- Page 1 Instruction Manual HLSD-2 Circular Access Tank Cover TE91K041 First published: 08-2012 ESE02264-EN4 2018-02 Original manual...
-
Page 3: Table Of Contents
7. Technical and physical data ................. 7.1. Standard ................... 7.2. Options .................... 7.3. Selection table ..................7.4. Certificates ..................8. General information ................... 8.1. Service & Repair .................. 8.2. Warranty - definition ................8.3. Warranty ................... 8.4. How to contact Alfa Laval Kolding A/S ............ -
Page 4: Ec Declaration Of Conformity
Phone No. hereby declare that Cover Designation HLSD-2 Circular Access Tank Cover Type From serial number 2015-00001 to 2030-99999 was manufactured in conformity with DIRECTIVE 97/23/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 29 May 1997 on the approximation of the laws of the Member States concerning pressure equipment. -
Page 5: Safety
2 Safety Unsafe practices and other important information are emphasized in this manual. Warnings are emphasized by means of special signs. Always read the manual before using the cover! 2.1 Important information WARNING Indicates that special procedures must be followed to avoid serious personal injury. CAUTION Indicates that special procedures must be followed to avoid damage to the cover. -
Page 6: Introduction
3 Introduction Study the instructions carefully and pay special attention to the warnings! 3.1 Introduction and general description This instruction manual has been prepared as a guide for the persons who will be operating/handling the HLSD-2 Circular Access Tank Covers. Warning: The service personnel must be acquainted with the content of these instructions in order to avoid operating errors. -
Page 7: Installation
Outward opening manhole cover type HLSD-2 is used on top of pressurized tanks and containers where closeable means of access to the interior of the vessel is required. HLSD-2 is approved and can be used on pressure vessels according to PED 97/23/EC. -
Page 8: Operation
5 Operation Study the instructions carefully and pay special attention to the warnings! 5.1 Safety regulations Warning: All operators must be trained / certified to work in the area of the container operation and must abide by the site safety regulations. All work on the cover must be carried out by competent staff with knowledge of the relevant rules of operation of container and pressure container. -
Page 9: Assembly
5.5 Material lifetime As the customer selects the material by order, no warranty in relation to material lifetime is offered by Alfa Laval Kolding A/S. It is the responsibility of the operator to make sure, that product coming in contact with the cover or seal, are suitable and the materials and seal are sufficiently resistant to the product / conditions. -
Page 10: Opening Of Cover
5 Operation Study the instructions carefully and pay special attention to the warnings! 5.7 Opening of cover The operator is responsible for the safe opening of the cover. Before opening the cover, ensure the container is checked to be free from pressure, heat and chemical vapours. If necessary, protective clothing and protective eyewear have to be used especially for high temperatures, for caustic or toxic liquid applications etc. -
Page 11: Maintenance
Cover has to be checked regularly for damage (e.g. gasket, gasket seating, nut / screw and complete swing assembly, hinge, spring, etc. - Only Alfa Laval recommended spare parts to be used). We recommend inspection of each cover at least annually against mechanical damage, corrosion and tightness. -
Page 12: Technical And Physical Data
7.1 Standard The HLSD-2 pressure cover is designed according to Merkblatter AD 2000 newest edition and designed for installation in pressure vessels until hazard category IV. The cover is not pressure tested and must be tested as a part of the pressure vessel. -
Page 13: Selection Table
7 Technical and physical data Study the instructions carefully and pay special attention to the warnings! 7.3 Selection table Cover Max. allowable pressure PS (bar) at design Max. test thickness Number of Cover Size pressure temperature Td (°C) (SL) bolts radius Ptest 50°C... -
Page 14: General Information
Study the instructions carefully and pay special attention to the warnings! 8.1 Service & Repair Upon every return of a product, no matter if for modifications or repair, it is necessary to contact your local Alfa Laval office to guarantee a quick execution of your request. -
Page 15: How To Contact Alfa Laval Kolding A/S
8 General information Study the instructions carefully and pay special attention to the warnings! 8.4 How to contact Alfa Laval Kolding A/S For further information please feel free to contact: Alfa Laval Kolding A/S 31, Albuen - DK 6000 Kolding - Denmark... - Page 16 © Alfa Laval Corporate AB This document and its contents is owned by Alfa Laval Corporate AB and protected by laws governing intellectual property and thereto related rights. It is the responsibility of the user of this document to comply with all applicable intellectual property laws. Without limiting any rights related to this document, no part of this document may be copied, reproduced or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the expressed permission of Alfa Laval Corporate AB.
