtain new network settings.

  • Page 25: Configuring Your Computer In Windows 2000

    Type IPCONFIG /RENEW and press the <ENTER> key. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.254. These values confirm that the Router is functioning Type EXIT and press <ENTER> to close the Command Prompt window.

  • Page 26: Configuring Your Computer In Windows Xp

    Configuring Client TCP/IP In the Local Area Connection Properties box, verify the box next to Internet Protocol (TCP/IP) is checked. Then highlight the Internet Protocol (TCP/IP), and click the Properties button. Select “Obtain an IP address automatically” to configure your computer for DHCP.

  • Page 27: Configuring A Macintosh Computer

    In the Local Area Connection Properties box, verify the box next to Internet Protocol (TCP/IP) is checked. Then highlight the Internet Protocol (TCP/IP), and click the Properties button. Select “Obtain an IP address automatically” to configure your computer for DHCP. Click the OK button to save this change and close the Properties window.

  • Page 28: Manual Ip Configuration (For All Windows Os)

    Configuring Client TCP/IP 4.2 | Manual IP Configuration (for all Windows OS) Check Specify an IP address on the IP Address tab. Enter an IP address based on the default network 192.168.2.x (where x is between 2 and 254), and use 255.255.255.0 for the subnet mask.
  • Page 29 Manual IP Configuration (for all Windows OS) On the DNS Configuration tab, add the IP address for the Router and click Add. This automatically relays DNS requests to the DNS server(s) provided by your ISP. Otherwise, add specific DNS servers into the DNS Server Search Order field and click Add.

  • Page 30: Verifying Your Tcp/Ip Connection

    Configuring Client TCP/IP 4.3 | Verifying Your TCP/IP Connection After installing the TCP/IP communication protocols and configuring an IP address in the same network as the Router, use the ping command to check if your computer has successfully connected to the Router.

  • Page 31: Chapter 5 | Configuring The Ez-Stream Wireless Router

    CHAPTER 5 | C The EZ-Stream Wireless Router can be configured by any Java-supported browser, i.e., Internet Explorer 5.0 or above. Using the web management interface, you can configure the Router and view statistics to monitor network activity. Note: Before you attempt to configure your Router, if you have access to the Internet please visit and download the latest firmware update to ensure your Router is running the latest firmware.

  • Page 32: Internet Explorer (For Macintosh)

    Configuring the EZ-Stream Wireless Router Click the LAN Settings button. Clear all the check boxes and click OK to save these LAN settings changes. Click OK again to close the Internet Options window. Internet Explorer (For Macintosh) Open Internet Explorer. Click Explorer/Preferences. In the Internet Explorer Preferences window, under Network, select Proxies.

  • Page 33: Setup Wizard

    SETUP WIZARD This next generation Barricade has a new web-based interface that is easier to use and is faster. Each option is accessible from the new side navigation section. If you want to setup the Router using the built-in Setup Wizard, simply click on the SETUP WIZARD option to start the process.

  • Page 34: Broadband Type

    Configuring the EZ-Stream Wireless Router For accurate timing of client filtering and log events, you need to set the time zone. Select your time zone from the drop-down list. Check Enable Automatic Time Server Maintenance to automatically maintain the Router’s system time by synchronizing with a public time server over the Internet.

  • Page 35: Cable Modem

    Cable Modem After selecting Cable Modem as the Broadband Type, a message will appear stating that your data has been successfully saved. Note: Select Home to return to the home page, then select Advanced Settings/WAN to configure the required parameters. (See “WAN” on page 38.) Fixed-IP xDSL Some xDSL Internet Service Providers may assign a fixed (static) IP address.

  • Page 36: Point-To-Point Tunneling Protocol (Pptp)

    Configuring the EZ-Stream Wireless Router Enter a Maximum Idle Time (in minutes) to define a maximum period of time for which the Internet connection is maintained during inactivity. If the connection is inactive for longer than the Maximum Idle Time, it will be dropped. (Default: 10) Enable the Auto-reconnect option to automatically re-establish the connection as soon as you attempt to access the Internet again.

