Satellite Radio Sound System
Instruction
Manual
Model
XS097
To activate your Satellite Radio Receiver or for latest news and questions regarding
SIRIUS at
sirius.com
or call 1-888-539-SIRIUS (7474).
For accessory & product information visit us at www.getxact.com.
Deluxe Universal
XTR8 Shown Here
Rotating Console
CD player and AM/FM
radio on side -
Satellite radio receiver
and remote control on
the flip side!
> CD Player with CDRW
and MP3 Playback
> AM/FM Radio
with 10 Presets
Advertisement
Table of Contents
Related Manuals for Sirius Satellite Radio XS097
Summary of Contents for Sirius Satellite Radio XS097
-
Page 1: Instruction Manual
Satellite Radio Sound System Instruction Manual Model XS097 To activate your Satellite Radio Receiver or for latest news and questions regarding SIRIUS at sirius.com or call 1-888-539-SIRIUS (7474). For accessory & product information visit us at www.getxact.com. XTR8 Shown Here... - Page 2 "Sirius" and the Sirius dog logo are registered trademarks of Sirius ® Sirius Satellite Radio Receiver or for latest news and questions regarding Sirius www.sirius.com or call 1-888-539-SIRIUS (7474). TRADEMARKS Satellite Radio Inc. To activate your ®...
-
Page 3: Safety Precautions
4. When installed indoors unplug the AC Power Adapter from the wall outlet when the Deluxe Universal Satellite Radio Sound System is not to be used for an extended period of time. If batteries are installed, set the Power On/Off- VOL control to the Off position to prevent unintentional battery discharge, or remove the batteries. -
Page 4: Fcc Warning
SAFETY RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR DISASSEMBLE). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Dangerous Voltage The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 5 SAFETY Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 6 Dear Customer Selecting fine audio equipment such as the unit you have just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
-
Page 7: Table Of Contents
TABLE OF Introduction Product Overview Package Contents Components Guide Boom Box Setup Configuring your Boom Box Mounting your Boom Box Installing Removable Mounting Clip Installing the Satellite Antenna Installing the Power Cable Installing the Batteries (Optional) Antenna Aiming (XTR8) Antenna Aiming (XTR7) SIRIUS Satellite Map ®... -
Page 8: Introduction
INTRODUCTION Product Overview Thank you for purchasing this product! Your XACT Deluxe Universal Satellite Radio Sound System is compatible with the XTR3, XTR7, and XTR8 Satellite Radio Receivers. Package Contents Carefully unpack your kit box and ensure that you have the following items. - Page 9 Boom Box. AUX Output Jack: Connect audio jack (not included) if you want to listen the Satellite radio signal, CD audio signal or AM/FM radio signal through another audio system. Adjust the volume level on your audio system to the desired level.
-
Page 10: Components Guide
COMPONENTS Deluxe Universal Satellite Radio Sound System 12. SKIP- / TUNNING DOWN 11. PROGRAM / MEMORY BUTTON 10. MODE BUTTON 15. PLAY / PAUSE / PRESET UP 9. ALBUM / BAND BUTTON 8. FUNCTION BUTTON GUIDE Function button: Push to select a function from CD/TUNER/AUX. - Page 11 BOOM BOX Configuring your Boom Box Line up your correct bracket with the screw holes on the center post. Next screw the provided phillips head screws to secure the bracket into place. XTR8 Replay SETUP XTR7 XTR Phillips head screwdriver required for this step.
-
Page 12: Boombox Setup
BOOMBOX Mounting your Visor to the Boom Box 1. Slide the XACT Visor Sirius Satellite Radio Receiver onto the mounting tab of the Boom Box until it locks into place. (figure 1). To remove the XACT Visor Sirius Satellite Radio... -
Page 13: Mounting Your Boom Box
BOOM BOX Mounting you XTR7 XTR to the Boom Box 1. Slide the XACT Sirius Satellite Radio Receiver (figure 1) onto the mounting tab of the Boom Box until it engages. (figure 2). 2. Connect the DC Power, antenna and audio connectors to the appropriate jacks. - Page 14 Mounting you XTR8 Replay to the Boom Box 1. Slide the XACT Sirius Satellite Radio Receiver (figure 1) onto the mounting tab of the Boom Box until it engages. (figure 2). 2. Connect the DC Power, antenna and audio connectors to the appropriate jacks.
