Page 1 OZENDA 11g Wireless ADSL Firewall Router Model: AR4505GW...
Page 2 OZENDA 11g Wireless ADSL Firewall Router...
Page 3: Table Of Contents
Introduction ....... . . 1-1 About the ADSL Router ........1-1 Features and Benefits .
Page 4 Status ..........4-59 Finding the MAC address of a Network Card ....4-60 Windows 98/ME .
Page 5 ABLE OF ONTENTS Specifications ....... . C-1...
Page 6 ABLE OF ONTENTS...
Page 7: Introduction
Congratulations on your purchase of the IEEE 802.11g ADSL Router, hereafter referred to as the “ADSL Router”. We are proud to provide you with a powerful yet simple communication device for connecting your local area network (LAN) to the Internet. For those who want to surf the Internet in the most secure way, this router provides a convenient and powerful solution.
Page 8: Applications
NTRODUCTION • Firewall with Stateful Packet Inspection, client privileges, intrusion detection, and NAT • NAT also enables multi-user Internet access via a single user account, and virtual server functionality (providing protected access to Internet services such as web, FTP, email, and Telnet) •...
Page 9: Virtual Server
• Shared IP Address The ADSL Router provides Internet access for up to 253 users via a single shared IP address. Using only one ISP account, multiple users on your network can browse the web at the same time. • Virtual Server If you have a fixed IP address, you can set the ADSL Router to act as a virtual host for network address translation.
Page 10 NTRODUCTION...
Page 11: Installation
Before installing the ADSL Router, verify that you have all the items listed under the Package Contents list. If any of the items are missing or damaged, contact your local distributor. Also be sure that you have all the necessary cabling before installing the ADSL Router. After installing the ADSL Router, refer to “Configuring the ADSL Router”...
Page 12: System Requirements
NSTALLATION System Requirements You must meet the following minimum requirements: • ADSL line installed by your Internet Service Provider. • A PC using a fixed IP address or dynamic IP address assigned via DHCP, as well as a gateway server address and DNS server address from your service provider.
Page 13 Figure 2-1. Rear Panel Item Description LAN Ports Fast Ethernet ports (RJ-45). Connect devices on your local area network to these ports (i.e., a PC, hub, or switch). Power Press this button to turn on/turn off the ADSL Router. button Reset Button Use this button to reset the power and restore the default factory settings.
Page 14: Led Indicators
NSTALLATION LED Indicators The power and port LED indicators on the front panel are illustrated by the following figure and table. Figure 2-2. Front Panel Status ADSL Flashing Flashing (4 LEDs) Flashing Description The ADSL Router is receiving power. Normal operation.
Page 15: Isp Settings
ISP Settings Please collect the following information from your ISP before setting up ADSL Router • ISP account user name and password • Protocol, encapsulation and VPI/VCI circuit numbers • DNS server address • IP address, subnet mask and default gateway (for fixed IP users only) Connect the System The ADSL Router can be positioned at any convenient location in your office or home.
Page 16: Phone Line Configuration
NSTALLATION Phone Line Configuration Installing a Full-Rate Connection If you are using a full-rate (G.dmt) connection, your service provider will attach the outside ADSL line to a data/voice splitter. In this case you can connect your phones and computer directly to the splitter as shown below: Plain Old Telephone System (POTS)
Page 17: Installing A Splitterless Connection
Installing a Splitterless Connection If you are using a splitterless (G.lite) connection, then your service provider will attach the outside ADSL line directly to your phone system. In this case you can connect your phones and computer directly to the incoming ADSL line, but you will have to add low-pass filters to your phones as shown below: Plain Old...
Page 18: Attach To Your Network Using Ethernet Cabling
NSTALLATION Attach to Your Network Using Ethernet Cabling The four LAN ports on the ADSL Router auto-negotiate the connection speed to 10 Mbps Ethernet or 100 Mbps Fast Ethernet, as well as the transmission mode to half duplex or full duplex. Use RJ-45 cables to connect any of the four LAN ports on the ADSL Router to an Ethernet adapter on your PC.