  • Page 37: Bigpond

    BigPond If you use the BigPond Internet Service which is available in Australia, enter your Username, Password, and Authentication Service Name for BigPond authentication. Click NEXT to complete the setup. 5.3 | ADVANCED SETUP Use the web management interface to define system parameters, manage and control the Router and its ports, or monitor network conditions.
  • Page 38 Configuring the EZ-Stream Wireless Router Menu Wireless Firewall DDNS UPnP Tools Description Configures the radio frequency, SSID, encryption, and 802.1x for wireless communications. Shares a single ISP account with multiple users, sets up virtual servers. Configures a variety of security and specialized functions, including: Access Control, Hacker Prevention, and DMZ.

  • Page 39: Status

    STATUS The Status screen displays WAN/LAN connection status, firmware, and hardware version numbers, attempts to access your network, as well as information on DHCP clients connected to your network. The following items are included on this screen: Section INTERNET Release Renew GATEWAY INFORMATION...

  • Page 40: System

    Configuring the EZ-Stream Wireless Router Section Security Log Save Clear Refresh DHCP Client Log SYSTEM Time Zone Set the time zone and time server for the Router. This information is used for log entries and client access control. Check Enable Automatic Time Server Maintenance to automatically maintain the Router’s system time by synchronizing with a public time server over the Internet.
  • Page 41 Password Settings Use this menu to restrict access based on a password. (Default: smcadmin) For security you should assign your administration password before exposing the Router to the Internet. Passwords can contain from 3–12 alphanumeric characters and are not case sensitive. Note: If your password is lost, or you cannot gain access to the user interface, press the Reset button on the rear panel (holding it down for at least five seconds) to...
  • Page 42 Configuring the EZ-Stream Wireless Router Remote Management Remote Management allows a remote PC to configure, manage, and monitor the Router using a standard web browser. Check Enable and enter the IP address of the remote host. Click SAVE SETTINGS. Note: If you specify 0.0.0.0 as this IP address, any host can manage the Router.
  • Page 43 ADVANCED SETUP Syslog Server The Syslog Server tool will automatically download the Barricade log to the server IP address specified by the user. Enter the Server LAN IP Address and check the Enabled box to enable this function.

  • Page 44: Wan

    Configuring the EZ-Stream Wireless Router Specify the WAN connection type provided by your Internet Service Provider, then click More Configuration to enter detailed configuration parameters for the selected connection type.
  • Page 45 ADVANCED SETUP Dynamic IP The Host Name is optional, but may be required by some ISPs. The default MAC address is set to the WAN’s physical interface on the Router. Use this address when registering for Internet service, and do not change it unless required by your ISP.
  • Page 46 Configuring the EZ-Stream Wireless Router Point-to-Point Over Ethernet (PPPoE) Enter the PPPoE User Name and Password assigned by your Service Provider. The Service Name is normally optional, but may be required by some service providers. The MTU (Maximum Transmission Unit) governs the maximum size of the data packets.
  • Page 47 ADVANCED SETUP Point-to-Point Tunneling Protocol (PPTP) Point-to-Point Tunneling Protocol (PPTP) can be used to join different physical networks using the Internet as an intermediary. Using the above screen allows client PCs to establish a normal PPTP session and provides hassle-free configuration of the PPTP client on each client Enter the assigned IP address, subnet mask and default gateway IP address (usually supplied by your ISP), and then the PPTP User ID, Password and PPPTP Gateway IP address.
  • Page 48 Configuring the EZ-Stream Wireless Router Auto-connect: This option will re-connect when you attempt to access the Internet. Keep session: This option keeps your PPTP online by having the Router continually check your internet connection. If you are disconnected, it will automatically reconnect to the WAN. Static IP If your Internet Service Provider has assigned a fixed IP address, enter the assigned address and subnet mask for the Router, then enter the...
  • Page 49 ADVANCED SETUP BigPond BigPond is a service provider in Australia that uses a heartbeat system to maintain the Internet connection. On this page you can configure the user settings including, User Name, Password, and the Authentication Service Name.
  • Page 50 Configuring the EZ-Stream Wireless Router Domain Name Servers map numerical IP addresses to the equivalent domain name (e.g., www.smc.com). Your ISP should provide the IP address of one or more domain name servers. Enter those addresses in this screen. Primary Server: This is the IP Address of the first DNS server will be used first to translate the website name into an IP Address.

  • Page 51: Lan

    • LAN IP – Use the LAN menu to configure the LAN IP address for the Router and to enable the DHCP server for dynamic client address allocation. • Set a period for the lease time if required. For home networks this may be set to Forever, which means there is no time limit on the IP address lease.

