Beijing Choice Electronic Technology MD300K3 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
V1.0K3
Our company owns all rights of this unpublished work and intends to maintain it as a
confidential work. We may also seek to maintain this work as an unpublished copyright.
This publication is to be used solely for the purpose of reference or operation of our device.
No part of this work can be disseminated for other purposes.
In the event of inadvertent or deliberate publication, we intend to enforce its rights to this
work under copyright laws as a published work. Those having access to this work may not
copy, use, or disclose the information in this work unless expressly authorized by our
company.
All information contained in this publication is believed to be correct. We shall not be liable
for errors contained herein nor for incidental or consequential damages in connection with
the furnishing, performance, or use of this material. The information this publication refers
to is protected by copyrights or patents and does not convey any license under the patent
rights of our company, nor the rights of others. We do not assume any liability arising out of
any infringements of patents or other rights of third parties.
Content of the manual is subject to change without prior notice.
ALL RIGHTS RESERVED
®
®
Bluetooth
and the Bluetooth
Logo are registered trademarks of Bluetooth
Inc.
®
®
®
Windows98
, 2000
, XP
are registered trademarks of Microsoft Corporation.
V1.0K3
PULSE OXIMETER INSTRUCTION MANUAL
Copyright
Issue date: 13th October, 2010
0
®
SIG,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD300K3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beijing Choice Electronic Technology MD300K3

Summary of Contents for Beijing Choice Electronic Technology MD300K3

  • Page 1 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Copyright Our company owns all rights of this unpublished work and intends to maintain it as a confidential work. We may also seek to maintain this work as an unpublished copyright. This publication is to be used solely for the purpose of reference or operation of our device. No part of this work can be disseminated for other purposes.

  • Page 2: Table Of Contents

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Contents 1 Introduction ..................... 2 1.1 Brief Introduction....................2 1.2 Safety Information ....................2 1.3 Intended use......................4 1.4 Electromagnetism Interference ................. 4 1.5 Explanation of Symbols ..................5 1.6 Product Features ....................5 2 General Descriptions................6 2.1 Appearance ......................

  • Page 3: Introduction

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL 1 Introduction 1.1 Brief Introduction Thank you for purchasing the pulse oximeter. The main functions of the device include Haemoglobin Saturation (SpO ) and pulse rate (PR) measurements, visual and audible ® alarm, batteries charging, data storage and review, USB cable and Bluetooth for data transmission, etc.
  • Page 4 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL skin deterioration, and discomfort. When connecting this device to other peripherals, make sure that you are qualified to operate this device. Any peripheral must be certified according to the protocol of IEC 950 and IEC 601-1-1. Any input/output device should follow the protocol of IEC 601-1-1.

  • Page 5: Intended Use

    As to the other concerns for attention, please carefully look through the specific chapter in this instruction. 1.3 Intended use The MD300K3 handheld pulse oximeter is a portable, non-invasive device intended for continuous monitoring, spot checking of functional arterial oxygen saturation(SpO ) and pulse rate of adult and pediatric patients in hospital and home care.

  • Page 6: Explanation Of Symbols

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL levels of such interference due to close proximity or strength of a source, may result in disruption of performance of this device. This apparatus complies with the IEC 60601-1-2 international standard. The requirements of this international standard are: CISPR11, GROP1, and CLASS B. 1.5 Explanation of Symbols Symbol Explanation...

  • Page 7: Product Features

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL 1.6 Product Features Simple to use and easy to operate. Portable and compact in design. TFT display screen with adjustable backlight. Up to 127 patients’ ID and 72-hour records can be saved. Visual and three-level audible alarms, low battery power alarm. ®...
  • Page 8 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Fig.2-1 Description of Fig.2-1： (1) Fixing clip for the SpO probe. (2) Displaying screen. Print Button: Press this button to turn on/off the function of printing. OK Button: Press this button to enter menu items or confirm the selection/setting.
  • Page 9 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Up Button: Press this button shortly to increase the value by one unit. You can press and hold the button extendedly to speed up the adjustment of values. Alarm inhibition button: Press this button to close alarm sound for 120 seconds.