Page 19 HAPTER ONFIGURING LIENT After completing hardware setup by connecting all your network devices, you need to configure your computer to connect to the ADSL Router. See: “Windows 98/Me” on page 3-3 “Windows NT 4.0” on page 3-8 “Windows 2000” on page 3-12 “Windows XP”...
Page 20: Configuring Client Pc
ONFIGURING LIENT TCP/IP Configuration To access the Internet through the ADSL Router, you must configure the network settings of the computers on your LAN to use the same IP subnet as the ADSL Router. The default IP settings for the ADSL Router are: IP Address Subnet Mask DHCP function...
Page 21: Windows 98/Me
Windows 98/Me You may find that the instructions in this section do not exactly match your version of Windows. This is because these steps and screen shots were created from Windows 98. Windows Millennium Edition is similar, but not identical, to Windows 98. 1.
Page 22 LIENT 3. In the Network window, under the Configuration tab, double-click the TCP/IP item listed for your network card. 4. In the TCP/IP window, select the IP Address tab. If “Obtain an IP address automatically” is already selected, your computer is already configured for DHCP.
Page 23: Disable Http Proxy
5. Windows may need your Windows 98/Me CD to copy some files. After it finishes copying, it will prompt you to restart your system. Click Yes and your computer will restart. TCP/IP Configuration Setting Primary DNS Server Secondary DNS Server Default Gateway Host Name Disable HTTP Proxy...
Page 24 ONFIGURING LIENT 3. In the Internet Options window, click the Connections tab. Next, click the LAN Settings... button. 4. Clear all the check boxes. 5. Click OK, and then click OK again to close the Internet Options window.
Page 25: Obtain Ip Settings From Your Adsl Router
It may take a second or two for the IP Configuration window to appear. 3. In the IP Configuration window, select your network card from the drop-down menu. Click Release and then click Renew. Verify that your IP address is now 192.168.2.xxx, your Subnet...
Page 26: Windows Nt 4.0
ONFIGURING LIENT Windows NT 4.0 1. On the Windows desktop, click Start/Settings/Control Panel. 2. Double-click the Network icon.
Page 27 3. In the Network window, Select the Protocols tab. Double-click TCP/IP Protocol. 4. When the Microsoft TCP/IP Properties window open, select the IP Address tab. 5. In the Adapter drop-down list, be sure your Ethernet adapter is selected. 6. If “Obtain an IP address automatically”...
Page 28: Disable Http Proxy
ONFIGURING LIENT 8. Windows may copy some files, and will then prompt you to restart your system. Click Yes and your computer will shut down and restart. TCP/IP Configuration Setting Default Gateway Primary DNS Server Secondary DNS Server Host Name Disable HTTP Proxy You need to verify that the “HTTP Proxy”...
Page 29 2. In the Command Prompt window, type “IPCONFIG /RELEASE” and press the ENTER key. 3. Type “IPCONFIG /RENEW” and press the ENTER key. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1. These values confirm that your ADSL Router is functioning.
Page 30: Windows 2000
ONFIGURING LIENT Windows 2000 1. On the Windows desktop, click Start/Settings/Network and Dial-Up Connections. 2. Click the icon that corresponds to the connection to your ADSL Router. 3. The connection status screen will open. Click Properties. 4. Double-click Internet Protocol (TCP/IP). 5.
Page 31: Disable Http Proxy
Disable HTTP Proxy You need to verify that the “HTTP Proxy” feature of your web browser is disabled. This is so that your browser can view the ADSL Router’s HTML configuration pages (refer to “Internet Explorer” on page 3-5). Obtain IP Settings from Your ADSL Router Now that you have configured your computer to connect to your ADSL Router, it needs to obtain new network settings.
Page 32 ONFIGURING LIENT 3. Type “IPCONFIG /RENEW” and press the ENTER key. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1. These values confirm that your ADSL Router is functioning. 4. Type “EXIT” and press the ENTER key to close the Command Prompt window.
Page 33: Windows Xp
Windows XP 1. On the Windows desktop, click Start/Control Panel. 2. In the Control Panel window, click Network and Internet Connections. 3. The Network Connections window will open. Double-click the connection for this device. 4. On the connection status screen, click Properties. 5.