  • Page 52: Wireless

    Configuring the EZ-Stream Wireless Router WIRELESS To configure the Router as a wireless access point for wireless clients (either stationary or roaming), all you need to do is define the radio channel, the Service Set identifier (SSID), and security options.
  • Page 53 ADVANCED SETUP Channel and SSID You must specify a common radio channel and SSID (Service Set ID) to be used by the Router and all of your wireless clients. Be sure you configure all of your clients to the same values. SSID: The Service Set ID.
  • Page 54 Note: The available channel settings are limited by local regulations. SuperA/SuperG: The SuperA/G implemented with the SMC2304WBR-AG can dramatically boost your wireless connectivity with the network performance up to 108 Mbps. It supports static and dynamic turbo mode, frame bursting, compression, and 802.11a,b,g channel interoperation.
  • Page 55 ADVANCED SETUP Security If you are transmitting sensitive data across radio channels, you should enable wireless security.
  • Page 56 Configuring the EZ-Stream Wireless Router Wired Equivalent Privacy (WEP) encryption requires you to use the same set of encryption/decryption keys for the Router and all of your wireless clients. WEP mode: You can choose disabled, 64-bit or 128-bit encryption. Key Provisioning: Select a key type of static key or dynamic key. Static WEP Key Setting You may manually enter the keys or automatically generate encryption keys.
  • Page 57 ADVANCED SETUP If you use encryption, configure the same keys used for the Router on each of your wireless clients. Note that Wired Equivalent Privacy (WEP) protects data transmitted between wireless nodes, but does not protect any transmissions over your wired network or over the Internet.
  • Page 58 Configuring the EZ-Stream Wireless Router Field Cypher suite Authentication Pre-shared key type Pre-shared Key Group Key Re_Keying Default Parameter TKIP 802.1X Passphrase (8~63 characters) none Disable Description One of the security mechanism used by WPA for frame body and CRC frame encryption Select the authentication mode.
  • Page 59 ADVANCED SETUP 802.1X Management access will be checked against the authentication database stored on the Router. If an authentication RADIUS server is used, you must specify the secret key of the Message-Authenticator attribute, i.e., Message Digest-5 (MD5), and the corresponding parameters in the RADIUS Server Parameters field for the remote authentication protocol.

  • Page 60: General Parameters

    Configuring the EZ-Stream Wireless Router • General Parameters Field Enable 802.1X Session Idle Timeout Re-Authentication Period Quiet Period Server Type • RADIUS Server Parameters Field Server IP Server Port Secret Key NAS-ID Default Parameter 300 seconds 3600 seconds 60 seconds RADIUS Defaults Description...
  • Page 61 WDS (Wireless Distribution System) The WDS provides a means to extend the range of a Wireless Local Area Network (WLAN). WDS allows an access point to establish a direct link to other access points, and stations to roam freely within the area covered by the WDS.

  • Page 62: Nat

    Configuring the EZ-Stream Wireless Router Click WIRELESS/Channel and SSID of the navigation menu for configuring the operation “Mode” (11a as example) and radio “Channel” on the first access point. Go to WIRELESS/WDS page of the first access point, enter the (11a) WLAN MAC address of the peer (2nd, 3rd, 4th or the 5th) access point, and select the operation “Mode”...
  • Page 63 ADVANCED SETUP Virtual Server If you configure the Router as a virtual server, remote users accessing services such as web or FTP at your local site via public IP addresses can be automatically redirected to local servers configured with private IP addresses. In other words, depending on the requested service (TCP/UDP port number), the Router redirects the external service request to the appropriate server (located at another internal IP address).
  • Page 64 Configuring the EZ-Stream Wireless Router Special Applications Some applications, such as Internet gaming, videoconferencing, Internet telephony and others, require multiple connections. These applications cannot work with Network Address Translation (NAT) enabled. If you need to run applications that require multiple connections, use the following screen to specify the additional public ports to be opened for each application.
  • Page 65 Popular applications requiring multiple ports are listed in the Popular Applications field. From the drop-down list, choose the application and then choose a row number to copy this data into. Note: Choosing a row that already contains data will overwrite the current settings. Example: Trigger Port Trigger 28800...

