Slant/Fin SE-245 Brochure

Natural and L.P. Propane Gas
MODEL
NUMBER †
SE-70 70,000
SE-105 105,000
SE-140 140,000
SE-175 175,000
SE-210 210,000
SE-245 245,000
* Net ratings are based on a piping and pick-up allowance of 1.15. Slant/Fin
should be consulted before selecting a boiler for installation having unusual
piping and pick-up requirements. Ratings must be reduced by 4% at 2,000
feet elevation and an additional 4% for every additional 1,000 feet elevation
over 2,000 feet.
SLANT/FIN CORPORATION, Greenvale, NY 11548 • Phone: (516) 484-2600
FAX: (516) 484-5921 • In Canada: Slant/Fin LTD/LTEE, Mississauga, Ontario
www.slantfin.com
RATINGS CHART – GAS BOILERS
®
NET
I=B=R
A.G.A. RATING
D.O.E.
INPUT CAPACITY WATER
(Btuh) *
(Btuh) (Btuh)
58,000 50,000
87,000 76,000
116,000 101,000
145,000 126,000
173,000 150,000
202,000 176,000
EFFICIENCY
(A.F.U.E.)
WATER
STANDING INTERMITTENT
(Sq.Ft.) IGNITION
PILOT
333 81.5 82.0
507 81.6 82.1
673 81.7 82.2
840 81.7 82.2
1000 81.8 82.3
1173 81.8 82.3
†Type of gas: after model number, specify gas by name "Natural" or
"Propane".
Note: All Sentinel boilers are tested and rated for capacity under the U.S.
Dept. of Energy (D.O.E.) Test Procedure for boilers.
SENTINEL SE SERIES
DIMENSIONS
B
A C
11 1 ⁄ " 17 5 ⁄ " 4"
8 8
14 1 ⁄ " 20 5 ⁄ " 5"
8 8
17 ⁄ " 23 ⁄ " 5"
1 5
8 8
20 1 ⁄ " 26 5 ⁄ " 6"
8 8
23 ⁄ " 29 ⁄ " 7"
1 5
8 8
26 1 ⁄ " 32 5 ⁄ " 7"
8 8
D
45 1 ⁄ "
2
46 3 ⁄ "
1 6
46 ⁄ "
3
1 6
47"
48 ⁄ "
3
1 6
48 3 ⁄ "
1 6