  • Page 10: Rear Panel

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL 2.2 Rear Panel (1) Paper Feed button: when the printing function is on, press this button you can start printing. (2) Outlet: the outlet for printing paper. (3) The groove for installing the printing paper. (4) The cover of battery compartment.
  • Page 11 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Fig.2-3 Warnings! DO NOT USE Ni-MH rechargeable and alkaline batteries together, otherwise, that may damage the device or injury users. Make sure the polarities of the batteries are correct. 3) Close the battery cover. Battery life When the battery power is lower than 4.5V±0.1V the battery indicator will become empty and at the same time its frame will become red, which means little of battery capacity remains.

  • Page 12: Install Spo Probe

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Do not use batteries of different types together. Do not use new and used batteries together. Dispose of batteries in accordance with the local ordinances and regulations. Regular maintenance of rechargeable batteries is required, such as periodic charge and discharge.

  • Page 13: Setting Id, Date And Time

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL shown in Fig.3-1. When the SpO probe is connected well, please set the fixing clip up to ensure the probe well connected. Fig.3-1 The indicator will be shown on the display screen when the probe is well connected. If the probe is disconnected from the unit, the indicator and the prompt “Probe Off！...

  • Page 14: Id Number Setting

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Fig.4-1 2) Press the Down button to select the “Date and Time” item, and then press the Menu button to enter the time setup screen, refer to Fig.4-2. Fig.4-2 Pick different sub-items to set and press the OK button to highlight it and then using the Up or Down button to adjust the value.

  • Page 15: Take A Measurement

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL that “Cannot change!!!”, if you attempt to change it when taking a measurement. Fig.4-3 5 Take a Measurement Warnings! The measurement would not be performed if the following instances come across in operation: Shock Low temperature of hand Have taken vascular activity medicine Anemia carboxyhemoglobin...
  • Page 16 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL xenon light source), bilirubin lamps, fluorescent lights, infrared heating lamps, or direct sunlight; High-frequency electro surgical interference and defibrillators; Venous pulsations; Placement of a probe on an extremity with a blood pressure cuff, arterial catheter, or intravascular line;...
  • Page 17 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Fig.5-2 Digital display Fig.5-3 Wave display Status bar 1: The status of the oximeter is shown on the bar (Measure… , Finger out!!, Probe off!! and so on). Status bar 2: If the measured SpO % or PR value exceeds the alarm limits, there will be corresponding information.

  • Page 18: Other Settings

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL ◆The color of the PR value will become yellow when the PR value exceeds the alarm limits. ◆It shows three dashes throughout probe off and finger out conditions. 15:00: The current time. 6 Other Settings 6.1 Alarm Setting From the main menu, select and enter the “Alarm setting”...

  • Page 19: Data Management

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL × with “ ”. Note: Please caution the alarm off item, it may cause damages to users. ALARM PRIORITY Alarms of the oximeter include technical and physiological alarms. All the three priorities are divided by built-in module and can not be changed by users. High priority: indicates the patient is in the very dangerous situation.
  • Page 20 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL manually for free space. Fig.6-2 6.2.1 Data Review Pick and enter the “Data Review” sub-item, the screen as shown in Fig.6-3 will appear. You can move the rolling bar to view all the records that have saved in the unit by pressing the Up or Down button.
  • Page 21 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Press the OK button, a dialog box will pop up, refer to Fig.6-6. After selecting a ID number, press the Up or Down button to select “Delete” or “Review” and then press the OK button to confirm, you can delete or review all the SpO trends saved under this ID.
  • Page 22 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Fig.6-7 In the data management screen, the upper half screen will display the maximum, minimum and average values of SpO and PR for the current ID. Refer to Fig.6-8. Fig.6-8 6.2.5 Copy to SD The SD card is only as a transfer media for data transmission from the unit to PC. By entering this item you can copy the saved data in the unit to the inserted SD card manually, and then through the SD card reader transfer data to PC.