  • Page 66: Firewall

    Configuring the EZ-Stream Wireless Router FIREWALL The Router firewall can provide access control of connected client PCs, block common hacker attacks, including IP Spoofing, Land Attack, Ping of Death, IP with zero length, Smurf Attack, UDP port loopback, Snork Attack, TCP null scan, and TCP SYN flooding. The firewall does not significantly affect system performance, so we advise enabling it to protect your network users.
  • Page 67 ADVANCED SETUP Access Control Add PC Access Control allows users to define the outgoing traffic permitted or not permitted for the WAN interface. The EZ-Stream Wireless Router can also limit the access of PCs within the network by blocking specific ports as defined in the “User Define Service” field. Each access control rule can be activated at a pre-defined time.
  • Page 68 Configuring the EZ-Stream Wireless Router MAC Filter This section provides MAC filtering configuration information. To use MAC address filtering, you must enter a list of allowed/denied client MAC addresses into the filtering table. You can define up to 32 clients using the MAC address filtering table. When enabled only the MAC addresses entered will have access to your network.
  • Page 69 ADVANCED SETUP URL Blocking To configure the URL Blocking feature, use the table below to specify the web sites (www.somesite.com) and/or keywords you want to filter on your network. To complete this configuration, you will need to create or modify an access rule in “Access Control”...
  • Page 70 Configuring the EZ-Stream Wireless Router Schedule Rule The Schedule Rule allows you to configure access times to the Internet based on time and date. These rules will display on the Access Control-Add PC page, and can be used to configure more specific access control.
  • Page 71 Add Schedule Rule Enables Schedule-based Internet access control. Click Add Schedule Rule. Define the settings for the schedule rule (as shown on the following screen). Click OK and then click the SAVE SETTINGS button to save your settings. ADVANCED SETUP...
  • Page 72 Configuring the EZ-Stream Wireless Router Intrusion Detection The Intrusion Detection feature limits access for incoming traffic at the WAN port.
  • Page 73 • SPI and Anti-DoS firewall protection (Default: Enabled) – When the SPI (Stateful Packet Inspection) feature is turned on, all incoming packets will be blocked except for those types marked with a check in the Stateful Packet Inspection section. • RIP Defect (Default: Enabled) –...
  • Page 74 Configuring the EZ-Stream Wireless Router Stateful Packet Inspection allows you to select different application types that are using dynamic port numbers. If you wish to use the Stateful Packet Inspection (SPI) to block packets, click on the Yes radio button in the “Enable SPI and Anti-DoS firewall protection”...
  • Page 75 DoS Detect Criteria Set up DoS (Denial-of-Service) and port scan criteria in the spaces provided (as shown below). Parameter Total incomplete TCP/UDP sessions HIGH Total incomplete TCP/UDP sessions LOW Incomplete TCP/UDP sessions (per min.) HIGH Incomplete TCP/UDP sessions (per min.) LOW Maximum incomplete TCP/UDP sessions number from same host...
  • Page 76 Configuring the EZ-Stream Wireless Router If you have a client PC that cannot run an Internet application properly from behind the firewall, then you can open the client up to unrestricted two-way Internet access. Enter the IP address of a DMZ host to this screen.

  • Page 77: Ddns

    ADVANCED SETUP DDNS Provider – This DNS feature is powered by either DynDNS, or TZO.com. With a DDNS connection you can host your own web site, E-mail server, FTP site, and more at your own location even if you have a dynamic IP address. (Default: Disable) Domain Name –...

  • Page 78: Upnp

    Configuring the EZ-Stream Wireless Router The section also has a “Server Configuration” section that automatically opens the port options checked in the Virtual Server section. Simply enter in the IP Address of your server, such as a web server, and then click on the port option “HTTP Port 80” so users can access your server from the WAN connection (Internet).

  • Page 79: Tools

    TOOLS Use the Tools menu to back up the current configuration, restore a previously saved configuration, restore factory settings, update firmware, and reboot the Router. Configuration Tools • Backup Router Configuration – Saves the Router’s configuration settings to a file. •...
  • Page 80 Configuring the EZ-Stream Wireless Router Firmware Upgrade Use this screen to update the firmware or user interface to the latest versions. Download the upgrade file from the SMC web site (www.smc.com) and save it to your hard drive. In the Upgrade Target field, choose Firmware.
  • Page 81 Reboot Click REBOOT ROUTER to reset the Router. Click OK to reboot. The reset will be complete when the power LED stops blinking. Note: If you use the Reset button on the rear panel, the Router performs a power reset. If the button is depressed for over five seconds, all the LEDs will illuminate and the factory settings will be restored.