Page 34: Disable Http Proxy
ONFIGURING LIENT Disable HTTP Proxy You need to verify that the “HTTP Proxy” feature of your web browser is disabled. This is so that your browser can view the ADSL Router’s HTML configuration pages (refer to “Internet Explorer” on page 3-5). Obtain IP Settings from Your ADSL Router Now that you have configured your computer to connect to your ADSL Router, it needs to obtain new network settings.
Page 35: Configuring Your Macintosh Computer
Configuring Your Macintosh Computer You may find that the instructions here do not exactly match your operating system. This is because these steps and screen shots were created using Mac OS 10.2. Mac OS 7.x and above are similar, but may not be identical to Mac OS 10.2.
Page 36: Disable Http Proxy
ONFIGURING LIENT 3. If “Using DHCP Server” is already selected in the Configure field, your computer is already configured for DHCP. If not, select this Option. 4. Your new settings are shown on the TCP/IP tab. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1.
Page 37 ONFIGURING ACINTOSH OMPUTER 3. Uncheck all check boxes and click OK. 3-19...
Page 38 ONFIGURING LIENT 3-20...
Page 39 HAPTER ADSL ONFIGURING THE OUTER After you have configured TCP/IP on a client computer, you can configure the ADSL Router using Internet Explorer 5.5 or above. To access the ADSL Router’s management interface, enter the default IP address of the ADSL Router in your web browser: http://192.168.2.1.
Page 40: Configuring The Adsl Router
ADSL R ONFIGURING THE Navigating the Management Interface The ADSL Router’s management interface consists of 12 main items. Setup Wizard: Use the Setup Wizard if you want to quickly set up the ADSL Router. Go to “SETUP WIZARD” on page 4-3. Advanced Setup: Advanced Setup supports more advanced functions like hacker attack detection, IP and MAC address filtering, virtual server setup, virtual DMZ host, as well as other functions.
Page 41: Setup Wizard
SETUP WIZARD Channel and SSID Click on “SETUP WIZARD” and “NEXT”, then you will see the Channel and SSID page. Parameter ESSID ESSID Broadcast Enable or disable the broadcasting of the SSID. Wireless Mode Channel Click “NEXT” to continue. Description Extended Service Set ID.
Page 42: Parameter Setting
ADSL R ONFIGURING THE Parameter Setting Select your Country and Internet Service Provider. This will automatically configure the ADSL Router VPI/VCI settings for your ISP. If your Country or Internet Service Provider is not listed you will need to manually enter settings. Go to “Parameter Setting - Country or ISP Not Listed”...
Page 43: Confirm
Confirm The Confirm page shows a summary of the configuration parameters. Check ADSL operation mode (WAN), Network Layer Parameters (WAN) and DHCP parameters are correct. Parameter ADSL Operation Mode (WAN) Protocol VPI/VCI AAL5 Encapsulation Shows the packet encapsulation type. Go to page 4-20 for Network Layer Parameters (WAN) IP Address...
Page 44 ADSL R ONFIGURING THE Parameter DHCP Parameters Function Default Gateway Subnet Mask Name Server 1 Name Server 2 Start IP Address Number of IP If the parameters are correct, click “NEXT” to save these settings. OUTER Description Shows the DHCP function is enabled or disabled. LAN IP address of the ADSL Router.
Page 45: Parameter Setting - Country Or Isp Not Listed
SETUP WIZARD Parameter Setting - Country or ISP Not Listed If your Country or Internet Service Provider is not listed on the drop down menu, select “Others”. This will allow you to manually configure your ISP settings. For manual configuration you will need to know the Protocol, DNS Server, Encapsulation and VPI/VCI settings used by your ISP.
Page 46 ADSL R ONFIGURING THE ISP use Bridging - Parameter Setting Enter the Bridging settings provided by your ISP. Parameter Management IP Address VPI/VCI Encapsulation Click “NEXT” to continue to the “Confirm” settings page. Go to “Confirm” on page 4-5 in the manual for details about the “Confirm”...
Page 47 ISP use 1483 Bridging - Parameter Setting Enter the RFC1483 Bridging settings provided by your ISP. Parameter DNS Server VPI/VCI Encapsulation Click “NEXT” to continue to the “Confirm” settings page. Go to “Confirm” on page 4-5 in the manual for details about the “Confirm”...