  • Page 23: System Setting

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL 6.3 System Setting From the main menu, select and enter the System Setting screen, refer to Fig.6-9&6-10. Press the Up or Down button to pick the different sub-items to set and press the Select button to enter. Fig.6-9 Fig.6-10 6.3.1 Brightness...
  • Page 24 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL The beep on or off can be displayed in the main screen by the symbol 6.3.4 Display Mode You can set the display mode Digital or Wave by entering the Display Mode sub-item. First press the OK button to highlight it and then press the Up or Down button to select Digital or Wave item, last press the OK button again to confirm your selection.
  • Page 25 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Press the Paper Feed button on the top of the rear panel, then the unit will begin printing. You can end the current printing by pressing the PRINT button. If the printing paper is not installed, the steps for printing are as follows: Set the Print ON in the system setting menu firstly.

  • Page 26: Maintain And Repair

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL 6.3.9 About Enter the About screen from the System Setting screen, the version of software is displayed. 7 Maintain and Repair 7.1 Maintenance Use only the substances approved by us and methods listed in this chapter to clean or disinfect your equipment.
  • Page 27 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Make sure that only specified accessories are applied. Inspect if the alarm system functions correctly. Make sure that the batteries meet the performance requirements. Make sure that the pulse oximeter is in good working condition. In case of any damage or abnormity, do not use the pulse oximeter.

  • Page 28: Calibration And Verification

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Battery maintenance ○Please take out battery if you will not use the monitor for a long time. ○Please charge the battery fully if you will not use it for a long time. ○Please charge over 14 hours at the first time, or may reduce the battery life. If any abnormal phenomena occurs, should stop using immediately and reuse after inspection by technical person.

  • Page 29: Trouble Shooting

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL 7.3.4 SpO2 & PR Alarm Verification a). Connect SpO Probe to the SpO connector on the oximeter. b). Insert the operator’s finger into the finger probe, the SpO2 measured value of healthy person should be more than 96%. c).
  • Page 30 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL labor and capital bother, strike and stop-working etc. b) No-service offer The corresponding fee and insurance fee of disassembly, refurbishment, repackaging and conveying of the oximeter or the part of it doesn’t comply with the instruction manual.

  • Page 31: Storage And Transportation

    V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL ●Not-original package lead to oximeter during transportation ●Not-professional person operation leads to oximeter failure. Not our company professionals or authorized personnel disassemble oximeter and lead to oximeter failure. ●Not carefully read manual and so wrong operation lead to oximeter damage and failure. 7.5.5 User’s Special Request for Guarantee Time Our guarantee constitution for oximeter complies with electronic product after-sale service standard regulated by national laws.
  • Page 32 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL personnel authorized by our company. Display Data: SpO %, PR, pulse bar, plethysmogram; Others: connection status of probe and other alarm information; Data update time: less than 5 seconds; Display range: 0%~100% Measurement range: 70%~100% Resolution: Accuracy: 70-100%：±3%；...
  • Page 33 V1.0K3 PULSE OXIMETER INSTRUCTION MANUAL Working Distance: 20-100m Interface: USB 1.1 Operation system: Windows98 ® , 2000 ® , XP ® Classification According to the type of protection against electric shock: Internal powered equipment and class II equipment; According to the degree of protection against electric shock: Type BF applied part;...
  • Page 34 Optional accessories: 1. One Power adapter. 2. Four AA Ni-MH batteries. 3. One disposable sponge wrap sensor for adult: Model: M-50J. Manufacturer address：Beijing Choice Electronic Technology Co.，Ltd. Bailangyuan Building B Rm. 1127-1128, Fuxing Road, A36 100039 Beijing PEOPLE’S REPUBLIC OF CHINA...
  • Page 35 FCC ID: WWIMD300K3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
