- Page 1 OWNER’S MANUAL AIR CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. TYPE : FLOOR STANDING MODEL : APNW48GTA0 APUW48GTA0 www.lg.com P/NO : MFL67724502...
- Page 2 TIPS FOR SAVING ENERGY TIPS FOR SAVING ENERGY Here are some tips that will help you minimize the power consumption when you use the air conditioner. You can use your air conditioner more efficiently by referring to the instructions below: •...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product WARNING It can result in serious injury or death when the directions are ignored CAUTION It can result in minor injury or product damage when the directions are ignored WARNING... - Page 4 IMPORTANT SAFETY INSTRUCTIONS Operation • Take care to ensure that power cable could not be pulled out or damaged during operation. There is risk of fire or electric shock. • Do not place anything on the power cable. There is risk of fire or electric shock. •...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS • Use two or more people to lift and transport the product. Avoid personal injury. • Do not install the product where it will be exposed to sea wind (salt spray) directly. It may cause cor- rosion on the product. Corrosion, particularly on the condenser and evaporator fins, could cause product malfunction or inefficient operation.
-
Page 6: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS TIPS FOR SAVING EN- MAINTENANCE AND ERGY SERVICE Indoor Unit When the air conditioner is not going IMPORTANT SAFETY IN- to be used for a long time. STRUCTIONS Operation Tips Call the service immediately in the fol- lowing situations BEFORE USE Troubleshooting Tips! Save time and... -
Page 7: Before Use
BEFORE USE BEFORE USE Preparing for operation • Contact an installation specialist for installation. • Use a dedicated circuit. Usage • Being exposed to direct airflow for an extended period of time could be hazardous to your health. Do not expose occupants, pets, or plants to direct airflow for extended period of time. •... -
Page 8: Product Introduction
PRODUCT INTRODUCTION PRODUCT INTRODUCTION Name of parts Indoor unit Outdoor unit 1. Left/Right Airflow Control Louver 1. Air Outlet 2. Up/Down Airflow Control Louver 2. Air Inlet (rear, side) 3. Display/Control Panel 3. Bottom plate 4. Filter 4. Refrigerant Pipe Port 5. -
Page 9: Indoor Unit Controls And Indicators
PRODUCT INTRODUCTION Indoor unit controls and indicators 1. Fan mode operation lamp 10. Indoor fan speed lamp 2. Cooling operation lamp 11. Up/Down air flow lamp 3. Heating operation lamp 12. Left/Right air flow lamp 4. Dehumidification operation lamp 13. Start/Stop button 5. -
Page 10: Wireless Remote Controller
PRODUCT INTRODUCTION Wireless remote controller Control Description panel Remote controller operation lamp Power ON/OFF button : Operation will start when this button is pressed, and stop when the button is pressed again. Indoor fan speed button : To select the desired fan speed. -
Page 11: Remote Control Preparation
Remote control preparation How to mount onto a wall Use the screws to secure the holder to the wall or attach the holder side of indoor unit. To insert the remote control to the holder. - Do not use rechargeable batteries such bat- teries are different from standard dry cells in shape, dimensions, and performance. -
Page 12: Operating Instructions
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Cooling Mode Airflow Setting Press button to turn on the indoor. We can simply adjust the desired airflow di- rection. Press button to select Cooling opera- tion mode. Up/Down Airflow Direction Control - When canceling operating, press but- Press button to turn on the indoor. -
Page 13: Dehumidification Mode
OPERATING INSTRUCTIONS Dehumidification Mode Adjust the desired temperature by press- ing ( ) buttons. In rainy season or high humidity climate, it is - When room temperature is higher than possible to operate simultaneously dehumidi- fier and cooling mode to remove humidity ef- desired temperature, cooling operation will be performed, and when it is lower, fectively. -
Page 14: Defrost Mode
OPERATING INSTRUCTIONS Defrost Mode Press the low and high temperature set- ting buttons simultaneously for 3 seconds During defrost operation, will be indi- again. The unit will respond with beep. cated at display section of indoor. child lock operation will removed. During heating operation, if outside tem- perature is low and humidity is high, heat- ing capability will be deteriorated as frost is... -
Page 15: Maintenance And Service
MAINTENANCE AND SERVICE MAINTENANCE AND SERVICE Indoor Unit Filter Cleaning Please clean it once in a week. Grille, Case and Remote Control Remove the Air filters. - Turn the system off before cleanining, To - Take hold of the tab and pull slightly for- clean, wipe with a soft, dry cloth. -
Page 16: When The Air Conditioner Is Not Going To Be Used For A Long Time
MAINTENANCE AND SERVICE When the air conditioner is not When the air conditioner is to be used again. going to be used for a long time. Clean the air filter and install it in the in- When air conditioner is not going door unit. -
Page 17: Call The Service Immediately In The Following Situations
MAINTENANCE AND SERVICE Troubleshooting Tips! Save time and money! Check the following points before requesting repairs or service..If the malfunction persist, please contact your dealer. The air conditioner The room has a pecu- It seems that conden- Air conditioner does does not operate. - Page 19 İTHALATÇI FİRMA ÜRETİCİ FİRMA Bosch Termoteknik Isıtma ve Klima Sanayi LG Electronics Inc. Ticaret A.Ş. 76, Seongsan-Gu Changwon City Gyeong Merkez Adresi : Organize Sanayi Bölgesi İk- Nam 642-713 R.O.K, South Korea inci Kısım Gaziler Caddesi No.2 45030 Manisa İrtibat Adresi : Ankara Asfaltı Üzeri, Acıba- dem Mah.