Page 48 ADSL R ONFIGURING THE ISP use PPPoE - Parameter Setting Enter the PPPoE (Point-to-Point Protocol over Ethernet) settings provided by your ISP. Parameter DNS Server VPI/VCI Encapsulation Username Password Confirm Password Click “NEXT” to continue to the “Confirm” settings page. Go to “Confirm”...
Page 49 ISP use PPPoA - Parameter Setting Enter the PPPoA (Point-to-Point Protocol over ATM) settings provided by your ISP. Parameter DNS Server VPI/VCI Encapsulation Username Password Confirm Password Click “NEXT” to continue to the “Confirm” settings page. Go to “Confirm” on page 4-5 in the manual for details about the “Confirm”...
Page 50 ADSL R ONFIGURING THE ISP use 1483 Routing - Parameter Setting Enter the 1483 Routing settings provided by your ISP. Parameter IP Address Subnet Mask Default Gateway DNS Server VPI/VCI Encapsulation Click “NEXT” to continue to the “Confirm” settings page. Go to “Confirm”...
Page 51: Advanced Setup
Advanced Setup Click on Home which is located on the upper right-hand corner. The left-hand side displays the main menu and the right-hand side shows descriptive information. The advanced management interface contains 11 main menu items as described in the following table. Menu Description SYSTEM...
Page 52 ADSL R ONFIGURING THE Menu Description ADSL Sets the ADSL operation type and shows the ADSL status. TOOLS Contains options to backup & restore the current configuration, restore all configuration settings to the factory defaults, update system firmware, or reset the system. STATUS Provides WAN connection type and status, firmware and hardware version numbers, system IP settings, as well as DHCP, NAT, and...
Page 53: System
DVANCED ETUP SYSTEM Time Settings Select your local time zone from the drop down list. This information is used for log entries and client filtering. For accurate timing of log entries and system events, you need to set the time zone. Select your time zone from the drop down list. If you want to automatically synchronize the ADSL router with a public time server, check the box to Enable Automatic Time Server Maintenance.
Page 54: Password Settings
ADSL R ONFIGURING THE Password Settings Use this page to change the password for accessing the management interface of the Passwords can contain from 3~12 alphanumeric characters and are case sensitive. Note: If you lost the password, or you cannot gain access to the user interface, press the blue reset button on the rear panel, holding it down for at least five seconds to restore the factory defaults.
Page 55: Remote Management
DVANCED ETUP Remote Management By default, management access is only available to users on your local network. However, you can also manage the ADSL Router from a remote host by entering the IP address of a remote computer on this screen. Check the Enabled check box, and enter the IP address of the Host Address and click “SAVE SETTINGS”.
Page 56 ADSL R ONFIGURING THE Domain Name Servers (DNS) are used to map a domain name (e.g., www.smc.com) with the IP address (e.g., 64.147.25.20). Your ISP should provide the IP address of one or more Domain Name Servers. Enter those addresses on this page, and click “SAVE SETTINGS”. 4-18 OUTER...
Page 57: Wan
Specify the WAN connection parameters provided by your Internet Service Provider (ISP). ADSL Router ways: • ATM PVC • Clone MAC can be connected to your ISP in one of the following DVANCED ETUP 4-19...
Page 58 ADSL R ONFIGURING THE ATM PVC Enter the ATM (Asynchronous Transfer Mode) virtual connection parameters here. Parameter Description VPI/VCI Encapsulation Protocol 4-20 OUTER Description Click on the VC to set the values for the connection. Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI).
Page 59 DVANCED ETUP Clone MAC Address Some ISPs require you to register your MAC address with them. If this is the case, the MAC address of the ADSL Router must be changed to the MAC address that you have registered with your ISP. 4-21...
Page 60: Lan
ADSL R ONFIGURING THE Use the LAN menu to configure the LAN IP address and to enable the DHCP server for dynamic client address allocation. Parameter IP Address IP Subnet Mask DHCP Server Lease Time Start IP Address End IP Address Domain Name Note: Remember to configure your client PCs for dynamic address allocation.