  • Page 82: Chapter 6 | Troubleshooting

    APPENDIX A | T The information outlined in this section describes some useful steps for getting your computer and the Router online. Verify your connection to the Router If you are unable to access the Router’s web-based administration pages then you may not be properly connected or configured. The screen shots in this section were taken on a Windows 2000 machine, but the same steps will apply to Windows 95/98/Me/XP.
  • Page 83 I am getting an IP Address that starts with 169.254.xxx.xxx If you are getting this IP Address, then you need to check that you are properly connected to the Router. Confirm that you have a good link light on the Router for the port this computer is connected to.

  • Page 84: Troubleshooting

    Troubleshooting Then type ipconfig/renew. The 10/100 LED does not light after a connection is made. Check that the host computer and the Router are both powered Be sure the network cable is connected to both devices. Verify that Category 5 cable is used if you are operating at 100 Mbps, and that the length of any cable does not exceed 100 m (328 ft).

  • Page 85: Chapter 7 | Specifications

    APPENDIX B | S Below is an outline of the technical specifications for the SMC2304WBR-AG. Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.11a IEEE 802.11b IEEE 802.11g WAN Interface 10BASE-T/100BASE-TX LAN Interfaces 10BASE-T/100BASE-TX 4 RJ-45 ports: LAN data transfer rate is up to 10/20 Mbps...

  • Page 86: Specifications

    Specifications Weight 370 g (13.05 oz) Input Power 12 V, 1 A Maximum Current 0.04 A max. @ 110 V/240 V Power Consumption 5 Watts max. @ 100-240 VAC Internet Standards RFC 826 ARP, RFC 791 IP, RFC 792 ICMP, RFC 768 UDP, RFC 793 TCP, RFC 854-859 TELNET, RFC 1321 MD5, RFC 1497 BOOTP Extension, RFC 1570 PPP LCP Extension, RFC 1631 NAT, RFC1661 PPP, RFC 1700 Assigned Numbers, RFC 1866...

  • Page 87: Chapter 8 | Compliances

    APPENDIX C | C C.0 | Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 88: Industry Canada - Class B

    Compliances Wireless 2.4 Ghz and 5 GHz Band Statements: As the SMC2304WBR-AG can operate in the 5150-5250 MHz frequency band it is limited by the FCC, Industry Canada and some other countries to indoor use only so as to reduce the potential for harmful interference to co-channel Mobile Satellite systems.
  • Page 89 • EN 60950 (IEC 60950) - Product Safety • EN 301 893 - Technical requirements for 5 GHz radio equipment • EN 300 328 - Technical requirements for 2.4 GHz radio equipment • EN 301 489-1 / EN 301 489-17 - EMC requirements for radio equipment Countries of Operation &...
  • Page 90 Compliances detection feature will automatically restart operation on a channel free of radar. • The 5 GHz Turbo Mode feature is not allowed for operation in any European Community country. The current setting for this feature is found in the 5 GHz 802.11a Radio Settings Window as described in the user guide.
  • Page 91 Operation Using 5 GHz Channels in the European Community The user/installer must use the provided configuration utility to check the current channel of operation and make necessary configuration changes to ensure operation occurs in conformance with European National spectrum usage laws as described below and elsewhere in this document.
  • Page 92 Radio LAN device in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG Bij deze SMC Networks dat deze Radio LAN device voldoet aan de essentiële eisen en aan de overige relevante bepalingen van Richtlijn 1999/5/EC.
  • Page 93 Radio LAN device cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE Portuguese SMC Networks declara que este Radio LAN device está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.

  • Page 94: Safety Compliance

    Compliances C.3 | Safety Compliance Underwriters Laboratories Compliance Statement Important! Before making connections, make sure you have the correct cord set. Check it (read the label on the cable) against the following: Operating Voltage 120 Volts 240 Volts (Europe only) The unit automatically matches the connected input voltage.
  • Page 95 Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
  • Page 96 Fax 34 93 477 3774 Fax 216-71751415 Fax 34 93 477 3774 Fax 7 (095) 789 35 73 Fax 86-10-6235-4962 Fax 886-2-8797-6288 Fax (65) 238 6466 Fax 82-2-553-7202 Fax 81-45-224-2331 Fax 61-2-8875-7777 Fax 91-22-8204443 Model Number: SMC2304WBR-AG Revision number: E122003-R01 F1.0...
