A S S E M B LY I N S T R U C T I O N S

Advertisement

loading
Need help?

Need help?

Do you have a question about the HG3060 and is the answer not in the manual?

Questions and answers

Summary of Contents for Insportline HG3060

  • Page 1 A S S E M B LY I N S T R U C T I O N S...
  • Page 2 - 2 -...
  • Page 3: Parts List

    PARTS LIST NUMBER DESCRIPTION QUANTITY JOINT BASE JOINT TUBE STRAIGHT BASE UPRIGHT FRAME ADJUSTMENT TUBE AXES STRAIGHT BEAM GUIDE ROD TOP JOINT TUBE TOP CROSS BEAM JOINT BEAM JOINT ROD ADJUSTABLE PULLEY BLOCK PULLEY BLOCK SWIVEL PULLEY BLOCK (I) SWIVEL PULLEY BLOCK (II) SWIVEL PULLEY BLOCK (III) SWIVEL PULLEY BLOCK (IV) TOP PLATE...
  • Page 4 HEX HEAD BOLT M10*80 HEX HEAD BOLT M10*85 HEX HEAD BOLT M10*70 SQUARE NECK BOLT M10*95 HEX HEAD BOLT M10*95 R-WASHER 8 BIG WASHER 8 R-WASHER 10 WASHER 10 NUT M10 LOCK NUT M8 BIG WASHER-13 - 4 -...
  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS STEP 1 1. Attach straight base (C) to joint base (A) with (17), (29) and (30). 2. Attach joint tube (B) to straight base (C) with (17), (18), (29) and (30). 3. Attach swivel pulley block I (O) to joint base (A) with (4), (12) and (27). 4.
  • Page 6 STEP 2 - 6 -...
  • Page 7 7. Slide big washer (5) and rubber donut (3) onto guide rod (H). 8. Slide weight plate (T) onto guide rod (H), insert selector rod (U) into weight plate (T) with pin (8). 9. Attach secure bushing (V) and secure pin (W) to selector rod (U), then slide top plate (S) onto guide rod (H), attach swivel pulley block IV (R) with (16) and big washer (32) to selector rod (U) as shown.
  • Page 8 CABLE 1 - 8 -...
  • Page 9 CABLE 2 - 9 -...
  • Page 10 CABLE 3 - 10 -...