Page 61: Wireless
DVANCED ETUP Wireless also operates as a wireless access point, allowing wireless ADSL Router computers to communicate with each other. To configure this function, you need to enable the wireless function, define the radio channel, the domain identifier, and the security options. Check Enable and click “SAVE SETTINGS”.
Page 62 ADSL R ONFIGURING THE Channel and SSID You must specify a common radio channel and SSID (Service Set ID) to be used by the ADSL Router configure all of its clients to the same values. Parameter ESSID ESSID Broadcast Enable or disable the broadcasting of the SSID. Wireless Mode Channel 4-24...
Page 63 DVANCED ETUP Security To make your wireless network safe, you should turn on the security function. The ADSL Router supports WEP (Wired Equivalent Privacy), WPA (Wi-Fi Protected), and 802.1x security mechanisms. 4-25...
Page 64 ADSL R ONFIGURING THE If you use WEP to protect your wireless network, you need to set the same parameters for the ADSL Router and all your wireless clients. Parameter WEP Mode Key Entry Method Select Hex or ASCII code for encryption key generation. Key Provisioning You may automatically generate encryption keys or manually enter the keys.
Page 65 To manually configure the encryption key, enter five hexadecimal pairs of digits for each 64-bit key, or enter 13 pairs for the single 128-bit key. (A hexadecimal digit is a number or letter in the range 0-9 or A-F.) Note that WEP protects data transmitted between wireless nodes, but does not protect any transmissions over your wired network or over the Internet.
Page 66 ADSL R ONFIGURING THE 802.1X If 802.1x is used in your network, then you should enable this function for the ADSL Router. These parameters are used for the ADSL Router to connect to the authentication server. Parameter 802.1X Authentication Session Idle timeout Re-Authentication Period...
Page 67 Parameter Description Secret Key The secret key shared between the authentication server and its clients. NAS-ID Defines the request identifier of the Network Access Server. DVANCED ETUP 4-29...
Page 68: Nat
ADSL R ONFIGURING THE Network Address Translation allows multiple users to access the Internet sharing one public IP. Address Mapping Allows one or more public IP addresses to be shared by multiple internal users. This also hides the internal network for increased privacy and security.
Page 69: Virtual Server
DVANCED ETUP Virtual Server If you configure the ADSL Router as a virtual server, remote users accessing services such as web or FTP at your local site via public IP addresses can be automatically redirected to local servers configured with private IP addresses.
Page 70 ADSL R ONFIGURING THE Special Applications Some applications require multiple connections, such as Internet gaming, video-conferencing, and Internet telephony. These applications may not work when Network Address Translation (NAT) is enabled. If you need to run applications that require multiple connections, use these pages to specify the additional public ports to be opened for each application.
Page 71: Nat Mapping Table
DVANCED ETUP NAT Mapping Table This page displays the current NAPT (Network Address Port Translation) address mappings. 4-33...
Page 72: Route
ADSL R ONFIGURING THE Route These pages define routing related parameters, including static routes and RIP (Routing Information Protocol) parameters. Static Route Click “Add” to add a new static route to the list. Parameter Network Address Subnet Mask Gateway Click “Save Settings” to save the configuration. 4-34 OUTER Description...
Page 73 Parameter General RIP Parameters RIP mode Auto summary Table of current Interface RIP parameter Interface Operation Mode Version Poison Reverse Description Globally enables or disables RIP. If Auto summary is disabled, then RIP packets will include sub-network information from all sub- networks connected to the router.
Page 74 ADSL R ONFIGURING THE Parameter Authentication Required Authentication Code RIP sends routing-update messages at regular intervals and when the network topology changes. When a router receives a routing update that includes changes to an entry, it updates its routing table to reflect the new route.
Page 75: Routing Table
Routing Table Parameter Description Flags Indicates the route status: C = Direct connection on the same subnet. S = Static route. R = RIP (Routing Information Protocol) assigned route. I = ICMP (Internet Control Message Protocol) Redirect route. Network Destination IP address. Address Netmask The subnetwork associated with the destination.