-
Page 15: Installing Removable Mounting Clip
Installing Removable Mounting Clip (XTR8) If you have removed your U-button clip from the XTR8 Replay or it was not included with your receiver you will need to use this bracket. 1.) Line-up the two tabs on the bracket with the outer vent holes on the bottom of your receiver. -
Page 16: Installing The Satellite Antenna
Installing the Satellite Antenna Install the Antenna into the Antenna Jack as shown. Installing the Power Cable Install the adapter into the Power Jack as shown. SAT ANT JACK 8 10... -
Page 17: Installing The Batteries (Optional)
Installing Batteries (optional) Your Boom Box can also be used with 8 D-Cell batteries as shown: 1. Push the battery cover latches down and flip up the battery compartment covers to the open position. 2. Insert the 8 D-Cell batteries follow the battery polarity as shown; then close the cover. Note: The batteries are bypassed automatically whenever the supplied DC Adapter is plugged into the power jack on the back of the Boom Box. -
Page 18: Antenna Aiming (Xtr8)
To access the Antenna Aiming Feature: Press the button on the Sirius Satellite Radio Receiver’s key pad. Press the Antenna Aiming selection is highlighted and press Upon entering this option, two 10-segment horizontal bar graphs are displayed with a (-) sign to the left and a (+) sign to the right. -
Page 19: Am/Fm Radio Operation
AM/FM RADIO To Listen To The Radio Press the FUNCTION button to enter the RADIO Mode. Press the ALBUM / BAND button to Select a band (AM or FM). If listening to FM, Press the MODE button to select Stereo or Mono. Press and release the Skip/TUNING DN (12) or UP (13) button to tune a station. -
Page 20: Cd Operation
OPERATION To Insert and Play a CD This CD player is designed to play all kinds of Audio Discs and MP3 CD ROMS, such as CD recordables (CDR) and rewritables(CDRW). Do not try to play CDI, CDV, DVD or computer CD's in this unit. 1. -
Page 21: To Pause A Cd
OPERATION To Pause a CD 1. During CD playback, if you wish to pause the disc momentarily, press the PLAY/PAUSE button. Playback stops but the disc continues to spin and the elapsed time will blink on the display. 2. Press the PLAY/PAUSE button again to release pause and resume playback. The audio is restored and the elapsed time on the display stops flashing. -
Page 22: High-Speed Music Search
OPERATION High-Speed Music Search During playback, press and hold either the Skip/TUNING UP (13) or DN (12) button to move the player forward or backward within a track to locate a specific musical passage. The player will move forward or backward at high speed as long as the buttons are depressed. -
Page 23: Repeat Playback Of A Folder (Mp3 With Folders Only)
OPERATION Repeat Playback of a Folder (MP3 with folders only) 1. To repeat all files in a directory (MP3 CD only), press the MODE button three times; "ALBUM" will appear in the display. Press the Skip/TUNING UP or DN button to select the specific directory that you wish to repeat. -
Page 24: Notes Of Program Playback
OPERATION NOTES ON PROGRAM PLAYBACK: You can review the program by pressing the PROG. button repeatedly while in the Stop mode. To add a track to the program memory, simply press the PROG. Button repeatedly until the track • (directory if using an MP3) appears as "00" in the display, then continue as per the steps 2 and 3 on •... -
Page 25: Single Session
OPERATION Single Session The following chart is an example of a Windows Explorer display that will appear on your computer monitor for a single session MP3 CD ROM with directories/albums. Check the added notes to help you understand the MP3 CD unit display and the playback sequence of directories/albums and tracks on a single session MP3 Multi Session The computer user does not need to finalize the CDR disc as music is burned on the CD. -
Page 26: Specifications
SPECIFICATIONS AUDIO SECTION Nominal Output Power per Channel Total Harmonic Distortion (THD) Frequency Response Signal-to-Noise Ratio Speaker Impedance Headphone Output Impedance Headphone Output Level Headphone Connector Type Auxiliary Input Impedance Auxiliary Input Level Auxiliary Connector Type CD SECTION MPEG Rate Sampling Frequency TUNER SECTION MP3 Playback... -
Page 27: Problem Solving
PROBLEM For your assistance, we have listed a few common problems below. SYMPTOM System does not turn on Boombox does not operate using batteries Intermittent operation Antenna not Detected Message Acquiring Siginal Message No sound from Boombox speakers SOLVING CAUSE Receiver is set to off Batteries not installed or are installed incorrectly... - Page 28 PROBLEM SYMPTOM Disc will not play Erratic CD playback No sound from headphones Noise or sound distorted on radio FM STEREO indicator does not light SOLVING CAUSE CD compartment not closed Disc inserted incorrectly Dirty or defective disc Moisture or condensation on disc Dirty or defective disc Headphone plug not...
-
Page 29: Care And Maintenance
CARE AND Caring for Compact Discs Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, • unprinted side of the compact disc. Do not attach adhesive tape, stickers, etc. to the compact disc label. Clean the compact disc periodically with a soft, lint-free, dry cloth. - Page 30 • Check the VOL control for freedom of motion without binding of any kind. Check that the SAT/Audio Selector operates correctly and that it toggles between the Satellite Radio • output and the Audio output.
-
Page 31: Warranty
WARRANTY W W a a r r r r a a n n t t y y I I n n f f o o r r m m a a t t i i o o n n X X A A C C T T C C o o m m m m u u n n i i c c a a t t i i o o n n One-Year Limited Warranty This limited warranty sets forth all XACT Communication responsibilities regarding your product. - Page 32 WARRANTY W W a a r r r r a a n n t t y y S S e e r r v v i i c c e e N N o o t t P P r r o o v v i i d d e e d d This warranty does not cover damage resulting from accident, misuse, abuse, improper installation or operation, lack of reasonable care, unauthorized modification, or the affixing of any attachment not provided by XACT Communication with the equipment, and/or loss of parts.
- Page 33 WARRANTY T T o o O O b b t t a a i i n n W W a a r r r r a a n n t t y y S S e e r r v v i i c c e e •...
- Page 34 Notes...
- Page 35 Notes...
- Page 36 To activate your Satellite Radio Receiver or for latest news and questions regarding SIRIUS Satellite Radio service visit sirius.com ® or call 1-888-539-SIRIUS (7474). Call Toll Free 1-866-466-XACT (9228) or Visit our Website: www.getxact.com...