Page 76: Firewall
ADSL R ONFIGURING THE Firewall ADSL Router maintains TCP and UDP session information including time-outs and the number of active sessions, and provides the ability to detect and prevent certain types of network attacks. Network attacks that deny access to a network device are called Denial-of-Service (DoS) attacks.
Page 77: Access Control
Access Control Access Control allows users to define the outgoing traffic permitted or not-permitted through the WAN interface. The default is to permit all outgoing traffic. The following items are on the Access Control screen: Parameter Enable Filtering Function Normal Filtering Table Displays the IP address (or an IP address range) filtering Description Click Yes to turn on the filtering function.
Page 78 ADSL R ONFIGURING THE To add the PC to the filtering table: 1. Click “Add PC” on the Access Control screen. 2. Define the appropriate settings for client PC services. 3. Click “OK” and then click “SAVE SETTINGS” to save your settings. 4-40 OUTER...
Page 79: Mac Filter
DVANCED ETUP MAC Filter The ADSL Router can also limit the network access based on the MAC address. The MAC Filtering Table allows the ADSL Router to enter up to 32 MAC addresses that are not allowed access to the WAN port. Click Yes to enable, or No to disable this function.
Page 80: Url Blocking
ADSL R ONFIGURING THE URL Blocking The ADSL Router allows the user to block access to web sites by entering either a full URL address or just a keyword. This feature can be used to protect children from accessing violent or pornographic web sites. You can define up to 30 sites here.
Page 81: Schedule Rule
DVANCED ETUP Schedule Rule You may filter Internet access for local clients based on rules. Each access control rule may be activated at a scheduled time. Define the time schedule on this page, and apply the rule on the Access Control page. 4-43...
Page 82 ADSL R ONFIGURING THE Follow these steps to add a schedule rule: 1. Click “Add Schedule Rule”. 2. Define the appropriate settings for a schedule rule (as shown in this example). 3. Click “OK” and then click “SAVE SETTINGS” to save your settings. 4-44 OUTER...
Page 83: Intrusion Detection
DVANCED ETUP Intrusion Detection • Intrusion Detection Feature Stateful Packet Inspection (SPI) and Anti-DoS firewall protection (Default: Enabled) — The Intrusion Detection Feature of the ADSL Router limits access for incoming traffic at the WAN port. When the SPI feature is turned on, all incoming packets will be blocked except for those types marked in the Stateful Packet Inspection section.
Page 84 ADSL R ONFIGURING THE OUTER 4-46...
Page 85: Stateful Packet Inspection
• Stateful Packet Inspection This is called a “stateful” packet inspection because it examines the contents of the packet to determine the state of the communications; i.e., it ensures that the stated destination computer has previously requested the current communication. This is a way of ensuring that all communications are initiated by the recipient computer and are taking place only with sources that are known and trusted from previous interactions.
Page 86 ADSL R ONFIGURING THE • Connection Policy Enter the appropriate values for TCP/UDP sessions as described in the following table. Parameter Fragmentation half-open wait TCP SYN wait TCP FIN wait TCP connection idle timeout UDP session idle timeout H.323 data channel idle timeout 4-48 OUTER...
Page 87 • DoS Criteria and Port Scan Criteria Set up DoS and port scan criteria in the spaces provided (as shown below). Parameter Defaults Description Total incomplete TCP/UDP sessions sessions HIGH Total incomplete sessions TCP/UDP sessions Incomplete sessions TCP/UDP sessions (per min) HIGH Incomplete sessions TCP/UDP sessions...
Page 88 ADSL R ONFIGURING THE If you have a client PC that cannot run an Internet application properly from behind the firewall, you can open the client up to unrestricted two-way Internet access. Enter the IP address of a DMZ (Demilitarized Zone) host on this screen.
Page 89: Snmp
SNMP Use the SNMP configuration screen to display and modify parameters for the Simple Network Management Protocol (SNMP). Community A computer attached to the network, called a Network Management Station (NMS), can be used to access this information. Access rights to the agent are controlled by community strings.
Page 90 ADSL R ONFIGURING THE Trap Specify the IP address of the NMS to notify when a significant event is detected by the agent. When a trap condition occurs, the SNMP agent sends an SNMP trap message to any NMS specified as a trap receiver. Parameter Description IP Address Traps are sent to this address when errors or specific events occur on...
Page 91: Adsl
ADSL ADSL (Asymmetric Digital Subscriber Line) is designed to deliver more bandwidth downstream (from the central office to the customer site) than upstream. This section is used to configure the ADSL operation type and shows the ADSL status. Parameters Parameter Operation Mode This page is designed for the engineer to test the ADSL loop condition.
Page 92 ADSL R ONFIGURING THE Status The Status screen displays information on connection line status, data rate, operation data and defect indication, and statistics. 4-54 OUTER...
Page 93 The following items are included on the ADSL status page: Parameter Description Status Line Status Shows the current status of the ADSL line connection. Link Type Two types of link: Fast path and Interleaved path. Data Rate Upstream Maximum upstream data rate. Downstream Maximum downstream data rate.
Page 94 ADSL R ONFIGURING THE Parameter Statistics Received cells Transmitted cells Number of cells transmitted. 4-56 OUTER Description (Superframes represent the highest level of data presentation. Each superframe contains regular ADSL frames, one of which is used to provide superframe synchronization, identifying the start of a superframe.
Page 95: Tools
DVANCED ETUP Tools Use the Tools menu to backup the current configuration, restore a previously saved configuration, restore factory settings, update firmware, and reset the ADSL Router Configuration Tools Choose a function and click Next. Backup allows you to save the ’s configuration to a file.
Page 96: Firmware Upgrade
ADSL R ONFIGURING THE Firmware Upgrade Use the Firmware Upgrade screen to update the firmware or user interface to the latest versions. Download the upgrade file, and save it to your hard drive. Then click “Browse...” to look for the downloaded file. Click “BEGIN UPGRADE”.
Page 97: Status
Status The Status page displays WAN/LAN connection status, firmware, and hardware version numbers, illegal attempts to access your network, as well as information on DHCP clients connected to your network. The security log may be saved to a file by clicking “Save” and choosing a location. The following items are included on the Status page: Item INTERNET...
Page 98: Finding The Mac Address Of A Network Card
ADSL R ONFIGURING THE Finding the MAC address of a Network Card Windows 98/ME Click Start/Run. Type “winipcfg” and press “ENTER”. The MAC address is in the “Adapter Address” section. Windows NT4/2000/XP Click Start/Programs/Command Prompt. Type “ipconfig /all” and press “ENTER”.
Page 99: Troubleshooting
This section describes common problems you may encounter and possible solutions to them. The ADSL Router can be easily monitored through panel indicators to identify problems. Troubleshooting Chart Symptom Action LED Indicators • Power LED is • PPENDIX ROUBLESHOOTING Check connections between the ADSL Router, the external power supply, and the wall outlet.
Page 100 ROUBLESHOOTING Troubleshooting Chart Symptom LED Indicators Link LED is Off Network Connection Problems Cannot ping the ADSL Router from the attached LAN Action • Verify that the ADSL Router and attached device are powered on. • Be sure the cable is plugged into both the ADSL Router and the corresponding device.
Page 101 Troubleshooting Chart Symptom Action Management Problems Cannot connect • using the web browser • • Forgot or lost • the password Be sure to have configured the ADSL Router with a valid IP address, subnet mask, and default gateway. Check that you have a valid network connection to the ADSL Router and that the port you are using has not been disabled.
Page 102 ROUBLESHOOTING Troubleshooting Chart Symptom Wireless Problems A wireless PC cannot associate with the ADSL Router. The wireless network is often interrupted. The ADSL Router cannot be detected by a wireless client. Action • Make sure the wireless PC has the same SSID settings as the ADSL Router.
Page 103: Ethernet Cable
Ethernet Cable Caution: DO NOT plug a phone jack connector into any RJ-45 port. Use only twisted-pair cables with RJ-45 connectors that conform with FCC standards. Specifications Cable 10BASE-T 100BASE-TX Cat. 5 100-ohm UTP Wiring Conventions For Ethernet connections, a twisted-pair cable must have two pairs of wires.
Page 104: Cables
ABLES Each wire pair must be attached to the RJ-45 connectors in a specific orientation. The following figure illustrates how the pins on an Ethernet RJ-45 connector are numbered. Be sure to hold the connectors in the same orientation when attaching the wires to the pins. Figure B-1.
Page 105: Ethernet Cable
Pin Assignments With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data. RJ-45 Pin Assignments Pin Number 1: The “+” and “-” signs represent the polarity of the wires that make up each wire pair. Straight-Through Wiring If the port on the attached device has internal crossover wiring (MDI-X), then use straight-through cable.
Page 106: Crossover Wiring
ABLES Crossover Wiring If the port on the attached device has straight-through wiring (MDI), use crossover cable. Crossover Cable Pin Assignments End 1 1 (Tx+) 2 (Tx-) 3 (Rx+) 6 (Rx-) End 2 3 (Rx+) 6 (Rx-) 1 (Tx+) 2 (Tx-)
Page 107: Adsl Cable
ADSL Cable Use standard telephone cable to connect the RJ-11 telephone wall outlet to the RJ-11 ADSL port on the ADSL Router. Caution: Do not plug a phone jack connector into an RJ-45 port. Specifications Cable ADSL Line Wiring Conventions For ADSL connections, a cable requires one pair of wires.
Page 108 ABLES R1 T1 1 2 3 4 5 6 6x2 Jack Figure B-3. RJ-11 Pinouts Signal Name Not used Line 2 Tip Line 1 Ring Line 1 Tip Line 2 Ring Not used R1 T1 R2 1 2 3 4 5 6 1 2 3 4 5 6 6x4 Jack T = Tip...
Page 109 Physical Characteristics Ports Four 10/100Mbps RJ-45 Ports One ADSL RJ-11 ADSL Features Supports DMT line modulation Supports Annex A Full-Rate ADSL: up to 8 Mbps downstream, up to 1 Mbps upstream (G.992.1 &T1.413, Issue 2) Supports G.Lite ADSL: up to 1.5 Mbps downstream, up to 512 Kbps upstream Dying GASP support ATM Features...
Page 110 PECIFICATIONS Security Features Password protected configuration access User authentication (PAP/CHAP) with PPP Firewall NAT NAPT VPN pass through (IPSec-ESP Tunnel mode,L2TP, PPTP) LAN Features IEEE 802.1d (self-learning transparent Bridging) DHCP Server DNS Proxy Static Routing, RIPv1 and RIP Applications Netmeeting, ICQ, Real Player, QuickTime, DialPad, PC Anywhere, Telnet, SNTP, NNTP Radio Features Wireless RF module Frequency Band...
Page 111 PECIFICATIONS RF Output Power Modulation Rate-Output Power (dBm) 802.11b - 1Mbps (16 dBm) 802.11b - 2Mbps (16 dBm) 802.11b - 5.5Mbps (16 dBm) 802.11b - 11Mbps (16 dBm) Modulation Rate-Output Power (dBm) 802.11g - 6Mbps (15 dBm) 802.11g - 9Mbps (15 dBm) 802.11g - 12Mbps (15 dBm) 802.11g - 18Mbps (15 dBm) 802.11g- 24Mbps (15 dBm)
Page 112 PECIFICATIONS Modulation Rate-Receiver Sensitivity Typical (dBm) 802.11g - 6Mbps - (88 dBm) 802.11g - 9Mbps - (87 dBm) 802.11g - 12Mbps - (84 dBm) 802.11g - 18Mbps - (82 dBm) 802.11g - 24Mbps - (79 dBm) 802.11g - 36Mbps - (75 dBm) 802.11g - 48Mbps - (68 dBm) 802.11g - 54Mbps - (68 dBm) Environmental...
Page 113 PECIFICATIONS IEEE Standards IEEE 802.3, 802.3u, 802.11g, 802.1d ITU G.dmt ITU G.Handshake ITU T.413 issue 2 - ADSL full rate Standards Conformance Electromagnetic Compatibility CE, ETSI, R&TTE, ETS 300 328, ETS 300 826 Safety EN60950 Internet Standards RFC 826 ARP RFC 791 IP RFC 792 ICMP RFC 768 UDP...
Page 114 PECIFICATIONS...
Page 116 June 2004 Revision: R01 F0.25...
